6.4 Docking Options (for Charging Station only)
Pressing 'GO' at the 'Docking options' display will open the option to scroll between the following
menus (Figure 6.9):

Docking options

Docking options
Press GO Press GO
Figure 6.9

Charging Options

For more details about the 'Time' and 'Weekly program' settings, see chapter 4.1 and 4.2.
6.4.1

Entry Points

'Entry points' are defined as the points, where the mower leaves the Edge and turns into the lawn to
mow the inner area. In order to ensure better area coverage in mowing, the mower has a default of
three different entry points: at the Charging Station, 30% and 60% of the perimeter length. Robomow
uses the 3 default entry points in cyclic mode and it is not possible to set entry point per specific day.
The 'Entry points' option enables to set different entry points from those set by the factory to your
lawn and to set the entry point you want per scheduled day.
Under the 'Entry points' display you can find the following three options (figure 6.10):
Entry Points
Press GO

Set Entry Points

It is possible to set up to four points (includes the Charging Station itself, which is always defined as
entry point number one and cannot be cancelled).
Place the mower in the Charging Station when the Manual Controller in its place and follow the steps
below (Figure 6.12) in order to set the Entry Points:
Press 'GO' Press 'GO'
Weekly program Weekly program
Press GO Press GO
Time: Mo 10:35 Time: Mo 10:35
Press GO Press GO
Entry points Entry points
Press GO Press GO
Auto depart Auto depart
Press GO Press GO
Skip next depart on Skip next depart on
Press GO Press GO
Press 'GO' Press 'GO'
on on
Set entry points
Pres GO to learn
Back to default
Press GO
Entry points on
Press GO
Figure 6.10
57
