Table of Content
Quick Installation .................................................. 4
1.1 Layout ........................................................................... 4
1.2 Item Checklist .............................................................. 5
1.3 Jumpers ....................................................................... 5
1.4 Connectors .................................................................. 7
1.5 Form Factor ............................................................... 14
Feature ................................................................. 15
2.1 Motherboard Components Placement .................... 15
2.2 Block Diagram............................................................ 17
2.3 Specifications ............................................................ 18
Hardware Setup .................................................. 20
3.1 Before Installation ..................................................... 20
3.2 Install the Processor ................................................. 21
3.3 Install Memory Modules ............................................ 25
3.4 ATX Power Supply connector ................................... 27
3.5 Back Panel ................................................................. 29
FB11342400000
DVD266/DVD266-R Version 1.3A
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for IWILL DVD266
Summary of Contents for IWILL DVD266
-
Page 1: Table Of Contents
2.3 Specifications ............18 Hardware Setup ..........20 3.1 Before Installation ............. 20 3.2 Install the Processor ..........21 3.3 Install Memory Modules ..........25 3.4 ATX Power Supply connector ........27 3.5 Back Panel ..............29 FB11342400000 DVD266/DVD266-R Version 1.3A... - Page 2 4.8 Power Management Setup ........60 4.9 PnP/ PCI Configurations ........... 67 4.10 PC Health Status ............71 4.11 Iwill Smart Setting ........... 72 4.12 Load Fail Safe Defaults ........... 75 4.13Load Optimized Defaults .......... 76 4.14 Set Supervisor/ User Password Setting ....77 4.15 Save &...
- Page 3 Chapter 1 Quick Installation Power Installar CD ..........91 6.1 Software Installation ..........91 6.2 How to use the Power installer CD ......91 6.3 How to make driver diskette ........92 6.4 Install Driver ............... 93 6.5 Install Software Utility ..........94...
-
Page 4: Quick Installation
Chapter 1 Quick Installation 1 Quick Installation 1.1 Layout CPU 0 Keyboard Boot CPU FAN DRAM Votage CPU 1 CPU FAN ATX Power Connector A G P AUX IN PCI1 CD IN PCI2 PCI3 Audio VT8233 SPDIF PCI4 (SPDIF Version O n l y PCI5 Winbond... -
Page 5: Item Checklist
Chapter 1 Quick Installation 1.2 Item Checklist The motherboard Operation manual ATA 66/100 cable Floppy cable Power Installer CD 2 x High Quality CPU Cooler Optional USB riser kit Thermal Sensor for System 1.3 Jumpers 1.3.1 Clear CMOS jumper(CMOS) Normal (Default) Clear CMOS Clear CMOS Jumper... - Page 6 Chapter 1 Quick Installation Audio jumper Audio Enabled (Default) Disabled I D E R AI D j um per ( DVD 266- R O nl y) IDE RAID Enabled (Default) Disabled...
-
Page 7: Connectors
Chapter 1 Quick Installation FAN Connectors 1: GND 2: 12V 3: Sensor CPU FAN 1: GND 2: 12V 3: NC Aux FAN 1: GND 2: 12V 3: Sensor System FAN J39: CPU 0 Fan header (J39) J40: CPU 1 Fan header J70: Auxiliary Fan header(J70) J41: System Fan header (J41) Infrared connector (IR) PIN Assignment... - Page 8 Chapter 1 Quick Installation 1.4.5 Wake-ON-LAN header PIN Assignment 1 : 5 V S B 2 : G N D 3: LAN Wake 1. 4. 6 W ake O n M oden PIN Assignment 1 : 5 V S B 2 : G N D 3: Control PIN...
- Page 9 Chapter 1 Quick Installation 1.4.7 Case Open Case Open 1.4.9 Front panel connector (J43)
- Page 10 Chapter 1 Quick Installation Function Pin No. Definition PWR ON (Power /Soft Off) 12, 24 Pin 21: Anode ACPI (ACPI LED) 21, 22 Pin 22: Cathode Pin 17: Anode ALED (IDE LED) 17, 18 Pin 18: Cathode Pin 13: Reset RST (Reset) 13, 14 Pin 14: GND...
- Page 11 Chapter 1 Quick Installation Aux-In connector(Aux_IN) AUX_IN Pin Assignment 1:Left channel 2-3:GND 4:Right Channel CD_In connector(CD_IN) CD_IN Pin Assignment 1:Left channel 2 : G N D 3 : G N D 4:Right Channel...
-
Page 12: Internal Usb Connector
Chapter 1 Quick Installation 1.4.11 Internal USB connector The motherboard has two USB ports onboard. The extra two USB support can only functionable with the additional USB riser kit. U S B 1 U S B 2 Pin Assignment 1:5V 6 : U S B D T 3 + 2:5V 7 : G N D... - Page 13 Chapter 1 Quick Installation 1.4.12ATX power connector (J37) Pin Assignment P i n N o . D e f i n i t i o n P i n N o . D e f i n i t i o n + 3 .
-
Page 14: Form Factor
Chapter 1 Quick Installation 1.5 Form Factor VT8233 Winbond 260CM... -
Page 15: Feature
Chapter 2 Feature 2 Features 2.1 Motherboard Components Placement... - Page 16 Chapter 2 Feature Description ATX Power connector VIA VT8633 C P U 0 S o c k e t System Memory Socket (DDR) On board IDE Channels AGP slot IDE RAID Channels VIA VT8233 FDC connector AMI IDE RAID Chip (MG80649) 5 x PCI slots Joystick, Midi Line In / Out, Mic In C O M 2...
-
Page 17: Block Diagram
Chapter 2 Feature 2.2 Block Diagram... -
Page 18: Specifications
Chapter 2 Feature 2.3 Specifications Processor/Socket 370 Supports Socket370 processors Supports 66M/100M/133MHz Front Side Bus Support Dual or Single Intel Pentium III (Cu-256, FCPGA) CPU from 500MHz to 1.13GHz or higher Supports Single Intel Celeron (Cu-128, FCPGAM) CPU from 566MHz to 800MHz or higher CPU Frequency / Voltage Selection Supports Vcore selection from BIOS Supports CPU Multiplier selection by BIOS (from 2X to 12X) - Page 19 Chapter 2 Feature RAID Support (DVD266-R only) Supports 2 ATA66/100 channels Supports RAID Lev el 0/1/0+1 Supports “ SPARE” feature Supports Win9X/WinNT/Win2k/Linx On board PCI Audio C-Media CM8738 4.1channel Hardware Sound on board Management Supports Voltage monitoring Supports Fan control signal...
-
Page 20: Hardware Setup
Chapter 3 Hardware Setup Hardware Setup 3.1 Before Installation For installation, you may need some or all of the following tools: Medium size flat blade screwdriv er Medium size Phillips head screwdriv er A 3/16 inch nut driv er or wrench Users must follow these guidelines to ensure the motherboard is protected during installation. -
Page 21: Install The Processor
Chapter 3 Hardware Setup 3.2 Install the Processor The CPU should have a fan attached to it to prevent overheating. Be sure that there is sufficient air circulation across the processors heatsink by regularly checking that your CPU fan is working. Without sufficient circulation, the processor could overheat and damage both the processor and the motherboard. - Page 22 Chapter 3 Hardware Setup Step1: Locate the ZIF socket and open it by first pulling the lever of socket upward. Step2: Insert the CPU into the socket. Please keep the lever right angle when inserting CPU.
- Page 23 Chapter 3 Hardware Setup Step3: When inserting the CPU please note the correct orientation as shown. The notched corner should point toward the end of the lever. Step4: Push the lever down to close the socket.
- Page 24 Chapter 3 Hardware Setup Step 5: Attach the heatsink onto the CPU. Step6: Push the clip of heatsink downward to hock the ear of socket firmly. Step7: Finally, attach the fan cable to the CPU fan header FCPU.
-
Page 25: Install Memory Modules
Chapter 3 Hardware Setup 3.3 Install Memory Modules The motherboard has four sockets for DDR memory module and supports the maximum memory capacity up to 4GB. These architecture to prov ide the best choice for performance. Step 1:Open latches of DIMM socket Step 2:Proofread the RAM module to the DIMM Socket. - Page 26 Chapter 3 Hardware Setup Step 4:Press the latches into the notches of the RAM module.
-
Page 27: Atx Power Supply Connector
Chapter 3 Hardware Setup 3.4 ATX Power Supply Connector 3.5.1 Power on procedures STEP Description After all connections are made, close the System Case Be sure that all switches are off. Connect the power cord into the power suppply located on the back of your system case. - Page 28 Chapter 3 Hardware Setup The power LED on the front panel of the chassis will light. After few seconds, the system will then run power- on tests. Some additional messages will appear on the screen during the test. If you do not see anything within 30 seconds from the time you turn on the power, the system may have failed a power-on test.
-
Page 29: Back Panel
Chapter 3 Hardware Setup 3.5 Back Panel F u n c t i o n c o l o r D e s c r i p t i o n P S 2 / M o u s - T h i s c o n n e c t o r c a n b e u s e d t o s u p p o r t G r e e n a P S / 2 m o u s e... -
Page 30: Bios Setup
Chapter 4 BIOS Setup BIOS Setup 4.1 PhoenixNet Introduction PhoenixNet is a service that prov ides PC users with best-of- breed, free, software serv ices to support their PC hardware and software and to turn their computer into a powerful tool for communication, entertainment, education and business 4.1.1 Internet Launch System The PhoenixNet Internet Launch System (ILS) is a patent-... - Page 31 Chapter 4 BIOS Setup 4.1.3 PhoenixNet Online Services Manage & protect your computer and your files Antivirus.com Driveway Help.com Turn your computer into a communication tool RocketTalk FireTalk Adobe ActiveShare Turn your computer into an entertainment center Real JukeBox NetRadio Save time and money when shopping online MySimon CNET.com Best of the Web…...
- Page 32 Chapter 4 BIOS Setup 4.1.4 User Boot User reads system information from graphic Launch Screen. User registers MS Windows and completes MS OOBE. User accepts/Rejects PhoenixNet service. User accepts/Rejects PhoenixNet ISP partnery. PhoenixNet and ISP icon appear on desktop. 4.1.5 Internet Access PhoenixNet sets desktop icons &...
-
Page 33: Bios Setup
4.2.1 Upgrade BIOS The BIOS can be upgraded from a diskette with the Award Flash utility — AWDFLASH.EXE. The BIOS image file, and update utility are av ailable from IWILL’ s WEB site: http://suport.iwill.net 4.2.2 Enter BIOS setup program Power-on the system by either pressing the Power-On button, or by using any of the power-on features prov ided by the motherboard. - Page 34 Chapter 4 BIOS Setup 4.2.3 Using BIOS setup program M o v e t o t h e p r e v i o u s f i e l d D o w n M o v e t o t h e n e x t f i e l d L e f t M o v e t o t h e f i e l d o n t h e l e f t h a n d s i d e...
-
Page 35: Main Menu
Chapter 4 BIOS Setup 4.3 Main Menu The main menu allows you to select from sev eral setup pages. Use the arrow keys to select among these pages and press <Enter> key to enter the sub-menu. A brief description of each highlighted selection appears at the bottom of the screen. -
Page 36: Standard Cmos Features
Chapter 4 BIOS Setup 4.4 Standard CMOS Features 4.4.1Date This field specifies the current date. The date format is <month>, <day>, and <year>. 4.4.2 Time This field specifies the current time. The time format is <hour>, <minute>, and <second>. The time is calculated based on the 24-hour (military-time) clock. - Page 37 Chapter 4 BIOS Setup 4.4.3 IDE Primary Master / Primary Slave / Secondary Master / Secondary Slave Press “ Enter” to enter next page for detail hard driv e setting. 4.4.3.1 IDE HDD Auto-Detection Auto-Detect the HDDs Capacity, and its parameters, ex: Cylinder, Head and Sector.
- Page 38 Chapter 4 BIOS Setup 4.4.3.5 Cylinders Set the number of cylinders for this hard disk. 4.4.3.6 Heads Set the number of read/write heads 4.4.3.7 Precomp Setting a v alue of 65535 means no hard disk 4.4.3.8 Sectors Set the number of sectors per track 4.4.4 Drive A / Drive B This field specifies the traditional type of floppy driv es.
- Page 39 Chapter 4 BIOS Setup Disabled No 3 Mode drive is connectedd (Default Value) Drive A A 3 Mode drive is connected as drive A Drive B A 3 Mode drive is connected as drive B Both Both drive A and drive B are 3 Mode drives 4.4.6 Video EGA/VGA Specifies EGA or VGA adapterd...
-
Page 40: Base Memory
Chapter 4 BIOS Setup 4.4.8 Base Memory The POST (Power-On Self Test) determines the amount of base (conv entional) memory installed in the system. The v alue of the base memory is typically 640K. This field has no options. 4.4.9 Extended Memory The BIOS determines how much extended memory is present during the POST. -
Page 41: Advanced Bios Features
Chapter 4 BIOS Setup 4.5 Advanced BIOS Features... -
Page 42: Virus Warning
Chapter 4 BIOS Setup 4.5.1 Virus Warning When this function is enabled, the BIOS monitor the boot sector and partition table of the hard disk driv e for any attempt at modification. If an attempt is made, the BIOS will halt the system and then display an error message. -
Page 43: Quick Power On Self Test
Chapter 4 BIOS Setup 4.5.6 Quick Power On Self Test This field allows the system to skip certain tests while booting. This will decrease the time needed to boot the system. Enable (Default Value), Disabled 4.5.7 First / Secondary / Third / Other Boot Device The BIOS attempts to load the operating system from the dev ices in the sequence selected in these items. -
Page 44: Gate A20 Option
Chapter 4 BIOS Setup 4.5.11 Gate A20 Option This field configures how the gate A20 is handled. The gate A20 is a device used to address memory abov e 1 MB. At first, the gate A20 was handled from a pin on the keyboard. While some keyboards still prov ide this support, it is more common, and much faster, for modern system chipsets to prov ide support for gate A20. -
Page 45: Security Option
Chapter 4 BIOS Setup 4.5.14 Typematic Delay (Msec) When enabled, typematic delay allows you to select the time delay between when the key is first pressed and when the acceleration begins. 250msec (Default Value) 500msec, 750msec, 1000msec 4.5.15 Security Option This field configures how the system security is handled. - Page 46 Chapter 4 BIOS Setup 4.5.19 Video BIOS Shadow When enabled, the v ideo BIOS will be copied to system memory and increase the v ideo speed. Enable(Default Value), Disabled 4.5.20 C8000-CBFFF/CC000-CFFFF/D0000-D3FFF Shadow D4000-D7FFF/D8000-DBFFF/DC000-DFFFF Shadow Enable, Disabled (Default Value)
-
Page 47: Advanced Chipset Features
Chapter 4 BIOS Setup 4.6 Advanced Chipset Features This setup page is used to specify advanced features av ailable through the chipset. The default settings hav e been chosen carefully for most operating conditions. DO NOT change the v alue of any field in this setup page without full understanding. -
Page 48: Dram Clock
Chapter 4 BIOS Setup DRAM Settings The first chipset settings deal with CPU access to dynamic random access memory (DRAM). The default timings hav e been carefully chosen and should only be altered if data is being lost. Such a scenario might well occur if your system had mixed speed DRAM chips installed. -
Page 49: Bank Interleave
Chapter 4 BIOS Setup 4.6.4 Bank Interleave Select numbers of Bank to realize fast and seamless data access mode among many different pages. Disabled (Default Value), 2 Banks, 4Banks 4.6.5 VT8633 50H bit 4-0 4.6.6 DRAM Page-Mode Disabled (Default Value), Enabled 4.6.7 DRAM Parity / ECC Check This item allows you to enable/disable the DRAM Parity/ECC Check. - Page 50 Chapter 4 BIOS Setup 4.6.10 AGP Driving Control This item allows you to choose the AGP driv ing mode by Auot or manual. Auto(Default Value), Manual 4.6.11 AGP Driving Value 4.6.12 AGP Fast Write Enable, Disabled (Default Value) 4.6.13 AGP Master 1 WS Write Enable, Disabled (Default Value) 4.6.14 AGP Master 1 WS Read Enable, Disabled (Default Value)
-
Page 51: Pci Delay Transaction
Chapter 4 BIOS Setup 4.6.17 PCI Master O WS Write Enable(Default Value), Disabled 4.6.18 PCI Delay Transaction Enable, Disabled (Default Value) 4.6.19 Memory Hole In order to improv e performance, certain space in memory is reserv ed for ISA cards. This memory must be mapped into the memory space below 16MB. -
Page 52: Integrated Peripherals
Chapter 4 BIOS Setup 4.7 Integrated Peripherals... -
Page 53: Via Onchip Ide Device
Chapter 4 BIOS Setup 4.7.1VIA OnChip IDE Device 4.7.1.1 On-Chip Primary IDE Channel 0 This field enables or disables the onboard IDE controller. Enable (Default Value), Disabled 4.7.1.2 On-Chip Secondary IDE Channel 1 This field enables or disables the onboard IDE controller. -
Page 54: Via Onchip Pci Device
Chapter 4 BIOS Setup 4.7.1.4Primary Master / Slav e UDMA Secondary Master / Slav e UDMA If you select Auto, the IDE controller uses Ultra DMA 33/66 Mode to access Ultra DMA-capable IDE dev ices. Disabled, Auto (Default Value) 4.7.2 VIA OnChip PCI Device 4.7.2.1AC97 Audio This item allows you to decide to enable/disable theVIA chipset family to support AC97 Audio. -
Page 55: Usb Keyboard Support
Chapter 4 BIOS Setup 4.7.4 OnChip USB Controller This item allows you to decide how many ports that you want to use. All Disabled (Default Value), All Enabled, 1&2/1&3 USB Port, 1/2/3 USB Port 4.7.5 USB Keyboard Support This item allows you to choose to support USB keyboard or not. -
Page 56: Onboard Fdc Controller
Chapter 4 BIOS Setup 4.7.8 KB Password Power-On In yu wish to use this function, bring the cursor to the field writen Enter, then press <Enter>. The computer eill display the message, “ Enter Password” . Type your password is displayed, re-type your password. - Page 57 Chapter 4 BIOS Setup 3F8 / IRQ 4 Port address 3F8h, IRQ 4 (Default Vaule) 2F8 / IRQ 3 Port address 2F8h, IRQ 3 (Default Vaule) 3E8 / IRQ 4 Port address 3E8h, IRQ 4 2E8 / IRQ 3 Port address 2E8h, IRQ 3 Auto BIOS assigns port address and IRQ channel automatically.
-
Page 58: Ir Duplex Mode
Chapter 4 BIOS Setup 4.7.15 IR Duplex Mode When setting the field t either IrDA or ASKIR , you must select th emode of receiv ing and transmitting signals. Full , Half (Default Value) 4.7.16 Use IR Pins IR-Rx2Tx2 (Default Value), RxD , TxD 4.7.17 Onboard Parallel Port This field configures the onboard parallel port. -
Page 59: Epp Mode Select
Chapter 4 BIOS Setup 4.7.19 EPP Mode Select When the Parallel Port Mode field is configured as EPP, ECP+EPP mode, the EPP v ersion needs to be specified. Please refer to ypur peripheral document before selecting field. EPP1.7 Use EPP 1.7 protocol EPP1.9 Use EPP 1.9 protocol (Default Value) -
Page 60: Power Management Setup
Chapter 4 BIOS Setup 4.8 Power Management Setup Each power-sav ing mode has a respectiv e timer. The v alue of the timer can be assigned or reloaded and it will count down to zero. When the timer equals to zero, the system will be forced into the related suspend or power-sav ing mode. -
Page 61: Power Management
Chapter 4 BIOS Setup 4.8.1 Power Management This feature allows the user to select the default parameters for the power-sav ing mode. When idle for one hour, the system Min saving entersuspend mode. When idle for fifteen minutes, the Max Saving system enters suspend mode. -
Page 62: Pm Control By Apm
Chapter 4 BIOS Setup 4.8.4 APM Suspend Timer This field specifies the time the system enters power-sav ing mode. It is av ailable only when the Power Management field is set to User Define. 1Min, 2Min, 4Min, 6Min, 8Min 10Min, 20Min,30Min, 40Min, 1Hour, Disable (Default Value) 4.8.5 PM Control by APM When enabled, an Adv anced Power Management (APM) -
Page 63: Video Off Method
Chapter 4 BIOS Setup 4.8.7 Video off Method Turn off the vertical and horizontal V/H SYNC+Blank synchronization ports and write blanks (Default Vaule) to the video buffer. Writes blanks to the video buffer Blank Screen onlye. DPMS Initial display power management signaling with DPMS. -
Page 64: Irqs Activity Monitoring
Chapter 4 BIOS Setup 4.8.10 IRQs Activity Monitoring These are I/O ev ents whose occurrence can prev ent the system from entering a power-sav ing mode, or can awaken the system from such a mode. In effect, the system remains alert for anything that occurs to a dev ice configured and recognized by the system, ev en when the system is in a power down mode. - Page 65 Chapter 4 BIOS Setup 4.8.10.5 Wake up by PCI card When enabled, you can “ wake-up” your system using a PCI rev.2.2 card, such as a WOL card, connected in your PCI slot. Enabled, Disabled (Default Value) 4.8.10.6 Wake Up by Ring/LAN When enabled, the PC can power-on through an external modem connected to your PC.
- Page 66 Chapter 4 BIOS Setup 4.8.10.8 IRQs Activity Monitoring When On, any ev ent that occurs will awaken the system after it has powered-down.The following is a list of IRQs, or Interrupt Requests, which can be exempted much as the COM ports and LPT ports above can.
-
Page 67: Pnp/ Pci Configurations
Chapter 4 BIOS Setup 4.9 PnP/ PCI Configurations... -
Page 68: Pnp Os Installed
Chapter 4 BIOS Setup 4.9.1 PNP OS Installed The field specifies whether a Plug and Play operating system is installed. Yes, NO (Default Value) 4.9.2 Reset Configuration Data Normally, you leav e this field Disabled. Select Enabled to reset Extended System Configuration Data (ESCD) when you exit Setup if you hav e installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system can not boot. - Page 69 Chapter 4 BIOS Setup 4.9.3.1 IRQ Resources When resources are controlled manually, assign each system interrupt a type, depending on the type of dev ice using the interrupt. 4.9.3.1IRQ3/4/5/7/9/10/11/12/14/15 assigned to PCI Device Reserved (Default Value) 4.9.4 PCI / VGA Palette Snoop This field controls the ability of a primary PCI graphics controller to share a common palette with an ISA/VESA v ideo or MPEG card.
- Page 70 Chapter 4 BIOS Setup 4.9.6Assign IRQ For USB Enable (Default Value) , Disabled 4.9.7Assign IRQ For PCI PCI 1/5 IRQ PCI 2/Onboard Sound PCI 3/OnboardRAID PCI 4 These fields set how IRQ use is determined for each PCI slot. The default setting for each field is Auto, which uses auto-routing to determine IRQ use.
-
Page 71: Pc Health Status
Chapter 4 BIOS Setup 4.10 PC Health Status This page is monitoring your status of computer. On the screen displays CPU/System temperature, FAN speed, and voltages. -
Page 72: Iwill Smart Setting
BIOS Setup 4.11 Iwill Smart Setting O v e r - c l o c k i n g i s n o t g u a r a n t e e d . U s e r s m u s t h a v e s u b s t a n t i a l k n o w l e d g e o f p r o p e r C P U r e l a t i v e t o a d j u s t i n g C P U s p e e d s . -
Page 73: Spread Spectrum
Chapter 4 BIOS Setup 4.11.1 Iwill MicroStepping MicroStepping Microstepping is Iwill's anther step forward to prov ides users a fuss free CPU frequency set up procedure. It contains two main functions, Auto Detecting CPUs speed and Micro Adjustable CPU FSB speed. - Page 74 Chapter 4 BIOS Setup 4.11.3 CPU/DDR Clock This field allows user to adjust the CPU external and to show the DRAM clock. 4.11.4 CPU Clock Ratio 3, 3.5, 4, 4.5, 5, 5.5, 6, 6.5, 7, 7.5 ,8 8.5, 9, 9.5, 10, 11.5, 12 Note:BIOS will auto-detect and display your CPU Ratio 4.11.5 CPU Vcore Setting Auto (Default Value),...
-
Page 75: Load Fail Safe Defaults
Chapter 4 BIOS Setup 4.12 Load Fail Safe Defaults When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Pressing ‘ Y’ loads the BIOS default v alues for the most stable, minimal-performance system operations. -
Page 76: Load Optimized Defaults
Chapter 4 BIOS Setup 4.13 Load Optimized Defaults When you press <Enter> on this item you get a confirmation dialog box with a message similar to:... -
Page 77: Set Supervisor/ User Password Setting
Chapter 4 BIOS Setup 4.14 Set Supervisor/ User Password Setting These setup pages are used for password setting. When a password has been enabled and the Security Option field is set as Setup, you will be required to enter the password ev ery time you try to enter BIOS Setup program. -
Page 78: Save & Exit Setup/Exit Without Saving
Chapter 4 BIOS Setup The Superv isor Password function will be in effect after you sav e and exit setup. To disable a password, bring the cursor to this field, then press <Enter>. The computer will display the message, “ Enter Password”... -
Page 79: On Board Audio
Chapter 5 On board Audio 5 On board Audio The on board 4.1 channel PCI Audio on Iwill motherboards offer a new generation PCI audio solution: it utilizes the state-of-the-art CRL® 3D Audio technology (HRTF 3D positional audio), and supports Microsoft® Direct Sound ® 3D and Aureal®’ s A3D®... -
Page 80: Driver Installation
Chapter 5 On board Audio 5.1.2 Stereo Mixer and FM Music Synthesizer Stereo analog mixing from CD-Audio, Line-in Stereo digital mixing from Voice, FM/Wav e-table, Digital CD- Audio Mono mixing from MIC and software adjustable v olume OPL3 FM synthesizer (4 operators) Up to 15 melody sounds and 5 rhythm sounds (20 v oices) 5.1.3 Game and Midi Interface Fully compatible with MPU-401 Midi UART and Sound... - Page 81 PCI sound dev ice driv er. STEP 1 Power off your system, install the audio cable, speaker, microphone, and insert the Iwill Power Installer CD into the CD-ROM drive. STEP 2 Turn on the computer, and enter the Microsoft Windows 95 /98 /2000.
- Page 82 Chapter 5 On board Audio 5.2.3 Win 95/98 Un-Installation In the cases you are experiencing some technical difficulties (the sound dev ice is not function properly). It is suggested that you proceed with the un-install procedure: STEP 1 Click start button. STEP 2 Select run item.
- Page 83 Chapter 5 On board Audio 5.2.4 Windows NT4.0 Installation We recommend that you hav e Microsoft Windows NT intalled, and remov e any exsisting sound driv ers from your current system, before you install this PCI sound dev ice driv er. STEP 1 Click "Start"...
-
Page 84: The Audio Rack
Chapter 5 On board Audio 5.3 The Audio Rack 5.3.1 Introduction By means of a user-friendly interface (as easy as operating your home stereo system), this PCI audio rack prov ides you with the control ov er your PC’ s audio functions, including the adv antage of four speakers mode enable/ disable,... - Page 85 Chapter 5 On board Audio 5.3.2About Audio Rack The Audio Rack is consisted of sev eral major components. 5.3.2.1 Control Center Controls the display of the PCI Audio Rack’ s components. 5.3.2.2 MIDI Player Plays MIDI music files, and allows you to create your personal song playlists, and play the song files.
- Page 86 Chapter 5 On board Audio 5.3.4.1 Sel (or Trk) field: If you hav e multiple selections in your playlist, this shows the number of the current selection or CD track. 5.3.4.2 Current File or Track: The name of the current MIDI file, wav e audio file, or CD track.
- Page 87 Chapter 5 On board Audio Mixer panel while the four speakers mode is disabled. 5.3.5.1 Volume Control: Clicking on this button shows and allows you to use the output lev el controls. 5.3.5.2Recording Control: Clicking on this button shows and allows you use the input lev el controls.
- Page 88 Chapter 5 On board Audio cassette player, for instance, while the four speakers mode is enabled, this control becomes the Rear speaker v olume control. c Mic: Controls the microphone input lev el. d Wave: Controls wave (v oice) playback or the recording levels.
-
Page 89: The 4 Speakers System
MP3 player while the loop function enables. 5.3.7 The 4 Speakers System The on board audio on Iwill motherboards prov ide 2 wav e channels (front/rear + subwoffer), known as the 4.1 speakers system. When games or application programs v ia DirectSound®... - Page 90 Chapter 5 On board Audio 5.3.7.3 The mixer setup There is a 4 speakers option in the v olume control of the mixer, and when you enable this option, it means the rear speakers are connected to Line-in/Rear jack. When Line-in/Rear jack is connected to other external Line-in sources, please DO NOT enable this option in order to av oid hardware conflicts.
-
Page 91: Power Installar Cd
Chapter 6 Power Installer CD Power Installer CD 6.1 Software Installation The attached Power Installer CD contains all the necessary drivers, utilities. It prov ides an easy way for users to install the needed driv ers without going through a complicated process. The Power Installer CD is able to auto-detect and display the driv ers, utilities needed for your motherboard. -
Page 92: How To Make Driver Diskette
Chapter 6 Power Installer CD show on the screen. Power Installer does not support a keyboard at this moment. You must use a mouse to install it. 6.2.1 How to view manual This Power Installer CD includes detailed information of all manuals for ev ery motherboard manufactured. -
Page 93: Install Driver
Chapter 6 Power Installer CD STEP 1 First, power-on or boot your system. Press <Del> key during boot sequence to enter STEP 2 CMOS Setup Utility. Use arrow keys to select ADVANCED BIOS STEP 3 FEATURES on the menu, then press Enter. Select First Boot Device and change the default STEP 4 setting to CDROM using Page Up /Page Down... -
Page 94: Install Software Utility
Chapter 6 Power Installer CD You may just click on the Serv ice Pack Driv er shown on screen that needs to be installed, then follow the prompts to complete setup. 6.4.2 How to install Onboard Audio Driver File You may just click on the Onboard Audio Driv er shown on screen that needs to be installed, then follow the prompts to complete setup.
