Annual Service

A N N U A L / 5 0 0 , 0 0 0 C Y C L E S E R V I C E
•
Every 500,000 cycles the tool should be completely dismantled and new components should be used
where worn, damaged or recommended. All 'O' rings and seals should be renewed and lubricated with
MolyKote 111 grease before assembling.
•
For an easy complete service, Textron Fastening Systems offer a complete service kit as detailed below.

Service Kit: 71600-99990

Part No.
07900-00006
07900-00008
07900-00012
07900-00015
07900-00243
07900-00333
07900-00469
07900-00737
07900-00738
07900-00739
07900-00740
07900-00741
07900-00742
07900-00743

Before dismantling:

•
Disconnect the battery before any servicing or dismantling is attempted, unless specifically instructed otherwise.
•
Care must be taken at all times to ensure that conditions are clean so that no foreign matter enters the tool or serious
damage may result.
•
Empty the oil from the tool following the first three steps of the priming procedure. Refer to the priming procedure on pages 14
and 15 of the Instruction Manual.
•
Remove the nose equipment.
For a complete service of the tool, we advise that you proceed with dismantling of sub-assemblies in the order shown on
page 5. After dismantling the tool we recommend that you replace all seals.
On reassembly it is essential to prime the tool and fit an appropriate nose assembly prior to operating.
4
Spanners are specified in inches and across flats unless otherwise stated
Description
Spatular
7 / x 1 / Spanner
16 2
9 / x 5 / Spanner
16 8
5 / x 11 / Spanner
8 16
Screwdriver - Small
Screwdriver - Medium
2.5mm Allen Key
Piston Seal Sleeve
Piston Seal Tool
Piston Bullet
Cylinder Collar
Guide Tube
Insertion Rod
End Cap Assembly Tool
Part No. Description
07900-00748 Threaded Sleeve Bullet
07900-00747 Valve Seat Tool
07900-00749 Threaded Sleeve Tool
07900-00750 Valve Needle Sleeve
07900-00751 3mm Allen Key - Short Reach
07900-00753 Circlip Pliers - Small
07900-00754 Priming Pump
07900-00755 Grease - MolyKote 111 - 100g tube
®
07900-00756 Loctite
07900-00757 Scalpel
07900-00760 Pozi Screwdriver
07900-00788 Service Kit Storage Case
07900-00768 Reservoir Bullet
07900-00769 Trigger Tool
07992-00020 Grease - Moly-Lithium
243 Threadlocker
