8 port low profile pci express rs232 serial adapter card w/ 161050 uart

Advertisement

Quick Links

8 Port Low Profile PCI Express RS232
Serial Adapter Card w/ 161050 UART
PEX8S1052
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 11/21/2018
*actual product may vary from photos
