65DRV

1-1.7 POWER MANAGEMENT

• ACPI 1.0 compliant (Advanced Configuration and Power Interface).
• APM V1.2 compliant (Legacy power management).
• System event monitoring with two event classes.
• Supporting PS/2 Keyboard & Mouse power on.
• Supporting Wake On LAN (WOL) & Wake On Modem.
• Supporting real time clock (RTC) with date alarm, month alarm, and
century field.
• Supporting Keyboard power on & Mouse Power on.

1-1.8 MULTI-I/O FUNCTION

• Two Ultra DMA-33 / 66 /100 Master Mode PCI EIDE ports.
• Two UART's for Complete Serial Ports.
• One dedicated IR connector:
-- At third serial port dedicated to IR function either through the two complete serial
ports or the third dedicated port Infrared-IrDA (HPSIR) and ASK (Amplitude Shift
Keyed) IR.
• Multi-mode parallel connector supporting:
-- Standard mode, ECP and EPP.
• Floppy Disk connector supporting:
Two FDDs with drive swap support .
• Universal Serial Bus connector supporting:
--- USB v1.1 and Intel Universal HCI v1.1 compatible.
--- 2 built-in USB connectors, in addition to one internal USB header which
requires a USB cable to support 2 more optional USB ports.
• PS/2 Keyboard connector.
• PS/2 Mouse connector.

1-1.9 EXPANSION SLOTS

• Six PCI bus Master slots.
• One CNR slot.
• One AGP 4x Pro mode slot.
• Three DIMM slots.

1-1.10 FORM FACTOR

• ATX from factor, 4 layers PCB.
• Mainboard size 22.0cm X 30.2cm.
10
