PANEL DESCRIPTION

■ Programmable function keys

The followng functons can be assgned to [UP], [DOWN],
[P0], [P1], [P2.], [P3] and [P4.] programmable functon keys.
Consult your Icom dealer or system operator for detals con-
cernng your transcevers programmng.
INFORMATION:
Dependng on the pre-settng, the [A], [B], [C] and [D]
keys on the optonal HM-152T
the same as the functons whch are programmed to the
[P0], [P1], [P2.] and [P3] keys on the transcever, respec-
tvely. Ask your dealer for detals.
CH UP AND DOWN KEYS
➥ Push to select an operatng channel.
➥ Push to select a transmt code channel after pushng [TX
Code CH Select].
➥ Push to select a DTMF channel after pushng [DTMF Au-
todal].
➥ Push to select a scan group after pushng and holdng
[Scan A Start/Stop]/[Scan B Start/Stop] for 1 sec.
3
operate
dtmf microphone
ZONE KEY
Push ths key, then select the desred zone usng [CH Up]/
[CH Down].
What is "zone"?— Selected channels are assgned to a
zone accordng to how they are to be used n a group.
For example, 'Staff A' and 'Staff B' are assgned nto a
"Busness" zone, and 'John' and 'Cndy' are assgned nto a
"Prvate" zone.
ZONE UP AND DOWN KEYS
Push to select an operatng zone.
SCAN KEY
➥ Push to start and cancel scannng operaton.
• When Power ON Scan functon s actvated, push to pause the
scannng operaton. And the paused scan restarts after the
specfied tme perod has passed.
➥ Push and hold ths key for 1 sec. to ndcate the scan lst,
then push [CH Up] or [CH Down] to select the desred lst.
