Thank you
for choosing another quality product from Amperes Electronics.
MC2000 serves a variety of simple applications for a small PA setup such as restaurants, meeting rooms, lecture theatres or
boutiques. It fits into the requirement where budget is concerned but without compromising the quality and essential needs
such as multiple microphone inputs with phantom power, audio source inputs and other line inputs.
60W and 120W 100V line output variants are available. With this latest version, the internal circuits had been improvised to
include front mic muting and better circuitry.
We thank you for trusting another product from Amperes and we shall keep improving the product for better results while
keeping the cost low.
INSTRUCTION MANUAL
MC2106 60W 100V
MC2112 120W 100V
60 / 120W Basic Mixer Ampli ers
IMPROVED

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MC2106 and is the answer not in the manual?

Questions and answers

Summary of Contents for Amperes MC2106

  • Page 1 60W and 120W 100V line output variants are available. With this latest version, the internal circuits had been improvised to include front mic muting and better circuitry. We thank you for trusting another product from Amperes and we shall keep improving the product for better results while keeping the cost low.
  • Page 2 Parts Identifications Fornt View: Rear View: 1. INPUT LEVEL CONTROLS Individual control knobs for input 1 to 6. 2. LED INDICATORS LED indicators for Power and 4 segment output level meter. 3. MIC INPUT JACK Ch 1 is input for Mic Signal (balanced), BGM shall be muted when the front mic is active. 4.
  • Page 3 Parts Identifications REC OUTPUT Unbalanced line level output for connection to external link. The output level is independent of master volume. AC INPUT TERMINAL Supply of 220 ~ 240V ac via fused IEC connector. 11. RCA JACK For unbalanced line input sources such as CD player, etc. 12.
  • Page 4 Application Example 8 Ohm Speakers or 100v Speaker with Matching Trans Paging stereo CD1001 Dynamic / Cond. Microphone Note : 1. Paging microphone shall be without zone selection. 2. Speaker output connected to speakers with matching transformer (100V line out ) or without transformer of 4 Ohm.
  • Page 5 Connecting Paging Microphone External paging desk ( eg. Amperes PM1000 ) can be connected to the unit either at mic or line input phone jack, using 1/4” stereo phone jack. The diagram below illustrates the connection of Amperes PM1000 paging desk with zone selection :...
  • Page 6 Phantom Power PHANTOM POWER SWITCH Switch on when condenser microphone is used. In normal usage, it is recommended Channel 2 is provided with switchable phantom power of 12V. that it is switched off CH 2 is provided with phantom power Block Diagram LED LEVEL INDICATORS 12V Phantom...
  • Page 7 6 input channels for mic and line with phantom power for input 2 Tone and bass controls 70 / 100V line output with 4 ohm terminal with audio line output Short circuit, thermal protections Fan-less ventilation for silent operation Technical Specifications MC2106 MC2112 Rating 60W 100V line 120W 100V line Operating voltage...
  • Page 8 Only Amperes Electronics Service Centres are allowed to make warranty repairs : a list of Amperes Electronics Service Centres may be asked for by the purchaser or send directly to Amperes Electronics Sdn Bhd or its authorized master distributor, TNT Sales Sdn Bhd. This warranty is not valid if repairs are performed by unauthorized personnel or service centres.

This manual is also suitable for:

Mc2112
