  • Page 1 SIMPLY CLEVER ŠKODA Fabia Owner's Manual...
  • Page 2 For the sake of the environment Layout of this Owner's Manual (explanations) An Environmental note draws your attention to environmental protection aspects. This is where you will, for example, find tips aimed at reducing your fuel consump- tion. This Owner's Manual has been systematically designed to make it easy for you to search for and obtain the information you require.
  • Page 3 Preface You have opted for a ŠKODA – our sincere thanks for your confidence in us. You have received a vehicle with the latest technology and range of amenities. Please read this Owner's Manual carefully, because the operation in accordance with these instructions is a prerequisite for proper use of the vehicle.
  • Page 4 The on-board literature The Help on the Road brochure The on-board literature for your vehicle consists of this “Owner's Manual” as well The brochure contains the most important emergency telephone numbers as well as a “Service schedule” and the “Help on the road” brochure. as telephone numbers and contact addresses for ŠKODA Partners in various countries.

  • Page 5: Table Of Contents

    Bicycle carrier in the luggage compartment Safety Table of Contents Roof rack system Useful equipment Passive Safety Storage compartments Abbreviations General information Correct seated position Heating and air conditioning Heating, ventilation, cooling Using the system Seat belts Heating Wearing seat belts Air conditioning system (manual air conditioning Cockpit Inertia reel and belt pretensioners...
  • Page 6 Do-it-yourself Emergency equipment, and self-help Emergency equipment Changing a wheel Tyre repair Jump-starting Towing the vehicle Fuses and light bulbs Fuses Bulbs Technical data Technical data Vehicle data Index Table of Contents...
  • Page 7 Abbreviations Abbreviation Definition Engine revolutions per minute Anti-lock brake system Automatic gearbox Traction control in g/km discharged quantity of carbon dioxide in grams per driven kilo- meter Diesel particle filter Automatic double clutch gearbox Electronic differential lock Electronic Stability Control Kilowatt, measuring unit for the engine output Manual gearbox Multifunction display...
  • Page 8 Fig. 1 Cockpit Using the system...

  • Page 9: Using The System

    Switch depending on equipment fitted: Using the system › Boot lid remote release › Interior monitor Light switch and headlamp beam adjustment 40, 41 Cockpit Fuse box in the dashboard Bonnet release lever Lever for adjusting the steering wheel Overview Ignition lock Pedals Door opening lever on the driver's side...

  • Page 10: Instruments And Indicator Lights

    Overview Instruments and Indicator Lights Instrument cluster  Introduction This chapter contains information on the following subjects: Overview Engine revolutions counter Speedometer Coolant temperature gauge display Fuel gauge Counter for distance driven Service Interval Display Fig. 2 Instrument cluster Digital clock ...

  • Page 11: Engine Revolutions Counter

    Button for: Coolant temperature gauge display › Reset trip counter for the distance driven › Set hours/minutes  First read and observe the introductory information and safety warn- › Activate/deactivate display mode ings on page 8. Fuel gauge » page 9 ...

  • Page 12: Counter For Distance Driven

    Note Service Interval Display On some vehicles, the fuel gauge is shown in the display of the instrument clus- ter. Fig. 3  Service Interval Display: Note Counter for distance driven  First read and observe the introductory information and safety warn- ings on page 8.

  • Page 13: Multifunction Display (Onboard Computer)

    As soon as the due date for the service is reached, a flashing key symbol  and Recommended gear the text INSPEC_ appears in the display for around 20 seconds after the ignition has been switched on. Fig. 4 The following is displayed in the information display: Recommended gear Inspection now! Displaying the distance and days until the next service interval...

  • Page 14: Warning

     Multifunction display details First read and observe the introductory information and safety warn- ings on page 11. Warning against excessive speeds The multifunction display can only be operated when the ignition is switched on. The multifunction display is equipped with two automatic memories. The selected After the ignition is switched on, the function displayed is the one which you last memory is shown in the Display »...
  • Page 15 Operation Multifunction display details  First read and observe the introductory information and safety warn- Fig. 6 ings on page 11. Multifunction display: Control el- ements Outside temperature The current outside temperature is shown in the display. If the outdoor temperature is below +4 °C, the temperature display appears with the snowflake symbol (ice warning).
  • Page 16 If you wish to determine the average fuel consumption over a certain period of Oil temperature time, you must set the memory at the start of the new measurement to zero us- If the oil temperature is lower than 50 °C or if a fault in the system for checking ing the button »...

  • Page 17: Maxi Dot (Information Display)

    › Individual menu items can be selected by means of the rocker switch . When MAXI DOT (information display) the pushbutton is briefly pressed, the information you have selected is dis- played.  Introduction The following information can be selected (depending on the equipment installed on the vehicle): This chapter contains information on the following subjects: ■...

  • Page 18: Auto Check Control

    Language Auto Check Control You can set the language for the warning and information texts here.  First read and observe the introductory information and safety warn- MFD displays ings on page 15. Activate or deactivate certain displays of the multifunction display here. Time Vehicle condition The time, time format (12 or 24 hour indicator) and the changeover between sum-...

  • Page 19: Warning Lights

    Airbag system  WARNING Tyre pressure  If you have to stop for technical reasons, park the vehicle at a safe distance Windscreen washer fluid level  from the traffic, switch off the engine and activate the hazard warning light Traction control (ASR) switched off ...

  • Page 20: Braking System

    Further information » page 127.  Braking system   First read and observe the introductory information and safety warn- Alternator  ings on page 17.  First read and observe the introductory information and safety warn- The warning light illuminates if the brake fluid level is too low or there is a ...

  • Page 21: Engine Oil

    WARNING Engine oil   If you have to stop for technical reasons, then park the vehicle at a safe dis-  First read and observe the introductory information and safety warn- tance from the traffic, switch off the engine and activate the hazard warning ings on page 17.

  • Page 22: If You Have To Stop For Technical Reasons, Park The Vehicle At A Safe Distance From The Traffic, Switch Off The Engine And Activate The Hazard Warning Light System » Page

    WARNING Electronic Stability Control (ESC)  If you have to stop for technical reasons, park the vehicle at a safe distance  ■ First read and observe the introductory information and safety warn- from the traffic, switch off the engine and activate the hazard warning light ings on page 17.

  • Page 23: Antilock Brake System (Abs)

    The following is displayed in the information display: Rear fog light  Error: Traction control (TCS)  First read and observe the introductory information and safety warn- Seek help from a specialist garage. ings on page 17. The fact that the TCS system operates together with the ABS means that the TCS The warning light comes on when the rear fog lights are operating »...

  • Page 24: Glow Plug System (Diesel Engine)

    The warning light only goes out after the diesel particulate filter has been  Glow plug system (diesel engine)  successfully cleaned.  First read and observe the introductory information and safety warn- If the filter is not properly cleaned, the warning light does not go out and the ...

  • Page 25: Fuel Reserve

    WARNING Fuel reserve  If there is a fault, have the airbag system checked immediately by a specialist  First read and observe the introductory information and safety warn- garage. Otherwise, there is a risk of the airbag not being activated in the ings on page 17.

  • Page 26: Traction Control (Asr) Switched Off

    Traction control (ASR) switched off Speed regulating system     First read and observe the introductory information and safety warn- First read and observe the introductory information and safety warn- ings on page 17. ings on page 17. The ASR is switched off by pressing the button »...

  • Page 27: Unlocking And Locking

    WARNING Unlocking and locking Always withdraw the key whenever you leave the vehicle - even if it is only ■ for a short time. This is particularly important if children are left in the vehicle. Unlocking and locking The children might otherwise start the engine or operate electrical equipment (e.g.

  • Page 28: Replacing The Battery In The Remote Control Key

    Note Replacing the battery in the remote control key The system has to be synchronised, if the vehicle cannot be unlocked or locked ■ with the remote control key after replacing the battery » page Replacing the battery in the key a glued decorative cover requires the cover to ■...

  • Page 29: Opening/Closing The Door

     First read and observe the introductory information given on page 25. Opening/closing the door When you unlock/lock the door, the respective securing knob » Fig. 12 will move upwards or downwards. Unlocking from the outside › Unlock the front door with the key »...

  • Page 30: Central Locking System

    When using central locking or unlocking, all doors are locked or unlocked simulta- Emergency locking of the doors neously. The boot lid is unlocked when opening. It can be opened by pressing the handle above the licence plate » page 34, Opening/closing.

  • Page 31: Individual Settings

    gins to flash evenly at longer intervals. It is not possible to open the doors with Note the door handle either from the inside or from the outside. This acts as an effec- tive deterrent for attempts to break into your vehicle. In the event of an accident in which the airbags are deployed, the locked doors ■...
  • Page 32 Unlocking the vehicle using the key Locking the vehicle with the key  First read and observe the introductory information and safety warn- Fig. 14 ings on page 28. Turning the key for unlocking › and locking the vehicle Turn the key in the locking cylinder of the driver's door in the opposite direction of travel (lock position) »...

  • Page 33: Remote Control

    Unlocking all doors and the boot lid Note › Press the button in the area  » Fig. 15. The symbol  in the button is no lon- ger illuminated. The remote control is automatically deactivated when the ignition is switched ■...

  • Page 34: Anti-Theft Alarm System

    Folding in the key bit Synchronization › Press the button » Fig. 16 and fold in the key bit.  First read and observe the introductory information given on page 31. Unlocking The turn signal lights flash twice as confirmation that the vehicle has been un- locked.

  • Page 35: Interior Monitor And Towing Protection

    Operation Interior monitor and towing protection  First read and observe the introductory information given on page 32. Fig. 17 Button for interior monitor and towing protection How is the alarm system activated? The anti-theft alarm system is activated when the vehicle is locked with the radio remote control or the key in the driver's door .

  • Page 36: Tailgate

    Tailgate Opening/closing  Introduction This chapter contains information on the following subjects: Opening/closing Automatic locking Emergency unlocking WARNING Ensure that the lock is properly engaged after closing the boot lid. Other- ■ Fig. 18 Unlock the boot lid/boot lid handle wise, the tailgate might open suddenly while the vehicle is moving if it was locked –...

  • Page 37: Electrical Power Windows

    Delayed locking Electrical power windows It is possible to open the tailgate within a limited period of it being closed if the tailgate was locked with the  button on the remote control key.  Introduction There is a risk of unwanted entry into the vehicle before the boot lid is locked au- tomatically.

  • Page 38: First Read And Observe The Introductory Information And Safety Warn

    The window will also close fully automatically if you briefly pull the button as far Note as the stop. Renewed pulling of the button causes the window to stop immedi- ately. After switching the ignition off, it is still possible to open or close the windows ■...

  • Page 39: Electric Sliding/Tilting Roof

    If you attempt to close the window again within 10 seconds of the window being Operation in winter moved down for the second time, even though the obstacle was not yet been re- In the winter, ice on the window may cause greater resistance as the window is moved, the closing process is only stopped.

  • Page 40: Fig. 21

    Operation Comfort operation  First read and observe the introductory information and safety warn- Fig. 21 ings on page 37. Control dial for the power slid- ing/tilting roof An open sliding/tilting roof can also be closed from the outside. › Press and hold the ...
  • Page 41 › Carefully fold the glasses storage box downwards by gently pressing down and turning the screwdriver. › Insert an Allen key, SW 4, up to the stop into the opening and close or open the sliding/tilting roof. › Reinstall the glasses storage box by first inserting the plastic plugs and then pushing the entire part upwards.

  • Page 42: Lights And Visibility

    Note Lights and visibility An audible warning signal will sound if the light switch is in the  or  posi- ■ tion, the ignition key is removed and the driver's door is opened. The audible Lights warning signal is switched off by means of the door contact when the driver's door is closed (ignition off), however, the side lights remain on to illuminate the parked vehicle if necessary.

  • Page 43: Headlight Beam Adjustment

    Headlight beam adjustment DAY LIGHT function (daytime running lights)  First read and observe the introductory information and safety warn- Fig. 24 ings on page 40. Dash panel: Lights and visibility Switching on the daytime running lights › Turn the light switch to the O position »...

  • Page 44: Turn Signals And Main Beam Light

    Note Turn signals and main beam light The turn signal system only operates when the ignition is switched on. The cor- ■ Fig. 25 responding warning light in the instrument cluster also flashes.   The turn signal is automatically cancelled after negotiating a curve. Stalk: turn signal and main beam ■...

  • Page 45: Fog Lights

    Fog lights Rear fog light  First read and observe the introductory information and safety warn- Fig. 26 ings on page 40. Dash panel: Light switch Switching on › First of all, turn the light switch » Fig. 26 on page 43 to position  or . ›...

  • Page 46: Hazard Warning Light System

    ›  Engage reverse gear (manual gearbox) or move the selector lever into the posi- First read and observe the introductory information and safety warn- tion R (automatic gearbox), ings on page 40. › Turn the control dial for headlamp beam adjustment from the position - to the ›...

  • Page 47: Interior Lights

    If operation of the lights by the door contact switch is enabled (switch Interior lights » Fig. 28 is in the  position), the light will come on when: › the vehicle is unlocked; ›  one of the doors is opened; Introduction ›...

  • Page 48: Visibility

    Visibility Rear interior light  Introduction Fig. 30 Interior lights at the rear This chapter contains information on the following subjects: Rear window heating Sun visors  Rear window heating  First read and observe the introductory information given on page 45. Fig.

  • Page 49: Windscreen Wipers And Washers

    The windshield wipers and the windshield washer system only operate if the igni- Sun visors tion is switched on. The rear window is wiped once if the windscreen wipers are on when reverse Fig. 32 gear is selected. Sun visor: swivelling out Top up with windscreen wiper fluid »...

  • Page 50: Windscreen Wiper And Washer

    › Release the stalk. The washer system stops and the wiper continues for anoth- Windscreen wiper and washer er 1 to 3 wiper strokes (depending on the duration of the spraying process). The lever will stay in position after releasing it Fig.

  • Page 51: Rear Window

    Replacing the windscreen wiper blades Replacing the rear window wiper blade Fig. 34 Fig. 35 Windscreen wiper blade Rear window wiper blade   First read and observe the introductory information and safety warn- First read and observe the introductory information and safety warn- ings on page 47.

  • Page 52: Exterior Mirrors

    Manually dimmed rear-view mirror Exterior mirrors  First read and observe the introductory information given on page 49. Fig. 37 Inner part of door: Rotary knob Basic setting › Pull the lever on the bottom edge of the mirror forward. Dimming mirror ›...
  • Page 53 Note Do not touch the surface of the exterior mirrors if the exterior mirror heater is ■ switched on. If the power setting function fails at any time, the exterior mirrors can be set by ■ hand by pressing on the edge of the mirror surface. Contact your specialist garage if there is a fault with the electrical adjustment ■...

  • Page 54: Seats And Storage

    WARNING Seats and storage As the driver, you must observe the following instructions. Only adjust the driver's seat when the vehicle is stationary – there is the risk ■ Front seats of an accident. Keep a distance of at least 25 cm from the steering wheel. Not keeping to ■...

  • Page 55: Adjusting A Seat In A Forward/Back Direction

     First read and observe the introductory information and safety warn- Adjusting the front seats - Version 1 ings on page 52. Adjusting a seat in a forward/back direction Fig. 38 › Pull the lever (in the middle area) » Fig. 39 up and push the seat into the de- Control elements at the seat sired position.

  • Page 56: Rear Seats

    WARNING Folding the seat backrest forwards If, as an occupant, you have a subdued pain and/or temperature sensitivity, e.g. through medication, paralysis or because of chronic illness (e.g. diabetes), Fig. 41 we recommend not to use the seat heating. This can lead to burns on the Unlock the seat backrest back, the posterior and the legs which are difficult to heal.

  • Page 57: Head Restraints

    Install CAUTION › Press the wire clamp in the direction of the arrow » Fig. 42 -  and put it into the holder. Ensure that the seat belts are not damaged when operating the seat backrests. › Fold the seat cushion back into its original position. Under no circumstances must the rear seat belts be jammed by the folded back ...

  • Page 58: Boot

    › Press the locking button in direction of the arrow » Fig. 43 -  and pull the head Boot restraint out. › To re-insert the head restraint, push it far enough down into the seat backrest until the locking button clicks into place. ...

  • Page 59: Class N1 Vehicles

    WARNING Class N1 vehicles Store the objects in the boot and attach them to the lashing eyes.  ■ First read and observe the introductory information and safety warn- Loose objects in the passenger compartment can be thrown forward during ■...

  • Page 60: Folding Hooks

     First read and observe the introductory information and safety warn- Folding hooks ings on page 56. Fixing examples for a fixing net as a horizontal pocket, floor fixing net » Fig. 47 Fig. 46  and a horizontal pocket »...

  • Page 61: Further Positions Of The Luggage Compartment Cover

    › The mounts of the cover » Fig. 48 must be positioned above the holders Further positions of the luggage compartment cover of the side trim panel. › Interlock the cover by lightly knocking on the top side of the cover in the area between the holders.

  • Page 62: Variable Loading Floor In The Luggage Compartment (Estate)

    Variable loading floor in the luggage compartment Foldable boot cover (Combi) (Estate)  Introduction This chapter contains information on the following subjects: Dividing up the luggage compartment with variable loading floor Removing and refitting the variable loading floor Removing and installing carrier rails The variable loading floor makes handling of bulky items of luggage easier.
  • Page 63 Removing and refitting the variable loading floor Removing and installing carrier rails Fig. 52 Fold up variable loading floor/remove Fig. 53 Slacken check points/remove carrier rails   First read and observe the introductory information and safety warn- First read and observe the introductory information and safety warn- ings on page 60.

  • Page 64: Net Partition (Combi)

     First read and observe the introductory information and safety warn- Net partition (Combi) ings on page 62. Pulling out  Introduction › Open the rear right door. › Fold down the rear seat backrests slightly forwards, which makes it possible to This chapter contains information on the following subjects: clear the access for removing the net partition.

  • Page 65: Bicycle Carrier In The Luggage Compartment

    Using the net partition behind the front seats Removing and refitting the net partition housing Fig. 56 Rear seats: Net partition hous-  First read and observe the introductory information and safety warn- Fig. 55 Pull out the net partition/roll up ings on page 62.
  • Page 66 WARNING Install bicycle carrier When transporting bicycles, ensuring the safety of the passengers is para- mount. Fig. 58 Install bicycle carrier CAUTION Take care handling the bicycle - there is a risk of damaging the vehicle.  Install cross member Fig.

  • Page 67: Roof Rack System

    Put bicycle into the bicycle carrier Secure the stability of the bicycles with a belt Fig. 59 Put in the bicycle/example fastening the front wheel Fig. 60 Securing bicycles   First read and observe the introductory information and safety warn- First read and observe the introductory information and safety warn- ings on page 63.
  • Page 68 WARNING Note The items being transported on the roof rack must be reliably attached – If the vehicle is not factory-equipped with a roof rack, it can be purchased from ■ there is the risk of an accident. the ŠKODA Original Accessories. ...

  • Page 69: Useful Equipment

    CAUTION Useful equipment Do not leave open beverage containers in the cup holder during the journey.  Introduction There is a risk of spilling e.g. when braking which may cause damage to the elec- trical components or seat upholstery.  This chapter contains information on the following subjects: Cupholders Ashtray...

  • Page 70: Cigarette Lighter

    Cigarette lighter 12-volt power outlet Fig. 64 Fig. 65 Centre console: Cigarette lighter Boot: Power socket   First read and observe the introductory information given on page 67. First read and observe the introductory information given on page 67. Operating the cigarette lighter Overview of the 12-volt power socket ›...

  • Page 71: Storage Compartments

    Connecting electrical components when the engine is not running will drain the ■ Car park ticket holder battery of the vehicle – there is a risk of the battery discharging. Only use matching plugs to avoid damaging the 12-volt power socket. ■...

  • Page 72: Storage Compartments On The Front Passenger Side

    WARNING Cooling the storage compartment on the front passenger side Do not place anything on the dash panel. These objects might slide or fall ■ down when driving (when accelerating or cornering) and may distract you Fig. 68 from concentrating on the traffic – there is the risk of an accident. Storage compartment: Using When driving, ensure that no objects from the centre console or from other cooling system...

  • Page 73: Storage Compartment On The Driver's Side

    CAUTION Storage compartment on the driver's side Do not put any large items such as bottles or sharp objects into the map pockets, Fig. 69 as the pockets and the seat covers could be damaged.  Dash panel: Storage compart- ment on the driver's side Glasses storage box Fig.

  • Page 74: Stowage Compartment In Centre Console

    CAUTION Stowage compartment in centre console The storage compartment is designed for storing small objects of up to 1 kg. in Fig. 72 weight.  Centre console: Stowage com- partment Front armrest with storage compartment  First read and observe the introductory information and safety warn- ings on page 69.

  • Page 75: Storage Compartments In The Doors

     First read and observe the introductory information and safety warn- Storage compartments in the doors ings on page 69. The cover for the side compartment can be removed, thus enlarging the boot. › Grasp the top part of the cover and carefully remove it in the direction of the arrow »...
  • Page 76 CAUTION The storage compartment is designed for storing small objects with a maximum total weight of 8 kg. Note If the variable loading floor » page 60 is installed in the luggage compartment, no flexible storage compartment can be installed. ...

  • Page 77: Heating And Air Conditioning

    Note Heating and air conditioning The used air streams out through the vents in the boot. ■ We recommend that you do not smoke in the vehicle when the recirculating air ■ Heating, ventilation, cooling mode is operating since the smoke which is drawn at the evaporator from the in- terior of the vehicle forms deposits in the evaporator of the air conditioning sys- tem.

  • Page 78: Heating

    Change air flow of air outlet vents 3 and 4 Operational problems › In order to change the strength of the air flow, swivel the horizontal lamellas with the aid of the moveable adjuster » Fig.  First read and observe the introductory information and safety warn- ›...
  • Page 79 › Turn the control dial to the left to decrease the temperature. Operation Controlling blower › Turn the blower switch » Fig. 79 into one of the positions, 1 to 4, to switch the blower on. › Turn the blower switch into position 0 to switch the blower off.

  • Page 80: Air Conditioning System

    Control dial setting Set-up Button Air outlet vents 4    Comfortable heating Desired temperature 2 or 3 Do not switch on Opening To the left up to the  Fresh air mode - ventilation Desired position Do not switch on Opening stop Note...
  • Page 81 Note Operation The whole heat output will be needed to defrost the windscreen and side win- ■ dows. No warm air will be fed to the footwell. This can lead to restriction of the heating comfort. The warning light in the button lights up after activation, even if not all of ■...
  • Page 82 Setting the air conditioning system  First read and observe the introductory information given on page 78. Recommended basic settings of the control elements of the air conditioning sys- tem for the respective operating modes: Control dial setting » Fig. 80 on page 79 Button »...

  • Page 83: Overview Of The Controls

    Switching between Celsius and Fahrenheit WARNING Press and hold the buttons » Fig. 81 on page 81 at the same time. AUTO The information in the desired temperature measuring unit appears in the display. Do not leave recirculated air mode on over a longer period of time, as “stale” air can cause fatigue of the driver and passengers, reduce attention levels and Note also cause the windows to mist up.

  • Page 84: Automatic Mode

    Cooling system on/off Setting the temperature Set blower speed  First read and observe the introductory information given on page 81. The buttons/control dial Setting the blower speed › The required interior temperature can be set with the control dial »...

  • Page 85: Controlling Blower

    Note If recirculated air mode is switched on for around 15 minutes, the symbol  will begin to flash in the display as a sign that the recirculated air mode is switched on long-term. If the recirculated air mode is not switched off, the symbol flashes for around 5 minutes.

  • Page 86: Communication And Multimedia

    WARNING Communication and multimedia Concentrate fully at all times on your driving! As the driver you are fully re- ■ sponsible for road safety. Use the telephone system only to such an extent Universal telephone preinstallation GSM II that you are in full control of your vehicle at any time. The national regulations for using a mobile phone in a vehicle must be ob- ■...
  • Page 87 The universal telephone preinstallation GSM II comprises the following functions. After the first connection of the telephone, the system begins to load the phone › Phone Phonebook » page book from the phone and the SIM card into the memory of the control unit. ›...
  • Page 88 Button/wheel Action Operation Press briefly Accept call, terminate call, entry in the main menu of the telephone, list of selected numbers Press button for a long period Reject call, last number dialled , switch voice control on/off of time Press briefly Switch on/off voice control Turn upwards Increase the volume...

  • Page 89: Connecting Mobile Phone To Hands-Free System

    Some adapters include the button » Fig. 84 in addition to the button Restoring the visibility of the hands-free system  After pressing this button for 2 seconds, the number 112 (Emergency call) is dial- If you have not managed to connect your mobile phone with the hands-free sys- led.
  • Page 90 Call register Symbols in the information display The following menu items can be selected in the Call register menu item.  First read and observe the introductory information given on page 84. Missed calls ■ ■ Dialled numbers Received calls ■...

  • Page 91: Voice Control

    Switching on voice control Voice control › by briefly pressing the button on the adapter» Fig. 84 on page 86,  › by briefly pressing the button on the multi-function steering  wheel » page 85, Operating the phone on the multifunction steering wheel. Introduction Switching off voice control This chapter contains information on the following subjects:...

  • Page 92: Multimedia

    Voice command Action ® Music playback via Bluetooth After this command the system calls the last dialled REDIAL  First read and observe the introductory information given on page 90. number. Play music from the mobile phone or another paired MUSIC device.
  • Page 93 Operating the radio and navigation system on the multifunction steering wheel The radio and navigation system can of course still be operated on the devices. A Fig. 85 description is included in the relevant operating instructions. Multifunction steering wheel: If the side lights are switched on, the buttons on the multifunction steering Control buttons and wheel wheel are illuminated.
  • Page 94 The MDI input is located beneath the storage compartment on the front passen- ger side. The AUX-IN and MDI inputs are used to connect external audio sources (e.g. iPod or mp3 player) and to play back music from these devices via the factory-fitted ra- dio or navigation system.

  • Page 95: Driving

    WARNING (Continued) Driving When driving, the ignition key must always be in the position » Fig. 87 ■ page 95 (ignition switched on) without the engine running. This position is indicated by the warning lights coming on. If this is not the case, it could result Starting-off and Driving in unexpected locking of the steering wheel –...
  • Page 96 Do not tow start the engine – there is a risk of damaging the engine. On vehi- ■ Adjusting the steering wheel position cles with a catalytic converter, unburnt fuel may get into the catalytic converter where it may ignite. This in turn may damage the catalytic converter. The battery from another vehicle can be used as a jump-start aid »...
  • Page 97 To lock the steering, with the ignition key withdrawn, turn the steering wheel Electronic immobiliser until the steering locking pin engages audibly.  First read and observe the introductory information and safety warn- If the steering is locked and the key cannot or can only be turned with difficulty ings on page 93.

  • Page 98: Braking

    Note Braking If the brakes are applied in full and the control unit for the braking system con- ■  Introduction siders the situation to be dangerous for the following traffic, the brake light flashes automatically. After the speed was reduced below around 10 km/h or the This chapter contains information on the following subjects: vehicle was stopped, the brake light stops flashing and the hazard warning light system switches on.

  • Page 99: Manual Gear Shifting And Pedals

    Low brake fluid level Manual gear shifting and pedals An insufficient level of brake fluid may result in problems in the brake system. The level of the brake fluid is monitored electronically » page Braking system.   Introduction Brake booster The brake booster increases the pressure generated with the brake pedal.

  • Page 100: Automatic Gearbox

    Note WARNING If not in the process of changing gear, do not leave your hand on the gearshift Do not depress the accelerator if changing the position of the selector lever ■ lever while driving. The pressure from the hand can cause the gearshift mecha- when the vehicle is stationary and the engine is running - risk of accident! nism to wear excessively.

  • Page 101: Introductory Information

    Stop Introductory information › The selector lever position N does not have to be selected when stopping for a short time, such as at a cross roads. It is sufficient to hold the vehicle stationary  First read and observe the introductory information and safety warn- using the foot brake.

  • Page 102: Manual Shifting Of Gears (Tiptronic)

    If the battery is used, the selector lever cannot be moved out of the position P. Manual shifting of gears (Tiptronic) - Reverse gear Reverse gear must only be engaged when the vehicle is stationary and the en- gine is idling. The brake pedal must be depressed and at the same time the Shiftlock must be pressed, if you wish to obtain the selector lever positions R, P or N.

  • Page 103: Selector Lever Lock

    When accelerating, the gearbox automatically shifts up into the higher gear just Ignition key withdrawal lock before the maximum permissible engine speed is reached. After the ignition is switched off, the ignition key can only be withdrawn if the se- lector lever is in the position P.

  • Page 104: Running In

    Selecting the most appropriate driving programme for the particular style of driv- Selector lever-emergency unlocking ing is a continuous process. Irrespective of this it is, however, possible to switch or shift down into a dynamic shift programme by depressing the accelerator rap- idly.

  • Page 105: Economical Driving And Respect The Environment

    For the sake of the environment New engine Not driving at unnecessarily high engine revolutions and shifting to a higher gear  First read and observe the introductory information given on page 102. as early as possible are ways to minimise fuel consumption and operating noise levels and protects the environment.

  • Page 106: Driving With Anticipation

    The technical requirements for low fuel usage and economic efficiency of the ve- Shifting to save energy hicle have already been built into the vehicle at the works. ŠKODA places a partic- ular emphasis on minimising negative effects on the environment. Fig.

  • Page 107: Avoiding Full Throttle

    If an engine is only idling it takes much longer for it to reach its normal operating Avoiding full throttle temperature. Wear-and-tear and pollutant emissions, though, are particularly high in the warming-up phase. Therefore, start driving as soon as the engine has started, whereby high engine speeds should be avoided.

  • Page 108: Avoid Short Distances

    Avoid short distances Avoid unnecessary ballast  First read and observe the introductory information given on page 103. Fig. 95 Principle sketch: Fuel consump- tion in l/100 km at different tem- Transporting ballast costs fuel. peratures Each kilogramme of weight increases the fuel consumption. It is worth checking the boot to avoid transporting any unnecessary ballast.

  • Page 109: Avoiding Damage To Your Vehicle

    › Reduced fuel consumption and exhaust emission CO Avoiding damage to your vehicle › Minimum fuel leakage during accidents. › Reduced noise.  Introduction Choice of materials › Extensive use of recyclable material. This chapter contains information on the following subjects: ›...

  • Page 110: Driving Abroad

    CAUTION Fords on roads When driving through bodies of water, parts of the vehicle such as the engine, ■ Fig. 96 gearbox, chassis or electrics can be severely damaged. Oncoming vehicles can generate water waves which can exceed the permissible Driving through water ■...
  • Page 111 Headlights  First read and observe the introductory information given on page 108. The low beam of your headlights is set asymmetrically. It illuminates the side of the road on which the vehicle is being driven to a greater extent. When driving in countries in which the traffic drives on the other side of the road than in your home country, the asymmetrical low beam may dazzle oncoming drivers.

  • Page 112: Assist Systems

    Stabilisation control (ESC) Assist systems  First read and observe the introductory information and safety warn- ings on page 110. Brake assist systems The ESC system helps to maintain control of the vehicle in situations where it is  being operated at its dynamic limits, such as a sudden change to the direction of Introduction travel.
  • Page 113  Hill hold control (HHC) First read and observe the introductory information and safety warn- HHC allows you to move your foot from the brake pedal to the accelerator pedal ings on page 110. without having to use the handbrake when pulling away on a gradient. If the wheels are slipping, the ASR system adapts the engine speed to the condi- The system holds the brake pressure produced by the activation of the brake tions of the road surface.

  • Page 114: Parking Aid

    XDL function (Fabia RS and Fabia Estate RS only) Note XDL is an extension to the electronic differential lock. XDL does not respond to traction, but to the relief of the inner front wheel during fast cornering. The active Additionally fitted modules, such as a bicycle rack, can impair the function of the ■...

  • Page 115: Cruise Control System

    Activating/deactivating the parking aid CAUTION The parking aid is activated automatically when reverse gear is engaged and the ignition is turned on. This is confirmed by a brief audible signal. The cruise control system is not able to maintain a constant speed when driving ■...

  • Page 116: Start/Stop

    Briefly press the rocker button into the position RES to resume the stored Changing a stored speed speed after the clutch or brake pedal is released.   First read and observe the introductory information and safety warn- ings on page 113. Switching off the cruise control system completely Increasing the speed with the accelerator ...

  • Page 117: Operating Principle

    The START-STOP system is very complex. Some of the procedures are hard to Operating principle check without servicing. The general conditions for the proper functioning of the START-STOP system are listed in the following overview. Fig. 100 Conditions that must be met in full for automatic engine stop (stop phase) Centre console: Button for the ›...
  • Page 118 If the driver's seat belt is removed for more than 30 seconds or the driver's door is opened during stop mode, the engine must be started manually with the key. The following messages in the instrument cluster display must be observed. Messages in the instrument cluster display (valid for vehicles without Information display) ERROR START-STOP...

  • Page 119: Towing A Trailer

    Description Towing a trailer Towing device  Introduction This chapter contains information on the following subjects: Description Adjusting the ready position Fitting the ball head Check proper fitting Fig. 101 Remove cap: on the rear bumper/for the mounting recess Removing the ball head Use and care Fig.
  • Page 120 Lock cap Fitting the ball head Release pin Locking ball Note The tool for removing the wheel trim is part of the vehicle tool kit » page 176 ■ If you lose the key, please get in touch with a specialist garage. ■...
  • Page 121 Check the following points. WARNING The lever is at the top » Fig. 105.  Carefully remove the cap for the mounting recess - there is a risk of hand ■ The release pin is completely exposed (both its red and green parts are ...

  • Page 122: Trailer

    The ball head is released in this position and falls freely into the hand. If it does Always check the ball head before hitching a trailer. Apply a suitable grease not fall freely into the hand, use your other hand to push it upwards. where necessary.
  • Page 123 The distribution of the weight is very poor if your vehicle is unladen and the trail- Headlights er is laden. Maintain a particularly low speed if you cannot avoid driving with this The front of the vehicle can be lifted when a trailer is being towed and the head- combination.
  • Page 124 Note After coupling the trailer and connecting up the power socket, check the rear ■ lights on the trailer to ensure they work. If there is an error in the trailer lighting system, check the fuses in the fuse box ■...

  • Page 125: Safety

    › Front airbag for the driver and the front passenger. Safety › Front side airbags. › Head airbags. › Anchoring points for child seats using the ISOFIX system. › Passive Safety Anchoring points for child seats using the TOP TETHER system. ›...

  • Page 126: Correct Seated Position

    WARNING What influences driving safety? As the driver, you must observe the following instructions.  First read and observe the introductory information and safety warn- Always assume the correct seated position before setting off and do not ■ ings on page 123. change this position while driving.
  • Page 127 Correct seated position of the driver Correct seated position of the front passenger  First read and observe the introductory information and safety warn- ings on page 124. For the safety of the front passenger and to reduce the risk of injury in the event of an accident, we recommend the following setting.
  • Page 128 Incorrect seated positions considerably reduce the protective functions of the seat belts and therefore increase the risk of injury due to an incorrect routing of the seat belt. The driver is fully responsible for himself and passengers, especially children. Never allow a passenger to adopt an incorrect seated position when the car is moving.

  • Page 129: Seat Belts

    Particular safety aspects must be observed when transporting children in the ve- Seat belts hicle » page 139, Transporting children safely. WARNING Wearing seat belts Fasten your seat belt before each journey - even when driving in town! This ■ also applies to the people seated at the rear –...
  • Page 130 WARNING The physical principle of a frontal collision Observe the following instructions for the proper use of the seat belts. Never use a seatbelt to secure two persons (not even children). Nor may the ■ seat belt be placed over a child who is sitting on the lap of another passenger. The lock tongue should only be inserted into the lock which is the correct ■...
  • Page 131 › It is also important that rear seat occupants fasten their seat belts as they will Use the lock tongue to slowly pull the webbing over your chest and pelvis. › otherwise be thrown through the vehicle in an uncontrolled manner in the event Insert the lock tongue into the belt buckle »...

  • Page 132: Inertia Reel And Belt Pretensioners

    The seat belt can move freely when it is pulled slowly. The seat belt is locked by Seat belt height adjuster on the front seats the inertia reel when it is pulled suddenly. The belts also lock under full braking, under acceleration, when driving downhill Fig.
  • Page 133 Note Smoke is generated when the belt tensioners are deployed. This is not an indi- ■ cation of a fire in the vehicle. When disposing of the vehicle or parts of the belt tensioner system, it is impor- ■ tant to comply with national legal requirements. ŠKODA Partners are familiar with these regulations and will be able to provide you with detailed information.

  • Page 134: Airbag System

    System description Airbag system  First read and observe the introductory information and safety warn- ings on page 132. Description of the airbag system The functional status of the airbag system is indicated by the indicator light in   the instrument cluster »...

  • Page 135: Airbag Overview

    In certain accident situations, the several airbags may be deployed simultaneous- Airbag overview The airbags are not deployed in the case of minor frontal and side collisions, rear-  Introduction end collisions, tilting of the vehicle and vehicle rollover. Deployment factors This chapter contains information on the following subjects: It is not possible to generally determine which deployment conditions apply to Front airbags...
  • Page 136 WARNING Front airbags Correct seated position For the driver and front passenger, it is important to maintain a distance of ■ at least 25 cm to the steering wheel or dashboard » Fig. 114. Not keeping to this minimum distance will mean that the airbag system will not be able to properly protect you –...
  • Page 137 WARNING (Continued) Side airbags There must not be any further persons, animals as well as objects posi- ■ tioned between the occupants and the deployment area of the airbag. No ac- cessories, such as cup holders, should be attached to the doors. If children adopt an incorrect seated position when travelling, they may be ■...

  • Page 138: Deactivating Airbags

    WARNING Head airbags There must not be any objects in the deployment area of the head airbags ■ which might prevent the airbags from inflating properly. Only hang light items of clothing on the hooks fitted in the vehicle. Never ■...

  • Page 139: Switching Off The Front Passenger Airbag

    Note Deactivating airbags The national regulations for switching off airbags must be observed.  ■ First read and observe the introductory information given on page 136. A ŠKODA Service Partner will be able to inform you which airbags in your vehicle ■...
  • Page 140 WARNING The driver is responsible for whether the airbag is switched on or switched ■ off. Only switch off the airbag when the ignition is switched off! Otherwise a ■ fault can occur in the system for deactivating the airbag. If the warning light flashes, the front passenger airbag will not be de- ■...

  • Page 141: Transporting Children Safely

    WARNING (Continued) Transporting children safely Children are exposed to an increased risk of injury in the event of an acci- ■ dent if they lean forward or adopt an incorrect seated position during the Child seat journey This particularly applies to children who are transported on the front passenger seat as they can suffer severe, or even fatal injuries if the airbag system is deployed! ...
  • Page 142 WARNING Use of a child seat on the front passenger seat It is essential to switch off the front passenger airbag if you are using a child ■ Never use a rearward-facing child restraint system on a seat which is protected seat on the front passenger seat in which the child is carried with its back fac- by an active airbag installed in front of it.
  • Page 143 Group Weight of the child Approximate age Child safety and side airbag up to 10 kg up to 9 months up to 13 kg up to 18 months 9-18 kg up to 4 years 15-25 kg up to 7 years 22-36 kg over 7 years ...

  • Page 144: Fastening Systems

     First read and observe the introductory information given on page 142. Fastening systems There are two locking eyes between the rear exterior seats for fixing the ISOFIX  Introduction system child seat in place. This chapter contains information on the following subjects: The places are marked with labels with the ISOFIX logo »...
  • Page 145 Size category Group Front passenger seat Outer rear seats Rear seat middle of the child seat IL-SU 9-18 kg The size category is shown on the label attached to the child seat. If the front passenger seat is fitted with the ISOFIX system attachment points, it is suited for the installation of an ISOFIX child seat with the “Semi-Universal” approval. IL-SU The seat is suited for installation of an ISOFIX child seat with the “Semi- WARNING...

  • Page 146: General Maintenance

    CAUTION General Maintenance Do not wash your vehicle in bright sunlight – there is a risk of paint damage. Taking care of and cleaning the vehicle For the sake of the environment Only wash the vehicle at washing bays intended for this purpose. ...

  • Page 147: Vehicle Exterior Care

    If your vehicle is fitted with any particular mounted parts, such as a spoiler, roof Vehicle exterior care rack, two-way radio aerial – it is best to consult the operator of the car wash sys- tem beforehand.  Introduction The lips of the windscreen wiper rubbers must be cleaned and degreased with cleaning agents especially formulated for the task after an automatic wash with This chapter contains information on the following subjects: wax.

  • Page 148: Caring For Vehicle Paintwork

    Do not polish the paintwork in a dusty environment - there is a risk of scratch- ■ For the sake of the environment ing the paintwork. Do not apply polish to door seals or window guides. Used cans of vehicle care products should be treated as special hazardous waste. ■...

  • Page 149: Decorative Films

    If this method does not completely clean chrome parts, use a specific chrome care When drying the windows after washing the vehicle, do not use window leathers product. that have been used to polish the bodywork. Residues of preservatives in the chamois leather can smear the windows and reduce visibility.

  • Page 150: Care Of The Interior

    CAUTION CAUTION When washing your vehicle, ensure as little water as possible gets into the lock- Severe layers of dirt on the wheels can also result in wheel imbalance. This may ing cylinders. show itself in the form of a wheel vibration which is transmitted to the steering ...

  • Page 151: Dren - There Is A Risk Of Poisoning

    We recommend using care products from ŠKODA Original Accessories that are Natural leather available from ŠKODA Partners. The instructions for use on the package must be observed.  First read and observe the introductory information and safety warn- ings on page 148. WARNING Leather is a natural material with specific properties and requires regular cleaning Care products may be harmful to your health if not used according to the in-...

  • Page 152: Seat Covers

    Use a care cream with light blocker and impregnation effect on a regular basis ■ CAUTION and each time after cleaning. The cream nourishes the leather, allows it to breathe and keeps it supple and also provides moisture. It also creates surface Avoid leaving the vehicle for lengthy periods in bright sunlight to prevent the ■...

  • Page 153: Modifications, Repairs And Technical Changes

    You should always consult a ŠKODA Partner » page 152 before buying accesso- Seat belts ries, parts or before making any modifications, repairs or technical changes to your vehicle.  First read and observe the introductory information and safety warn- ings on page 148.
  • Page 154 ŠKODA Service Partners Airbags   First read and observe the introductory information and safety warn- First read and observe the introductory information and safety warn- ings on page 151. ings on page 151. ŠKODA Service Partners are equipped with modern, specially developed tools and The system components for the airbag system may be found in the front bumper, equipment.

  • Page 155: Inspecting And Replenishing

    Refuelling Inspecting and replenishing Fuel  Introduction This chapter contains information on the following subjects: Refuelling Unleaded petrol Diesel fuel Fig. 122 Right rear side of the vehicle: Fuel filler flap/fuel filler flap with cap The correct grades of fuel for your vehicle are stated on a sticker affixed to the unscrewed inside of the fuel filler flap »...

  • Page 156: Diesel Fuel

    Even in the event of an emergency, petrol of a lower octane number than 91 RON Note must not be used, otherwise the engine can be severely damaged! The fuel tank has a capacity of about 45 litres, containing a reserve of approx. Fuel additives 7 litres.

  • Page 157: Engine Compartment

    Operation in winter - Winter-grade diesel fuel Radiator fan In the cold season, only use “winter-grade diesel fuel” which will still operate Windscreen washer system properly even at a temperature of -20 °C. WARNING It is often the case in countries with different climatic conditions that diesel fuels available have a different temperature characteristic.
  • Page 158 WARNING (Continued) WARNING (Continued) If any coolant splashes into your eyes, immediately rinse out your eyes with If you wish to work under the vehicle, you must secure the vehicle against ■ ■ clear water and contact a doctor as soon as possible. rolling away and support it with suitable axle stands: the car jack is not suffi- Always safely store the coolant additive in its original container out of the cient for this –...
  • Page 159 Closing Opening and closing the bonnet › Lift the bonnet slightly and unhook the bonnet support. Press the bonnet sup- port into the holder designed to hold it. › Let the bonnet drop into the lock carrier lock from a height of around 20 cm – do not push it in.

  • Page 160: Engine Oil

    Under exceptional circumstances, methylated spirits can also be used if no screen Radiator fan cleaner with antifreeze is available. The concentration of methylated spirits must not be more than 15 %. The freeze protection at this concentration is sufficient  First read and observe the introductory information and safety warn- only to -5 °C.
  • Page 161 The oil capacities include oil filter change. Check the oil level when filling; do not Diesel engines Specification Capacity over fill. The oil level must be between the markings » page 160. 1.2 ltr./55 kW TDI CR DPF VW 507 00 1.6 ltr./55 kW TDI CR DPF VW 507 00 WARNING...
  • Page 162 One should therefore check the oil level at regular intervals, preferably every time Checking the oil level after the fuel tank is filled or after driving for long stretches. We recommend maintaining the oil level within the range , but not above, if Fig.

  • Page 163: Coolant

    WARNING Changing The engine compartment of your car is a hazardous area. While working in  ■ First read and observe the introductory information and safety warn- the engine compartment, be sure to observe the following warn- ings on page 158. ings »...

  • Page 164: Brake Fluid

    Loss of coolant Petrol engines Capacities (in litres) A loss of coolant is first and foremost an indication of a leak in the system. Do 1.4 ltr./132 kW TSI not merely top up the coolant. Have the cooling system checked by a specialist 1.6 ltr./77 kW garage immediately.

  • Page 165: Vehicle Battery

    There may be an indication of a leak in the brake system, however, if the fluid lev- WARNING el drops significantly within a short time or if it drops below the “MIN” marking. If the brake fluid level is too low, this is indicated by the warning light lighting up The engine compartment of your car is a hazardous area.
  • Page 166 Warning symbols on the vehicle battery WARNING (Continued) Symbol Importance If any battery electrolyte comes into contact with your eyes, rinse the eyes ■ immediately with clear water for several minutes - consult a doctor immedi-  Always wear eye protection. ately.
  • Page 167  First read and observe the introductory information and safety warn- CAUTION ings on page 163. The vehicle battery must only be disconnected if the ignition is switched off, ■ The battery is located in the engine compartment below a plastic box. otherwise the vehicle's electrical system (electronic components) can be dam- ›...

  • Page 168: Operation In Winter

    It is not normally necessary to disconnect the cables of the battery if you re- Note charge the vehicle battery using low amperages (as for example from a mini- charger). Refer to the instructions of the charger manufacturer. The battery electrolyte level is also periodically checked by a specialist garage ■...

  • Page 169: Automatic Load Deactivation

    Replacing the vehicle battery  First read and observe the introductory information and safety warn- ings on page 163. When replacing a battery, the new vehicle battery must have the same capacity, voltage, amperage and be the same size. Suitable vehicle batteries can be pur- chased from a specialist dealer.

  • Page 170: Wheels

    WARNING (Continued) Wheels Incorrect wheel alignment at the front or rear impairs handling – there is the ■ risk of an accident. Tyres and rims Unusual vibrations or pulling of the vehicle to one side could be a sign of ■...

  • Page 171: Tyre Service Life

    WARNING Tyre service life Observe the following information regarding the wheel bolts. The wheel bolts must be clean and must turn easily. Never apply grease or ■ oil. The specified tightening torque of the wheel bolts for steel and light alloy ■...
  • Page 172 Always check the inflation pressure when the tyres are cold. Do not reduce the Tyre age higher pressure of warm tyres. Tyres age losing their original characteristics, even if they are not used. There- fore, we recommend that you do not use summer or winter tyres that are older Adjust the tyre pressure accordingly if you are carrying a greater load.

  • Page 173: Unidirectional Tyres

    615 kg Spare wheel 630 kg 650 kg Fig. 134 Speed symbol Boot: Spare wheel This indicates the maximum permissible speed for a vehicle fitted with tyres in the category concerned. 170 km/h 180 km/h 190 km/h 200 km/h 210 km/h ...
  • Page 174 WARNING Wheel bolts Never use the temporary spare wheel if it is damaged. ■ If the dimensions or design of the temporary spare wheel differ from the fit- Fig. 135 ■ ted tyres, never drive faster than 80 km/h (or 50 mph). Remove the cap Avoid accelerating at full throttle, sharp braking and fast cornering.

  • Page 175: Tyre Pressure Monitor

    The rolling circumference of the tyre can change if: Hubcaps › the tyre inflation pressure is too low; › the structure of the tyre is damaged; › the vehicle is loaded on one side; Fig. 136 › the wheels of an axle are loaded heavily (e.g. when towing a trailer or when Pull off the wheel trim cap on driving uphill or downhill);...

  • Page 176: Winter Use

    To achieve the best possible handling properties, winter tyres must be fitted on Note all four wheels, the minimum tread depth must be 4 mm and tyres must be no older than 4 years. The tyre control display does therefore not replace the regular tyre inflation ■...

  • Page 177: Do-It-Yourself

    Note Do-it-yourself Pay attention to the expiration date of the first-aid kit. ■ We recommend using a first-aid box from ŠKODA Original Accessories available ■ Emergency equipment, and self-help from a ŠKODA Partner.  Fire extinguisher Emergency equipment  First read and observe the introductory information given on page 175. ...

  • Page 178: Changing A Wheel

    WARNING Vehicle tool kit The factory-supplied lifting jack is only intended for your model of vehicle. ■ Under no circumstances attempt to lift heavier vehicles or other loads – there is a risk of injury. Ensure that the vehicle tool kit is safely secured in the boot. ■...

  • Page 179: Subsequent Steps

    › Move the gearshift lever into Neutral or move the selector lever for the auto- WARNING (Continued) matic gearbox into position P. › Secure the base plate of the lifting jack with suitable means to prevent pos- Firmly apply the handbrake. ■...
  • Page 180 › Stow and attach the replaced wheel in the spare wheel well using a special Tightening › screw » page 171, Spare wheel. Push the wheel wrench onto the wheel bolt up to the stop › › Stow the vehicle tool kit in the space provided. Grasp the end of the wrench and turn the bolt against the direction of the ar- ›...
  • Page 181 WARNING Raising the vehicle Choose a flat and firm surface for jacking the vehicle.  Fig. 141 Jacking points for positioning lifting jack Securing wheels against theft Fig. 143 Principle sketch: Anti-theft wheel bolt with adapter  First read and observe the introductory information and safety warn- ings on page 176.

  • Page 182: Tyre Repair

    Note Tyre repair Immediately replace the wheel that was repaired using the breakdown kit or con-  Introduction sult a specialist garage about repair possibilities.  This chapter contains information on the following subjects: Breakdown kit Breakdown kit Preparations for using the breakdown kit Sealing and inflating the tyre Check after 10 minutes' driving Use the breakdown kit to reliably repair tyre damage caused by foreign bodies or...

  • Page 183: Sealing And Inflating The Tyre

    The valve remover has a slot at its lower end which fits into the valve core. Sealing and inflating the tyre This is the only way in which you can remove and re-install the valve core from the tyre valve. The same also applies to the replacement valve core ...

  • Page 184: Jump-Starting

    WARNING Jump-starting The tyre inflation hose and air compressor may get hot as the tyre is being ■  Introduction inflated – there is a risk of injury. Do not place the hot tyre inflation hose or hot air compressor on flammable ■...

  • Page 185: Towing The Vehicle

    Jump starting using the battery in another vehicle Jump-starting in vehicles with the START-STOP system Fig. 145 Fig. 146 Jump-starting: A – flat battery, B Engine compartment: Earth – battery providing current   First read and observe the introductory information and safety warn- First read and observe the introductory information and safety warn- ings on page 182.
  • Page 186 › On vehicles with a manual transmission, only push down on the accelerator Note pedal once the rope is taught. We recommend using a tow rope from ŠKODA Original Accessories available ■ The maximum towing speed is 50 km/h. from a ŠKODA Partner. Driver of the towed vehicle Towing another vehicle requires a certain amount of practice.
  • Page 187 Rear towing eye Fig. 148 Rear towing eye  First read and observe the introductory information and safety warn- ings on page 183. The rear towing eye is located below the rear bumper on the right » Fig. 148.  Emergency equipment, and self-help...

  • Page 188: Fuses And Light Bulbs

    CAUTION Fuses and light bulbs Never “repair” fuses and also do not replace them with a fuse of a higher am- ■ perage - risk of fire! This may also cause damage at another part of the electrical Fuses system. Have the electrical system checked as quickly as possible by a specialist garage ■...
  • Page 189 Power consumer Fuses in the dash panel Control unit for ABS, button for START STOP Petrol engine: Speed regulating system Fig. 149 Reversing light (manual gearbox) Underside of the dash panel: Distribution board cover. Ignition, engine control unit, automatic gearbox Brake pedal switch, clutch pedal switch Operating controls for the heating, control unit for air conditioning sys- tem, parking aid, control unit for cornering lights, radiator fan, washing...
  • Page 190 Power consumer Fuses in the engine compartment High pressure fuel pump, pressure valve Engine control unit Engine control unit, vacuum pump Power supply of ignition lock Main beam Rear fog light, DC/DC converter START-STOP Fog lights Air blower for heating 40-41 Not assigned Rear window heater...

  • Page 191: Bulbs

    We recommend that you always carry a box of replacement bulbs in the vehicle. ■ Foglights and daytime running lights Replacement bulbs can be purchased from ŠKODAOriginal Accessories. Fabia Scout, Fabia RS foglights We recommend that the headlight settings are checked by a specialist garage ■ Changing the licence plate light bulb after a main beam or low beam bulb has been replaced.
  • Page 192 Headlights Changing the low beam and high beam bulb (halogen headlights) Fig. 154 Removing bulbs for low and main beam Fig. 153 Bulb arrangement: Halogen headlights/halogen projector head- lights  First read and observe the introductory information and safety warn- ings on page 189.
  • Page 193 › Turn the connector with the bulb in anti-clockwise direction up to the Changing the low beam and high beam bulb (halogen projector stop » Fig. 156 and remove it. headlights) › Replace the lamp, insert the connector with the new bulb and turn clockwise up to the stop.
  • Page 194 Foglights and daytime running lights Fabia Scout, Fabia RS foglights Fig. 157 Front bumper: Protective grille/removing the fog light Fig. 158 Front bumper: Fabia Scout/Fabia RS  First read and observe the introductory information and safety warn- ings on page 189.
  • Page 195 Changing light bulbs and installing fog lights Rear light › Press the locking button » Fig. 159 of the plug and remove the plug from the socket › Turn the socket with the bulb counter-clockwise up to the stop and remove. ›...
  • Page 196 › Grip the tail lamp assembly and carefully remove it by pulling it back at an angle with loosening movements. Do not pull the grommet with the cables out of the bodywork. › To re-install the tail light assembly, first of all guide it with the screw into the opening of the bodywork »...

  • Page 197: Technical Data

     First read and observe the introductory information given on page 195. Technical data Vehicle data sticker The vehicle data sticker » Fig. 163 is located on the floor of the boot and is also Technical data stated in the service schedule. The vehicle data sticker contains the following data: Vehicle data Vehicle identification number (VIN)
  • Page 198  between 0 and 120 km/h. Dimensions  First read and observe the introductory information given on page 195. Dimensions (mm) FABIA ESTATE FABIA FABIA SCOUT FABIA RS ESTATE ESTATE SCOUT ESTATE RS GreenLine GreenLine Length 4000 4000...
  • Page 199 1.2 ltr./44 kW engine Output (kW per rpm) Max. torque (Nm at rpm) Number of cylinders/Displacement (cm 44/5200 108/3000 3/1198 Performance FABIA ESTATE Top speed (km/h) Acceleration 0 - 100 km/h (s) 16.5 16.7 Permissible trailer load, braked (kg) /900...
  • Page 200 1.2 ltr./77 kW TSI engine Output (kW per rpm) Max. torque (Nm at rpm) Number of cylinders/Displacement (cm 77/5000 175/1500-4100 4/1197 Performance FABIA MG5 FABIA DSG7 COMBI MG5 COMBI DSG7 Top speed (km/h) Acceleration 0 - 100 km/h (s) 10.1 10.2 10.2...
  • Page 201 1.6 ltr./77 kW engine Output (kW per rpm) Max. torque (Nm at rpm) Number of cylinders/Displacement (cm 77/5600 153/3800 4/1598 Performance FABIA MG5 FABIA AG6 COMBI MG5 COMBI AG6 Top speed (km/h) Acceleration 0 - 100 km/h (s) 10.4 11.5 10.5...
  • Page 202 Max. torque (Nm at rpm) Number of cylinders/Displacement (cm 132/6200 250/2000-4500 4/1390 Performance FABIA RS ESTATE RS Top speed (km/h) Acceleration 0 - 100 km/h (s) 1.2 ltr./55 kW TDI CR DPF engine Output (kW per rpm) Max. torque (Nm at rpm)
  • Page 203 1.6 ltr./55 kW TDI CR engine Output (kW per rpm) Max. torque (Nm at rpm) Number of cylinders/Displacement (cm 55/4000 195/1500-2000 4/1598 Performance FABIA ESTATE Top speed (km/h) Acceleration 0 - 100 km/h (s) 14.1 14.2 Permissible trailer load, braked (kg) 1000...
  • Page 204 1.6 ltr./77 kW TDI CR engine Output (kW per rpm) Max. torque (Nm at rpm) Number of cylinders/Displacement (cm 77/4400 250/1500-2500 4/1598 Performance FABIA ESTATE Top speed (km/h) Acceleration 0 - 100 km/h (s) 10.9 11.0 Permissible trailer load, braked (kg) 1200...

  • Page 205: Index

    Alarm Index Anti-theft alarm system Operation Ball head Trailer Check fitting Antilock Braking System Fitting Armrest Ready position Abroad Removing Ashtray Driving abroad Belts warning light Belt tensioners warning light Assist systems Bicycle carrier Accessories 21, 111 Bonnet Adjusting 20, 111 Closing Exterior mirrors Cruise control system...
  • Page 206 Bulbs Changing a wheel Clock Changing Preparation Clothes hook In the rear light Removing and refitting a wheel Cockpit Subsequent steps Button in the driver's door 12-volt power outlet Electrical power windows Charging a vehicle battery Ashtray Check Cigarette lighter Fit ball head properly General view Lighting...
  • Page 207 Digital clock Sliding/tilting roof First aid kit Towing the vehicle Dipstick Foot mats Tyre repair see Foot mats Display Unlocking the boot lid Service interval Ford Wheel change Distance driven Front airbag Emergency equipment Door Front seats Fire extinguisher Child safety lock Fuel First aid kit Closing...
  • Page 208 Heating Lights Mirror Deicing the windows Cockpit 45, 46 Additional interior mirror Exterior mirrors Daytime running lights Exterior mirrors Operation Fog lights Manually dimmed rear-view mirror Rear window Foglights with the CORNER function Vanity Recirculated air mode Halogen projector headlights with cornering light Mobile phone Seats function...
  • Page 209 Parking Replacing fastening and unfastening Parking aid Vehicle battery Height adjustment Windscreen wiper blades Parts replacement Seatbelts Replenishing Inertia reels Passive safety Coolant Before every journey Seat belts Engine oil Driving safety The physical principle of a frontal collision Windscreen washer fluid Safety equipment Seats Rims...
  • Page 210 Speed symbol Washing by hand Sizes see Wheels Wash system Wear indicator Spoiler Technical data Stalk Telephone Main beam Tiptronic Underbody protection Turn signals see automatic gearbox Underbody waxing START/STOP Tools unlock Function TOP TETHER Central locking system Starting and stopping the engine Towing Unlocking Starting engine...
  • Page 211 Seat covers Speed symbol Winter use Synthetic leather Storing wheels Winter tyres Underbody waxing Swapping wheels around Vehicle exterior care Tyre pressure Waxing Tyre service life Tyre wear indicator Vehicle Condition Unidirectional tyres see Auto Check Control Wheel sizes Vehicle data sticker Winter tyres Vehicle dimensions Wheels and tyres...
  • Page 212 ŠKODA AUTO a.s. pursues a policy of constant product and model development. Reprinting, reproduction, translation, or any other use, either in whole or in part, We trust that you will understand that changes to models in terms of shape, is not permitted without the written consent of ŠKODA AUTO a.s.. equipment and engineering, may be introduced at any time.
  • Page 215 Also please pay attention to those parts in the Owner's Manual that are marked  below. Work with us – for the sake of the environment. Návod k obsluze Fabia anglicky 05.2013 S55.5610.13.20 5J6 012 003 QM...

Table of Contents

Save PDF
