Note: The power supply is suitable for outdoor use, yet it is required placing it in a sheltered place, dry
location, which is well ventilated and not exposed to direct sunlight. It is recommended to place the
Charging Station as close as possible to a receptacle, roll the extra cable and store it near the power
supply. See paragraph 1.15 for further details on the cable.
!
•
It is recommended to place the Charging Station in a shaded place.
•
Place the Charging Station at minimum distances from corners of the perimeter as shown in figure 1.3
•
A minimum distance of 6 feet (2 meters) is required between the Charging Station fence and any
obstacle not excluded with the perimeter wire. See figure 1.3.
•
A minimum distance of 8 feet (2.5 meters) is required between the Charging Station fence and the
perimeter wire. See figure 1.4.
CAUTION! Serious Injury Can Occur! When placing the power
cord leading to the Charging Station insure it is fastened securely
to the ground and does not present a tripping hazard.
Do not cross over surfaces such as sidewalks and driveways
where it cannot be fastened securely.
Figure 1.3 – Distance From Corners and Obstacles
Greater than 8
feet (2.5m)
Figure 1.4 – Distance From Perimeter Wire
Greater than
4 feet (1.2m)
Greater than
8 feet (2.5m)
Greater than
6 feet (2m)
