9. Base
Used for directing the Robomow to the
charging contacts.
10. Cover including the Perimeter Switch
& a Power Supply
Used for recharging the Robomow
Power Pack and activates the perimeter
wire, which defines the area in which
the Robomow will operate.
11. Charging Fence
Used for preventing the Robomow to
climb on the Charging Station during
operation.
12. Charging Stakes (x5)
Used for securing the Charging Station
to the ground.
13. Screws x2
Used for assembling the Charging
Station Cover to the Base.
14. Charging Station wheel supports
(right and left) + 2 screws
Used for supporting Robomow drive
wheels when entering and departing the

Charging Station.

What's in the Box
(Charging Station)
9
10
11
12
13
14
11
