  • Page 1 Version 1.5...

  • Page 2: Table Of Contents

    3.5 DMX 512 connection ............................8 3.6 Master/slave connection ............................9 3.7 Stand-alone operation ............................10 4. CitySource 96 (SmartWhite) - DMX protocol ......................11 5. Control menu map ..............................12 6. Fixture menu ................................14 6.1 Fixture Address ..............................14 6.2 Fixture information .............................

  • Page 3: Safety Instructions

    CitySource 96 (SmartWhite) FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE POWERING OR INSTALLING YOUR CitySource 96 ! Save it for future reference. This device has left our premises in absolutely perfect condition. In order to maintain this condition and to ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes written in this manual.
  • Page 4 CitySource 96 (SmartWhite) When choosing the installation spot, please make sure that the fixture is not exposed to extreme heat or dust. Avoid using the unit in locations subject to possible impacts. The fixture body never must be covered with cloth or other materials.

  • Page 5: Fixture Exterior View

    CitySource 96 (SmartWhite) 2. Fixture exterior view 1. Lens array 2. Radiator 3. Mounting bracket 4. Tilt-lock screw 5. Power cable 6. Data cable (DMX in/out) 7. Control buttons 8. LED display 9. Antenna Standard version Wireles DMX version 3. Installation...

  • Page 6: Connection To The Mains

    CitySource 96 (SmartWhite) IMPORTANT! OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, including calculating working load limits, installation material being used, and periodic safety inspection of all installation material and the fixture. If you lack these qualifications, do not attempt the installation yourself, but instead use a professional structural rigger.
  • Page 7 CitySource 96 (SmartWhite) You can install a frost foil under the eggcrate top hat to get frost light output. 1. Disconnect the fixture from the mains. 2. Uninstall the eggcrate lens module 25° (2) as described above. 3. Place the frost foil (6) under the the eggcrate top hat (7) and secure it by means of the four screws (1) and washers (3) on the fixture.

  • Page 8: Installation Of The Barn-Doors And Top Hat/Half Top Hat

    CitySource 96 (SmartWhite) 3.4 Installation of the barn-doors and top hat/half top hat You can install the barn-doors or top hat/half top hat to better define illuminated surface. 1. Disconnect the fixture from the mains. 2. Remove the eggcrate lens module 25°(2) by unscrewing the four M5x14 screws (1) including washers (3).

  • Page 9: Master/Slave Connection

    CitySource 96 (SmartWhite) To build a DMX chain 1. Connect the DMX output of the controller directly with the DMX input of the first fixture in the DMX chain. 2. Connect the DMX output of the first fixture in the DMX chain with the DMX input of the next fixture.

  • Page 10: Stand-Alone Operation

    CitySource 96 (SmartWhite) 3.7 Stand-alone operation The fixtures on a data link are not connected to the controller but can execute pre-set programs which can be different for every fixture. To set the program to be played, see the "Stand-alone setting" (menu "St.AL.").

  • Page 11: Citysource 96 (Smartwhite) - Dmx Protocol

    CitySource 96 (SmartWhite) 4. CitySource 96 (SmartWhite) - DMX protocol Version 1.0 Mode Value Function Type of control Warm white –both LED arrays 0 - 255 Warm white LEDs saturation control (0-100%) proportional Cool white – both LED arrays 0 - 255...

  • Page 12: Control Menu Map

    CitySource 96 (SmartWhite) 5. Control menu map Default settings=Bold print Menu Level 1 Menu Level 2 Menu Level 3 Menu Level 4 Menu Level 5 Menu Level 6 A001 dM.Ad. 001-512 MA.SL. d.AbL MASt. InFo Poti. FuLL totL rSEt totL rSEt DM.In.
  • Page 13 CitySource 96 (SmartWhite) Menu Level 1 Menu Level 2 Menu Level 3 Menu Level 4 Menu Level 5 Menu Level 6 tEM.U. °C, °F LOAd FuLL In.Po. WWh.1 0-255 F.dim 0-255 Stor. hOLd On, Off dFSE MAn.M. PrE.C. WWh.1 WW01..WW.03 dimr di.01...di.06...

  • Page 14: Fixture Menu

    CitySource 96 (SmartWhite) Menu Level 1 Menu Level 2 Menu Level 3 Menu Level 4 Menu Level 5 Menu Level 6 S.tim. 0-25.5 sec CoPY SPEC. rdML rdMH Adj. WWh.1 F.dimr CaL.U. WWh.1 CWh.2 Stor. rAdI* r.InF. No.LI (0-100) r.UnL.

  • Page 15: Fixture Information

    - the function shows the total number of the operation hours in the “FuLL” mode since the CitySource 96 has been fabricated. rESEt - the function shows the number of the operation hours that the CitySource 96 has been powered on in the “FuLL” mode since the counter was last reset. In order to reset this counter to 0 you have to press and hold the UP and DOWN buttons and at the same time press the ENTER button.

  • Page 16: Personality

    CitySource 96 (SmartWhite) Measuring points: LEdS.--- the temperature of the LEDs module. boAr. --- the temperature on the PCB in the fixture base. The temperatures can be displayed in either °C or °F units - see option “tEM.U“ in the menu “Pers“.

  • Page 17: Test Sequences

    6. 5 Test sequences Use this menu to run demo-test sequences without an external controller, which will show you some possibilities of using the CitySource 96. 6.6 Stand-alone setting The fixtures on a data link are not connected to the controller but can execute pre-set programs which can be different for every fixture.

  • Page 18: Special Functions

    - Flash cable RS232/DMX No.13050624 (if you want to use a serial port of PC) - Robe Universal Interface (if you want to use an USB port of PC) Note1: Software update should execute a qualified person. If you lack qualification, do not attempt the update yourself and ask for help your ROBE distributor.
  • Page 19 DMX input of the fixture if you using the flash cable RS232/DMX with the DMX input of the Robe Universal Interface if you using the USB cable. Disconnect the fixture from the other fixtures in a DMX chain. Turn both the computer and the fixture on.

  • Page 20: Rdm

    DMX512, the RDM protocol allows a console or dedicated RDM controller to send commands to and receive messages from specific moving lights. RDM allows explicit commands to be sent to a device and responses to be received from it. The list of commands for CitySource 96 is the following. Parameter ID Discovery command...

  • Page 21: Wireless Dmx Operation

    CitySource 96 (SmartWhite) 8. Wireless DMX operation The wireless version of the CitySource 96 is equipped with the Lumen Radio CRMX module and antenna for receiving DMX signal. CRMX module operates on the 2.4 GHz band. To link the fixture with DMX transmitter.
  • Page 22 CitySource 96 (SmartWhite) • Operations modes: DMX, Stand-alone, Master/Slave • Manual control of all effects via control panel • 3 user editable programs each up to 68 steps Wireless DMX/RDM module (only for Wireles DMX version) • Compliance with USITT DMX-512 (1986 & 1990) and 512-A •...
  • Page 23 Protection factor • IP 65 (except DMX IN/OUT connectors) Included items • 1 x CitySource 96 (CitySource 96/W) • 1 x Eggcrate lens module 25° (No. 10980067) • 1 x omega holder (No. 99010420) • 1 x Removable floor stand (No.99512731) •...

  • Page 24: Cleaning And Maintenance

    CitySource 96 (SmartWhite) Note: By reason of the fast-moving development of LED technology, newer products may have better light parameters than previous products. 11. Cleaning and maintenance DANGER ! Disconnect from the mains before starting any cleaning or maintenance work Rinse off loose dirt with low pressure water spray.
  • Page 25 CitySource 96 (SmartWhite)
