Amperes AM6000 Instruction Manual

INSTRUCTION MANUAL
AM6000
amplifier monitor panel
AM 6000
Thank you
AM6000 monitor panel does not only provide audio monitoring of your pa power amplifiers of up to 6 units
connected to it with its high fidelity 1 watt speaker, but it offers 7 level LED monitoring as well as continuous
audio presence signal indicators. The LED level meter proves to be useful in the amplifier output calibration of
your installation.
With AM6000, we offer a product of easy installation, with the affordable price of a quality equipment. Though
it is rather simple in the installation works, a brief read through the manual is recommended.
the emerging preference
amperes electronics
www.ampereselectronics.com
MONITOR VOLUME
2 3
1 4
OFF MAX
for selecting and trusting another product from Amperes Electronics.
AMPLIFIER SELECT
-24 -21 -18 -15 -12 -9
3 4
2 5
1 6
AMPLIFIER OUTPUT LEVEL METER ( dB )
AMPLIFIER OUTPUT SIGNAL
1 2 3 4
-6 -3 0
amperes
5 6
