• Move the limit switch S11p,
until it makes contact with the platform slider.
• Check the horizontal position of the barriers.
They are pre-adjusted from Lehner-
Lifttechnik already, but it could be necessary
to finish them on site.
• It is possible to adjust both barriers
separately. Open the screw shown in the
illustration, adjust the barrier and lock the
adjustment with the screw again.
• Adjust limit switch S11m, so the barriers are
horizontal position when the automatic
platform is opened.
• Adjust limit switch S11o, so the platform is
pressed towards the carriage by the
automatic drive when the platform is closed.
Omega platform lift
OMEGA
Installation Manual
Screw for
adjusting
