1 Port PCI Express eSATA II Controller Card
PEXESATA1
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 03/05/2014
Advertisement
Table of Contents
Related Manuals for StarTech.com PEXESATA1
Summary of Contents for StarTech.com PEXESATA1
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 03/05/2014...
- Page 2 Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges...
-
Page 3: Table Of Contents
Table of Contents Introduction ...............................1 Package contents ............................1 System Requirements ..........................1 Hardware Guide ...............................2 Installation................................3 Driver Installation - Windows® XP/Server 2003 ..............4 Driver Installation - Windows® 2000 ....................4 Windows 2000/XP/2003 Server Fresh Installation ..............5 Windows Vista™/7 Fresh Installation .....................6 Installation Without a Floppy Drive ....................7 Specifications ..............................8 Technical Support ............................9 Warranty Information ............................9... -
Page 4: Introduction
Introduction Thank you for purchasing a StarTech.com SATA II PCI Express Adapter. This innovative card allows you to turn an available PCI Express (1x) slot into an internal or external SATA (eSATA) connection with support for full SATA data transfer rates of up to 3Gbps - an ideal solution if you need an extra SATA port or want to externalize your storage. -
Page 5: Hardware Guide
Connector B There are two SATA ports available on PEXESATA1 - referred to in the above picture as A and B. Port A is an external SATA (eSATA) port and B is an internal SATA port; Please note that only one of them will work at a time. -
Page 6: Installation
Please note: If you are performing a new operating system installation and wish to boot from the drive that will be connected to PEXESATA1, please copy the following files from the included Driver CD to a blank floppy disk that can be used during OS installation: si3531.cat... -
Page 7: Driver Installation - Windows Xp/Server 2003
4. Position the card above the open PCI Express slot, ensuring that the card is properly aligned with the slot. Insert the card firmly into the slot, distributing force evenly across the length of the board. Once inserted, secure the card into the adjoining socket (previously covered by a metal bracket, on the rear panel of the computer chassis), using the correct size screw (if necessary, please consult documentation that accompanied purchase of computer). -
Page 8: Windows 2000/Xp/2003 Server Fresh Installation
5. If a floppy drive is available on the host system, attach PEXESATA1 to the Serial ATA drive(s), using a SATA (data) cable. Similarly, connect the drive to an available power connector as provided by the computer power supply. -
Page 9: Windows Vista/7 Fresh Installation
(if necessary, please consult documentation that accompanied purchase of computer). 5. Attach PEXESATA1 to the Serial ATA drive (internal or external, depending on jumper settings - see Hardware Guide for further details), using a SATA (data) cable. Similarly, attach an available SATA power connector (provided by computer power supply) to the drive. -
Page 10: Installation Without A Floppy Drive
10. Windows Vista™ will then install the necessary files, after which the drive connected to PEXESATA1 will be recognized as a usable drive onto which the OS can be installed. 11. Select the drive on which you wish to install the operating system, and click Next, to... -
Page 11: Specifications
Specifications PCI Express 1.0a (x1 slot connector) Bus Interface SATA revision 2.0 (3Gbps) Chipset ID Silicon Image SiI3531 External: 1x eSATA plug Connectors Internal: 1x SATA plug Maximum Data Transfer Rate SATA: 3Gbps Certifications CE, RoHS, WEEE Dimensions 102 mm x 120 mm x 20 mm (L x W x H) (4.02 in x 4.72in x 0.79 in) Weight... -
Page 12: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 13 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
