Charging Station - Friendly Robotics robomower RL1000 Operation Manual

9. Base
Used for directing the RoboMower to
the charging contacts.
10. Cover including the Perimeter Switch
& a Power Supply
Used for recharging the RoboMower
Power Pack and activates the perimeter
wire, which defines the area in which
the RoboMower will operate.
11. Charging Fence
Used for preventing the RoboMower to
climb on the Charging Station during
operation.
12. Charging Stakes (x5)
Used for securing the Charging Station
to the ground.
13. Screws x2
Used for assembling the Charging
Station Cover to the Base.
14. Charging Station wheel supports
(right and left) + 2 screws
Used for supporting RoboMower drive
wheels when entering and departing the

Charging Station.

What's in the Box
(Charging Station)
9
10
11
12
13
14
11
