BODY / STEERING / SUSPENSION

Strut Assembly

Nut - 15 ft.lbs. (21 Nm)
Strut Bumper
Spacer Rubber
Washer
Strut
Upper Pivot Ball
Spacer Nut
Clamp
5
Lower Pivot Ball
Washer
17 ft.lbs. (23 Nm)
Spring Retainer
17 ft.lbs. (23 Nm)
Bolts
Spring
Brake Caliper
Hubstrut Bearing
Retaining Ring
5.23
