2
BASIC OPERATION
D TX code number edit
If the transcever has [TX Code CH Select] or [TX Code
Enter] assgned to t, TX code contents can be edted wthn
the allowable dgts.
USING [TX CODE CH SELECT] KEY:
q Push [TX Code CH Select] to enter the TX code channel
selecton mode.
• Select the desred operatng channel before enterng the TX
code channel selecton mode f necessary.
w Push [TX Code CH Select] for 1 sec. to enter the TX code
edt mode.
• The dgt to be edted blnks.
e Push [TX Code CH Select] to select the desred dgt to
be edted.
r Push [CH Up] or [CH Down] to select the desred dgt.
t Push [TX Code CH Select] to set. The dgt to the rght wll
blnk automatcally.
y Repeat r and t to edt all allowable dgts.
u After edtng, push [TX Code CH Select] to set.
• Return to the stand-by mode.
i Push [Call] to transmt.
11
(PMR operaton only)
USING [TX CODE ENTER] KEY:
q Push [TX Code Enter] to enter the TX code edt mode.
• The dgt to be edted blnks.
w Push [TX Code Enter] to select the desred dgt to be ed-
ted.
e Push [CH Up] or [CH Down] to select the desred dgt.
r Push [TX Code Enter] to set. The dgt to the rght wll
blnk automatcally.
t Repeat e and r to edt all allowable dgts.
y After edtng, push [TX Code Enter] to set.
• Return to the stand-by mode.
u Push [Call] to transmt.

D DTMF transmission

If the transcever has [DTMF Autodal] assgned to t, the
automatc DTMF transmsson functon s avalable. Up to 8
DTMF channels are avalable.
q Push [DTMF Autodal]— a DTMF channel appears.
w Push [CH Up] or [CH Down] to select the desred DTMF
channel.
e Push [DTMF Autodal] to transmt the DTMF code.
