Sql Board; Main Unit - Icom IC-M422 Service Manual

[MAIN UNIT]

REF ORDER
NO. NO.
C345 4030017730 S.CER ECJ0EB1E471K
C346 4030017460 S.CER ECJ0EB1E102K
C347 4030017680 S.CER ECJ0EC1H820J
C348 4030017680 S.CER ECJ0EC1H820J
C349 4030017460 S.CER ECJ0EB1E102K
C351 4030016790 S.CER ECJ0EB1C103K
C353 4030017490 S.CER C1608 JB 1A 105K-T
C354 4030017460 S.CER ECJ0EB1E102K
C355 4510009450 ELE 16 WA 470M (8X9)
C356 4510004591 ELE 16 ME 470 HC+TS
C357 4030011600 S.CER C1608 JB 1E 104K-T
C358 4030017420 S.CER ECJ0EC1H470J
C359 4030017420 S.CER ECJ0EC1H470J
C360 4030017460 S.CER ECJ0EB1E102K
C361 4030017460 S.CER ECJ0EB1E102K
C367 4030017460 S.CER ECJ0EB1E102K
C368 4030017420 S.CER ECJ0EC1H470J
C369 4510006021 ELE 16 ME 2200 HC
C370 4030011600 S.CER C1608 JB 1E 104K-T
C373 4030017400 S.CER ECJ0EC1H220J
C374 4030017400 S.CER ECJ0EC1H220J
C375 4030017430 S.CER ECJ0EC1H101J
C376 4030017730 S.CER ECJ0EB1E471K
C377 4030017420 S.CER ECJ0EC1H470J
C378 4030017460 S.CER ECJ0EB1E102K
C379 4030017430 S.CER ECJ0EC1H101J
C380 4030017730 S.CER ECJ0EB1E471K
C381 4510008120 S.ELE 16 CE 100 BS
C382 4030006900 S.CER C1608 JB 1H 103K-T
C383 4030011600 S.CER C1608 JB 1E 104K-T
C384 4030016930 S.CER ECJ0EB1A104K
C385 4030016790 S.CER ECJ0EB1C103K
C386 4510008120 S.ELE 16 CE 100 BS
C387 4030016930 S.CER ECJ0EB1A104K
C388 4030017460 S.CER ECJ0EB1E102K
C389 4510007310 S.ELE 16 CE 10 BS
C390 4030016930 S.CER ECJ0EB1A104K
C391 4030017460 S.CER ECJ0EB1E102K
C392 4510007310 S.ELE 16 CE 10 BS
C393 4510007310 S.ELE 16 CE 10 BS
C411 4030006900 S.CER C1608 JB 1H 103K-T
C412 4030017420 S.CER ECJ0EC1H470J
C421 4510007280 S.ELE 50 CE 2R2 BS
C422 4510007280 S.ELE 50 CE 2R2 BS
C423 4030016930 S.CER ECJ0EB1A104K
C424 4030017420 S.CER ECJ0EC1H470J
C425 4030017420 S.CER ECJ0EC1H470J
C431 4030018900 S.CER ECJ0EB0J474K
C432 4030017490 S.CER C1608 JB 1A 105K-T
C433 4030017460 S.CER ECJ0EB1E102K
C441 4030017460 S.CER ECJ0EB1E102K
C443 4510004591 ELE 16 ME 470 HC+TS
C444 4510004591 ELE 16 ME 470 HC+TS
C445 4030011600 S.CER C1608 JB 1E 104K-T
C446 4030017420 S.CER ECJ0EC1H470J
J2 6510015541 S.CNR B4B-ZR-SM4-TF (LF) (SN)
J3 6510015541 S.CNR B4B-ZR-SM4-TF (LF) (SN)
J4 6510021720 S.CNR 30FLT-SM1-TB
J5 6510021720 S.CNR 30FLT-SM1-TB
W1 7120000470 JMP ERDS2T0
W2 9091201210 WIR 74/98/050/X99/X99
W3 7120000470 JMP ERDS2T0
W4 8900014020 CBL OPC-1439 <TJM>
W5 8900014020 CBL OPC-1439 <TJM>
W6 7120000470 JMP ERDS2T0
EP2 9033003901 TUB IRRAX 1.0 (d) L=2 mm
EP3 6910017290 TUB IRRAX 1.5 (d) L=30 mm
EP341 6910014690 S.BEA MPZ1608S221A-T
EP342 6910014690 S.BEA MPZ1608S221A-T
EP441 6910014690 S.BEA MPZ1608S221A-T
EP442 6910014690 S.BEA MPZ1608S221A-T
[FRONT UNIT]
REF ORDER
DESCRIPTION
NO. NO.
MC1 0800007890 MIC HM-150B ACC <FG>
0800007900 MIC HM-150SW ACC <FG>
W1 7120000470 JMP ERDS2T0
W2 7120000470 JMP ERDS2T0
DESCRIPTION M.
LOCATION
T
T 50.4/7.5
T 50.4/6.2
T 42.2/15.2
T 42.2/13.9
T
T
T 4.1/74.3
T 18.6/74.9
T 4.1/77.7
T 5.4/77.7
T 9.2/61.9
T 10.6/61.9
T 35.6/78.5
T 32.4/81.9
T 19.3/66.8
T 54.6/82.6
T 39.3/72.9
T
T 36.7/72.9
T 5.4/80.5
T 4.1/80.5
T 34.3/78.5
T 34.6/81.9
T 4.5/56.3
T 6.3/62.5
T
T
T 5.7/67.8
T 14.8/61.8
T
T
T 24.9/63.8
T
T
T 32.8/63.8
T 39.6/65.6
T 39.9/24.3
T 37.5/24.1
T 11.5/13.6
T
T 8.4/10.7
T 2.4/20.5
T
T
T
T 4.1/29.3
T 26.8/67.9
T 5.4/32.6
T 4.1/32.6
T 79.5/12.5
T 37.7/27.2
T
T 62.9/16.5
T 9.9/63.9
T 9.8/66.1
T 9.4/34.1
T 7.4/35.7
M.
LOCATION
[BLACK]
[SW]
[VR BOARD]
H/V
REF ORDER
NO. NO.
16/73.9
R1 7210003220 VAR
W1 8900014010 CBL
10.3/70
5/72.8

[SQL BOARD]

REF ORDER
NO. NO.
R1 7210003150 VAR
6-2 HM-150B/SW
[MAIN UNIT]
38/72.9
REF ORDER
NO. NO.
R1 7010007590
R2 7010007600
R3 7010007610
R4 7010007620
5.7/65
7/67.8
C1 4030018660
30/58.9
MC1 7700002640
22/61.6
32/56.4
S1 2260002780
30/60.2
S2 2260002790
S3 2260002790
S4 2260002790
W1 9027150010
10/23.8
W2 9027150010
W3 9027150020
W4 9027150030
2/12.8
4/21.5 M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
5/27.8
46/10.5
H/V
6 - 5
DESCRIPTION
TP96N97A-15.7SK-10KB-2852
OPC-1442
DESCRIPTION
TP96N97-15SK-10KB-2685
DESCRIPTION
RES 12K R20
RES 6.8K R20
RES 15K R20
RES 33K R20
S.CER 0.022 C1608 16V B
MIC KUC3523-040245
SW SKHHLPA010
SW KHHAMA010
SW KHHAMA010
SW KHHAMA010
W 71/98/010/X98/X98
W 71/98/010/X98/X98
W 24/00/020/W01/W01
W 24/04/020/W01/W01
H/V
M.
LOCATION
H/V
M.
LOCATION
H/V
M.
LOCATION
B 40.9/43.6
S.=Surface mount
