Avision AM7100NF Installation Manual

AM7100NF Installation Guide
Note: To learn the details on how to install and operate the machine, please refer to the manual in the supplied CD.
Unpacking the Machine
Remove the plastic bag and tapes on
the machine.
4. Move the paper-size dial to your
5. Load the paper into the input tray
desired paper size and orientation.
Important: Whenever you wish to
change your paper size and
orientation, you need to make the
same change in the paper-size dial to
ensure proper copy result.
Removing the Tapes on the
Toner Cartridge
Caution: To prevent the toner from
damage, do not expose the toner cartridge
to light for more than a few minutes.
1. Open the toner cartridge door by
pressing the button indicated.
Unlocking Your Machine
and insert the input tray to the
1.
machine.
2.
Important: If you need to transport the
product, lock the product first to protect the
scan unit.
Package Contents:
AM7100NF Main unit
Power Cable/USB Cable/Quick Guide
CD-ROM/Registration Card
2. Pull out the toner cartridge as shown.
3. Remove the tapes as shown.
4. Insert the cartridge to the machine and
close the toner cartridge door.
Connecting Your Telephone Cord
Open the document cover.
1.
Locate the lock switch at the left side.
2.
Loading Paper
1. Fan your paper first.
2. Pull out the Main Input Tray.
Connect one end of the telephone cord
into the "LINE" port of the machine.
Connect the other end of the telephone
cord into an active telephone wall jack.
www.avision.com
3. Press the paper guide release lever
and slide the paper guide to your
desired paper size.
Connecting Your Power Cable
1. Connect one end of the power cable
to the power jack of the machine.
2. Connect the other end to an
appropriate power outlet.
