Laspaziale S1 Dream Owner's Manual

Espresso machine
Hide thumbs Also See for S1 Dream:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual

Espresso Machine

Made In Italy by
Owner's Manual
User Interface Details Addendum
Covers Firmware Version 1.19 Only
Version Date: April 5, 2014

Advertisement

Table of Contents
loading

Related Manuals for Laspaziale S1 Dream

Summary of Contents for Laspaziale S1 Dream

  • Page 1: Espresso Machine

    Espresso Machine Made In Italy by Owner’s Manual User Interface Details Addendum Covers Firmware Version 1.19 Only Version Date: April 5, 2014...

  • Page 2: Table Of Contents

    S1 Dream Espresso Machine – GUI Addendum Table of Contents S1 Dream Graphical User Interface Addendum Scope ............3 Dream Front Panel Description ................... 3 The Dream’s Machine Off and Turning On Screens ............4 Steam Boiler Water Level Sensor Threshold Settings ............4 The Home Screen .......................
  • Page 3 S1 Dream Espresso Machine – GUI Addendum 7.25 Screen Contrast ....................33 7.26 Deactivate Group Pressure Front ePanel Display (Plumbed Version Only) ..33 7.27 Set / Change Password ..................34 7.28 Software Update aka Firmware Update ..............35 7.29 Menu Screen #4 (Last Menu Screen ................. 36 7.30 Default Setting...

  • Page 4: S1 Dream Graphical User Interface Addendum Scope

    1. S1 Dream Graphical User Interface Addendum Scope The LaSpaziale Dream Owner’s Manual is more of an extended “Quick Start” Guide. It does not cover the extensive Menu system in much detail. It is the goal of this addendum to document the complete Graphical User Interface (GUI) system in detail with photos and text in order to help the user gain the best possible espresso experience with this new machine.

  • Page 5: The Dream's Machine Off And Turning On Screens

    Rather than recall the first batch of machines to swap the sensor leads, LaSpaziale put in a software work around. It is now possible to select one of two thresholds depending on whether you have one of those original machines or a later machine.

  • Page 6: The Home Screen

    S1 Dream Espresso Machine – GUI Addendum In order to confirm whether your machine is correct after checking your serial number as noted below in paragraph 5, check the Threshold setting as noted below. Start with the machine OFF and then press and hold the Menu button.

  • Page 7: Dream Gui Addendum Page

    S1 Dream Espresso Machine – GUI Addendum The “E” in the upper left corner stands for Economy mode; i.e. 15A mode. If you have the Dream plugged into a 15A outlet this needs to be showing. The Menu to set this is covered later and is referred to as Full Power - ON (20A) or OFF (15A).

  • Page 8: Quick Access To Information And Profile Selection Screens

    S1 Dream Espresso Machine – GUI Addendum Note that the word OFF in the lower left corner of the display is followed by +1 in this photo. This means that the time listed below OFF+1 is for tomorrow. If the display only showed OFF the time below would be for today.

  • Page 9: Multiple Screens Of Additional Status Information

    S1 Dream Espresso Machine – GUI Addendum With the Home Screen showing, press and hold the Blue Up Arrow button to the right of the display panel until the screen below is shown. You will see the serial number on the top line.

  • Page 10: Down Arrow Profile Selection

    S1 Dream Espresso Machine – GUI Addendum If there were active alarms, i.e. ongoing, unresolved error conditions a text explanation of each one – if more than one – displays here. Later in the menu documentation section you will see how to scroll through a history of all alarms that have occurred on this machine.

  • Page 11: Set Calendar

    S1 Dream Espresso Machine – GUI Addendum Note: There are a few quirks in the menu system that will be pointed out when we get to each one. This document will just navigate from one menu to the next in sequence until all have been covered.

  • Page 12: Set Time Of Day

    S1 Dream Espresso Machine – GUI Addendum Press the down arrow once to highlight the Calendar icon. Note the calendar icon change. The top display line also changes to “Calendar” as a further indication. Press the Menu button once to enter the Calendar set function.

  • Page 13: Enable Disable Button Beep

    S1 Dream Espresso Machine – GUI Addendum Enable Disable Button Beep Wherever you currently are in the menu system be sure you are seeing Menu screen #1. Use the Arrow keys to get there and then highlight the Beep icon, then press the Menu button.

  • Page 14: Set Backlight Lcd Time-Out

    S1 Dream Espresso Machine – GUI Addendum These are they system impacts of your choice: American English – Time AM/PM, Date MM/DD/YY, Temp = Fahrenheit, Liquid = Gallons British English – Time AM/PM, Date DD/MM/YY, Temp = Celsius, Liquid = Liters Italian –...
  • Page 15 S1 Dream Espresso Machine – GUI Addendum later turned back On. If you are starting a new programming session Monday is where you want to start. However, if you want to change a day other than Monday, you can press the Up Arrow to scroll through the days of the week.

  • Page 16: Show / Reset Shot Counters

    S1 Dream Espresso Machine – GUI Addendum If the Copy option was selected on the last screen “Copying” will blink several times and then you are back on main Menu screen #1. Hint: If you have some days that are programmed the same...

  • Page 17: Profile Sub-Menus

    S1 Dream Espresso Machine – GUI Addendum Wherever you currently are in the menu system, be sure you are seeing Menu screen #1. Use the Arrow keys to get there and then highlight the Program icon. Next press the Menu button to start the profile programming mode.

  • Page 18: Set Coffee Water Temperature

    S1 Dream Espresso Machine – GUI Addendum 7.9.1 Set Coffee Water Temperature See also the Offset setting which is one of the last menu settings described later in this document. Since Offset works in conjunction with this setting, you could have the coffee temperature below boiling but have the offset incorrectly set to a positive value that causes the water temperature to be too high.

  • Page 19: Set Coffee Doses (Water Volume)

    S1 Dream Espresso Machine – GUI Addendum If B.English or Italian are selected as the language this value is show in Celsius. 7.9.3 Set Coffee Doses (Water Volume) Depending on where you are in the profile menus, press the Up or Down arrow to highlight the Coffee Doses icon and display that text on the top of the screen.

  • Page 20: Set Preinfusion - Plumbed Models Only

    S1 Dream Espresso Machine – GUI Addendum The Dream provides automatic timed flow as an option for the hot water spigot. The displayed value shows the current number of seconds that the hot water is programmed to run. Put a measuring cup under the hot water spigot, then press the hot water button, press it again when the desired amount has been dispensed.

  • Page 21: Set Mat (Milk Adjustable Temperature)

    S1 Dream Espresso Machine – GUI Addendum 7.9.6 Set MAT (Milk Adjustable Temperature) This future feature is for a replacement steam arm that has a temperature sensor in the tip. When the programmed milk temperature is reached, the steam automatically shuts off.

  • Page 22: Name Profile

    S1 Dream Espresso Machine – GUI Addendum 7.9.7 Name Profile Depending on where you are in the profile menus, press the Up or Down arrow to highlight the Multiprofiles icon and display that text on the top of the screen. Then press the Menu button to enter the MULTIPROFILES programming screen.

  • Page 23: Service Menu

    S1 Dream Espresso Machine – GUI Addendum Starting with the Program icon on menu Screen 1 highlighted, press the Down arrow to bring up Menu screen #2. 7.12 Service Menu Note that this is the top item on Screen #2. In the upper corner of the screen you see double left pointing arrows and in the upper right corner you see double right pointing arrows.

  • Page 24: Filter Replacement Notification

    S1 Dream Espresso Machine – GUI Addendum When this screen is first displayed, it shows the current Service cycle count. The current count is also shown in the status screens documented in paragraph 6. Unfortunately, that fact is not shown in those screens since the feature was disabled when those screenshots were taken.

  • Page 25: Alarm History

    S1 Dream Espresso Machine – GUI Addendum Use the up or down arrow buttons to select OFF or ON, then press the Menu button to activate your choice. If OFF is selected, the previous Menu screen #2 is displayed. In this case you will received on Filter replacement notification.
  • Page 26 S1 Dream Espresso Machine – GUI Addendum This and the next three screens show an examples of four alarm history screens from this Dream machine. Note that this is alarm 6 of 11. You use the Up and Down arrow keys to scroll back and forth through the list. Note that details of the alarm as well as the date and time it occurred are displayed.

  • Page 27: Read "Backup" Function (Machine Writes Data To Sd Card)

    Card) Most everyone uses SD Cards these days and is familiar with the standard notation that a Read operation will read a file from the card and put it on your computer. LaSpaziale is using the opposite frame of reference.

  • Page 28: Write "Restore" Function (Machine Reads Data From Sd Card)

    S1 Dream Espresso Machine – GUI Addendum 7.16 Write “Restore” Function (Machine Reads Data from SD Card) With the large Write icon displayed and the word Write showing at the top of the screen, press the Menu button. With the SD card that came with your machine inserted into the reader, plug the ribbon cable connector in to the port to the right of the pressure gauge.

  • Page 29: Led Settings (Lamps Adjacent To Group)

    S1 Dream Espresso Machine – GUI Addendum 7.17 LED Settings (Lamps Adjacent to Group) This setting controls the two LED lamps on either side of the group that light up the area so you can see what it happening while pulling a shot or drawing hot water.

  • Page 30: Electronic Grinds System (Egs)

    S1 Dream Espresso Machine – GUI Addendum Use the Up or Down arrows to scroll to the desired value. As you can see from this and the next two screens the options are 5, 10, or 15 seconds. The value initially displayed is this last value that was set for this feature.

  • Page 31: Menu Screen #3

    S1 Dream Espresso Machine – GUI Addendum Use the Up arrow or the Down arrow buttons, move the Dot to ON or OFF, then press the Menu button to lock in that option and return to Menu screen #2. 7.20 Menu Screen #3 Starting with the EGS Screen highlighted as shown in the previous paragraph, press the Down Arrow to display the Menu screen #3 Configuration Options.

  • Page 32: Screen Saver

    S1 Dream Espresso Machine – GUI Addendum Press the Continuous Flow button (the one between the One-Cup and Two-Cup buttons) to begin the cleaning operation. It continuously cycles 5sec On / 5sec Off. If you get to this screen and don’t want to perform a group cleaning now, press either the Up or Down Arrow to immediately return to Menu screen #3.

  • Page 33: Time Update I.e. Daylight Savings Time Enable

    S1 Dream Espresso Machine – GUI Addendum Use the Up or Down arrow to select your desired setting, then press the Menu button to lock it in. If you selected OFF the screensaver is disabled and you return to Menu screen #3.

  • Page 34: Screen Contrast

    S1 Dream Espresso Machine – GUI Addendum Use the Up or Down arrows to select either the European or the American Daylight Savings time Start/Stop dates. Then press the Menu button to lock in the value and return to Menu screen #3.

  • Page 35: Set / Change Password

    S1 Dream Espresso Machine – GUI Addendum 7.27 Set / Change Password With the large Padlock icon displayed and the word PASSWORD showing at the top of the screen, press the Menu button. Use the Up or Down Arrows to select the desired password mode.

  • Page 36: Software Update Aka Firmware Update

    Firmware version 1.19 and this Menu is called the Software Update function. Even though there is a slight difference in the definition of the two terms, LaSpaziale is using them interchangeably. Plug in the SD Card reader with the SD Card containing the firmware update file inserted.

  • Page 37: Menu Screen #4

    S1 Dream Espresso Machine – GUI Addendum 7.29 Menu Screen #4 (Last Menu Screen Starting from the first SW Update screen above, press the Down Arrow key. This will take you to the first item on Menu screen #4. Note in the first photo of the next paragraph that there are double left pointing arrows in the upper left corner and no double right pointing arrows in the upper right corner.

  • Page 38: Full Power (15A/20A Setting)

    S1 Dream Espresso Machine – GUI Addendum The Owner’s Manual instructs that this value should only be changed by a trained technician. Apparently this can correct for inaccuracies of the steam boiler temperature sensor. However, the steam boiler temperature is only selected in order to adjust for the desired steam pressure.

  • Page 39: View / Change Pid Settings

    S1 Dream Espresso Machine – GUI Addendum With the large Square and Diagonal Arrow icon displayed and the word Offset showing at the top of the screen, press the Menu button. Use the Up and Down arrows to scroll to your desired value, then press the Menu button to lock in the value and return to Menu screen #4.

  • Page 40: Returning To The Home Screen

    S1 Dream Espresso Machine – GUI Addendum 7.35 Returning to the HOME Screen 1) Using the Up Arrow key either continually press it or else press and hold it down until this screen appears. This is the top level of Menu screen #1.

  • Page 41: Read / Write (Backup/Restore) Function Details

    NOT overwrite the actual machine serial number when reloaded onto the machine. d) You will see that LaSpaziale has an error in the file format in the row that contains the days of the week for the programmable On/Off times. There is an extra semicolon between each...

  • Page 42: Dream Gui Addendum Page

    DO NOT FIX THIS. Apparently, LaSpaziale has the same error in the code when it is read back into the Dream so this error needs to remain in the file.

  • Page 43: Example Of Converted Dream_R.csv File

    S1 Dream Espresso Machine – GUI Addendum 8.1 Example of converted DREAM_R.CSV file Dream GUI Addendum Page 42...
