4. CitySource 96 (RGBCW) - DMX protocol

Version 1.1
Mode/Channel
1 2* 3 4 5
- 1 1 1 -
- 2 2 2 -
- 3 3 3 -
- - 4 4 -
- - - - 1
- - - - 2
- - - - 3
- - - - 4
- - - - 5
- - - - 6
- - - - 7
- - - - 8
1 - - 5 -
CitySource 96 (RGBW)
Value Function
6
- Red LEDs - both LED arrays
0 - 255 Red LEDs saturation control (0-100%)
- Green LEDs - both LED arrays
0 - 255 Green LEDs saturation control (0-100%)
- Blue LEDs - both LED arrays
0 - 255 Blue LEDs saturation control (0-100%)
- White LEDs - both LED arrays
0 - 255 White LEDs saturation control (0-100%)
1 Red LEDs – LED array 1
0 - 255 Red LEDs saturation control (0-100%)
2 Green LEDs - LED array 1
0 - 255 Green LEDs saturation control (0-100%)
3 Blue LEDs - LED array 1
0 - 255 Blue LEDs saturation control (0-100%)
4 White LEDs - LED array 1
0 - 255 White LEDs saturation control (0-100%)
5 Red LEDs - LED array 2
0 - 255 Red LEDs saturation control (0-100%)
6 Green LEDs - LED array 2
0 - 255 Green LEDs saturation control (0-100%)
Blue LEDs - LED array 2
7
0 - 255 Blue LEDs saturation control (0-100%)
White LEDs - LED array 2
8
0 - 255 White LEDs saturation control (0-100%)
Colour macros (255 values) – both LED arrays
9
0 No function (for DMX mode 4 and 6)
White (for DMX mode 1)
1-15 White tones (cool
16 Blue (Blue=full, Red+Green+White=0)
17-55 Red=0, Green up,Blue =full, White=0
56 Light Blue (Red=0, Green=full, Blue =full, White=0)
57 - 95 Red=0, Green=full, Blue down, White=0
Green (Red=0, Green=full, Blue =0, White=0)
96
97 – 134 Red up, Green=full, Blue=0, White=0
135 Yellow-green (Red=full, Green=full, Blue=0, White=0)
136 - 174 Red=full, Green down, Blue=0, White=0
175 Red(Red=full, Green=0, Blue=0, White=0)
176 -214 Red=full, Green=0, Blue up, White=0
215 Magenta (Red=full, Green=0, Blue=full, White=0)
warm)
11
Type of control
proportional
proportional
proportional
proportional
proportional
proportional
proportional
proportional
proportional
proportional
proportional
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
