Supplied Accessories - Icom iF9511S Instruction Manual

3
CONNECTION AND MAINTENANCE
n Supplied Accessories
Microphone
DC power cable
Mounting bracket
* 1
IC-F9511T only
* 2
Used for labelling the program-
mable function keys according
to their assinged functions.
15
Microphone hanger Microphone
and screw set hanger cable
Speaker* 1
Function name
stickers* 2
KEY-STICKER
Key caps
Flat washers Bracket bolts
Spring washers Mounting screws
(M5×12)
Nuts
Self-tapping screws
(M5×16)
• Function name stickers
There are no names on the programmable function keys
since the functions can be freely assigned to these keys.
Attach the supplied function name stickers as below to the
appropriate keys for easy recognition of that key's assigned
function.
Then, protect the attached stickers from unsticking with the
supplied key cap as below.
Function name sticker
Key cap
