Martin MAC 2000 Performance II User Manual page 41

DMX channel Value
0 – 126
20
127-128
129 – 255
21
0 – 255
0 – 126
22
127 - 128
129 – 255
23
0 – 255
0 – 126
24
127 - 128
129 – 255
25
0 – 255
0
26
127
255
0
27
127
255
0
28
127
255
0
29
127
255
0 - 2
3 – 236
237 – 239
30 240 – 242
243 – 245
246 – 248
249 – 251
252 – 255
0 – 2
3 – 239
240 – 242
243 – 245
246 – 248
249 – 251
252 – 255
31
0 – 2
3 – 239
240 – 242
243 – 245
246 – 248
249 – 251
252 – 255
Percent Function
Framing shutter 2
0 Angle –
50 Parallel
100 Angle +
Framing shutter 3
0 - 100 Out -> In
Framing shutter 3
0 Angle –
50 Parallel
100 Angle +
Framing shutter 4
0 - 100 Out -> In
Framing shutter 4
0 Angle –
50 Parallel
100 Angle +
Rotate framing shutters
0 - 100 Right - > Center -> Left
Pan coarse
0 Max Left
50 Neutral
100 Max Right
Pan fine
0 Max Left
50 Neutral
100 Max Right
Tilt coarse
0 Max Up
50 Neutral
100 Max Down
Tilt fine
0 Max Up
50 Neutral
100 Max Down
Speed: Pan/Tilt Movement
0 - 1 Tracking
2 - 92 Speed Fast -> Slow
93 Tracking (Slow speed - Overriding the PTSP menu setting)
94 Tracking (Normal speed - Overriding the PTSP menu setting)
95 Tracking (Fast speed - Overriding the PTSP menu setting)
96 - 97 Fan speed (Regulation, min. noise level – Overriding the FAN menu setting)
98 Fan speed (Full speed, max. cooling – Overriding the FAN menu setting)
99 - 100 Blackout while moving
Speed: Dimmer, Cyan, Magenta, Yellow, CTC, Effect, Iris, Focus, Zoom
0 Tracking
1 - 93 Speed Fast -> Slow
94 - 95 Tracking (Studio mode disabled – Overriding the MOdE menu setting)
96 Tracking (Studio mode enabled – Overriding the MOdE menu setting)
97 - 98 Tracking (Shortcuts disabled - Overriding the SCUT menu setting)
99 Tracking (Shortcuts enabled - Overriding the SCUT menu setting)
100 Fast Speed
Speed: Gobo 1, Framing, Animation wheel pos., Animation wheel rot.
0 Tracking
1 - 93 Speed Fast -> Slow
94 - 95 Tracking (Studio mode disabled – Overriding the MOdE menu setting)
96 Tracking (Studio mode enabled – Overriding the MOdE menu setting)
97 - 98 Tracking (Shortcuts disabled - Overriding the SCUT menu setting)
99 Tracking (Shortcuts enabled - Overriding the SCUT menu setting)
100 Blackout while moving
DMX protocol
Start code = 0
41
