[MAIN UNIT]
REF ORDER
NO. NO.
EP3 6910015370 S.BEA ACZ1005Y-102-T
EP4 6910015600 S.BEA ACZ1005Y-241 (240)
EP5 6910015600 S.BEA ACZ1005Y-241 (240)
EP6 6910015370 S.BEA ACZ1005Y-102-T
EP8 6910014730 S.BEA MPZ2012S331A-T
EP9 6910019100 S.BEA MPZ1608S101AT
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
LOCATION
B 25.4/35.1
T 23.9/21.7
T
B 28.8/29.7
B 75.6/18.6
T 75.9/26.2
S.=Surface mount
H/V
14/26.1
6 - 6
