AXIOMTEK OPS860-HM Series User Manual

Intel open pluggable specification box
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OPS860-HM Series
Intel Open
Pluggable Specification Box
®
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OPS860-HM Series and is the answer not in the manual?

Questions and answers

Related Manuals for AXIOMTEK OPS860-HM Series

Summary of Contents for AXIOMTEK OPS860-HM Series

  • Page 1 OPS860-HM Series Intel Open Pluggable Specification Box ® User’s Manual...
  • Page 2 Axiomtek does not make any commitment to update the information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice. No part of this document may be reproduced, stored in a retrieval...
  • Page 3 Safety Approvals  CE Marking  FCC Class A  FCC Compliance This equipment has been tested in compliance with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are meant to provide reasonable protection against harmful interference in a residential installation.

  • Page 4: Safety Precautions

    Safety Precautions Before getting started, please read the following important safety precautions. The OPS860-HM does not come equipped with an operating system. An operating system must be loaded first before installing any software into the computer. Be sure to ground yourself to prevent static charge when installing the internal components.
  • Page 5 W hen handling boards and components, wear a wrist - grounding strap, available from most electronic component stores. Trademarks Acknowledgments Axiomtek is a trademark of Axiomtek Co., Ltd. IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation. ®...

  • Page 6: Table Of Contents

    Table of Contents Disclaimers ....................ii Safety Approvals ..................iii Safety Precautions ..................iv CHAPTER 1 INTRODUCTION ..............1 General Description ............. 1 System Specifications ............3 1.2.1 Main CPU Board ..............3 1.2.2 I/O System ................4 Mechanical Assembly ............5 1.3.1 Dimensions ................
  • Page 7 Security Menu ..............57 Save & Exit Menu .............. 59 APPENDIX A REFERENCE DOCUMENTS ..........61 APPENDIX B WATCH DOG TIMER ............63...
  • Page 8 MEMO: viii...

  • Page 9: Chapter 1 Introduction

    OPS860-HM User’s Manual CHAPTER 1 INTRODUCTION This chapter contains general information and detailed specifications of the OPS860-HM Chapter 1 includes the following sections:  General Description  Specification  Dimensions  I/O Outlets  Package List General Description Intel Open® Pluggable Specification (OPS) Compliance OPS860-HM is based on the Intel®...
  • Page 10 OPS860-HM User’s Manual Easy maintenance OPS860-HM offers a best solution for digital signage market. Compliant with Intel OPS architecture, digital signage players are capable of deploying interchangeable systems faster and easing upgrading/maintenance, while lowering costs for d evelopment and implementation Additionally, having the ability to simply slot-in and out the unique pluggable engine box makes daily hassle easier and faster for users.

  • Page 11: System Specifications

    OPS860-HM User’s Manual System Specifications 1.2.1 Main CPU Board  The OPS860-HM has four reference solutions as CPU socket type. Customer can choose what they need.  Intel® Core™ i5-2510E Processor (3M Cache, 2.5 GHz)  Intel® Core™ i3-2330E Processor (3M Cache, 2.2 GHz) ...

  • Page 12: I/O System

    OPS860-HM User’s Manual 1.2.2 I/O System  Standard I/O  One VGA  Two USB ports 2.0  1 x Power on /Off button  1 x reset button  Ethernet  10/100/1000Mbps Ethernet  Audio  Line-out/ Mic-in  Expansion ...

  • Page 13: Mechanical Assembly

    OPS860-HM User’s Manual Mechanical Assembly 1.3.1 Dimensions This diagram shows you dimensions and outlines of the OPS860- The overall dimension of the module including the mounting frame is 200mm x 119mm x 30mm and also shows the location of the front panel screw holes as well as the security lock.

  • Page 14: I/O Out Let

    OPS860-HM User’s Manual 1.3.2 I/O out let The following figures show you the locations of the OPS860-HM I/O outlets. Connector Connector Audio(Line-out) 2.5’’HDD slot USB 2.0 x2 Audio(Mic.-in) Ethernet Power indicator HDD indicator Power Switch JAE TX-25 Reset Optional Antenna Introduction...

  • Page 15: Mechanical Specifications

    OPS860-HM Docked in the Reference Display Panel The OPS 860 Pluggable Module docked at a display panel system. In this reference design, the module is docked and undocked in the vertical direction. NOTE: Please contact Axiomtek for available option display panel. Introduction...
  • Page 16 OPS860-HM User’s Manual  Exploded View of the Pluggable Module  The Guide Rail Mechanism for the OPS860-HM Module You can use the rails along side of OPS860-HM Module to dock and undock the plug connector at the back of the module to connect with docking board.
  • Page 17 OPS860-HM User’s Manual  Location of Lock Hole on the Pluggable Module *The drawing is base on Intel Open Pluggable Specification Introduction...
  • Page 18 OPS860-HM User’s Manual  Dimensions of the Guide Rail Introduction...
  • Page 19 OPS860-HM User’s Manual  Location of JAE TX25 Plug Connector Please refer to the following drawing for location of the JAE TX25 plug connector. Pin 1 of the connector is located at 114.8 mm from the edge of the module, and 106.9 mm from the inner side of the front panel.

  • Page 20: Reference Design

    OPS860-HM User’s Manual 1.3.4 Reference Design Display Panel Rear View – Internal The digital signage OPS860-HM prototype is based on a 32” display panel with the functional blocks illustrated in Figure 18. It is mainly a 3-board partitioning design consisting of the pluggable module, docking board and the panel control board.

  • Page 21: Package List

    HDD Mylar x 1  THERMAL GREASE(Syringe 1G)  M3 x 4 screw x 2  M4 x 6 screw x 2 If you can not find the package or any items are missing, please contact Axiomtek distributors immediately. Introduction...
  • Page 22 OPS860-HM User’s Manual MEMO : Introduction...

  • Page 23: Chapter 2 Hardware Installation

    OPS860-HM User’s Manual CHAPTER 2 HARDWARE INSTALLATION OPS860-HM convenient your various hardware configurations, such as HDD (Hard Disk Drive), Memory Module. The chapter 2 will show you how to install the hardware. It includes:  CPU, Hard disk Drive and DRAM Installation ...
  • Page 24 OPS860-HM User’s Manual NOTE Please pull out power cable of system fan while installation Hardware Installation...
  • Page 25 OPS860-HM User’s Manual Step 2 Install CPU Step 2.1 Loosen the screws of CPU socket Hardware Installation...
  • Page 26 OPS860-HM User’s Manual Step 2.2 Insert the CPU in to the slot. Please follow the indication on CPU as mark and slot to ensure the proper insertion of the CPU Step 2.3 CPU is inserted into the socket and the latch is closed. Hardware Installation...
  • Page 27 OPS860-HM User’s Manual Step 3 Install DRAM Step 3.1 Loosen the screws on the real of chassis as illustrated. Step 3.2 After losing the screws, extract the real of chassis out of the module. Hardware Installation...
  • Page 28 OPS860-HM User’s Manual Step 3.3 Install DRAM module. Put DRAM. Place the memory module into the socket and press it firmly. The socket latches are levered upwards and clipped on to the edges of the DIMM. Step 4 Install Wireless Modules The OPS860-HM provides one Mini card slot for user to install one wireless LAN card.
  • Page 29 OPS860-HM User’s Manual Step 4.1 Please refer to Step 1 to loosen the screws of the chassis and PCB board. Turn over the PCB board Step 4.2 Install Wi-Fi module. Place the Wi-Fi module into the socket and press it firmly down until it is fully located. Hardware Installation...
  • Page 30 OPS860-HM User’s Manual Step 4.3 Find the Antenna cable and connect it wireless LAN card. Screw the antenna connector at expansion I/O side and Install the antenna on the wireless LAN card  The wireless Module with one antenna application : ...
  • Page 31 OPS860-HM User’s Manual Step 5 Install HDD drive To enable future remove of HDD drive affix the HDD Mylar sheet to the HDD drive so that it extends past the length of the HDD at the opposite end of the HDD to the Connector Step 5.1 Loosen the screw of HHD driver cover Step 5.2 Affix the HHD Mylar sheet to the HDD drive Hardware Installation...
  • Page 32 OPS860-HM User’s Manual Step 5.3 Plug HDD drive in to HDD connector Hardware Installation...
  • Page 33 OPS860-HM User’s Manual Step 5.4 Pull the HDD Mylar to slot-out the HDD drive Hardware Installation...

  • Page 34: Pluggble Module Method

    OPS860-HM User’s Manual Pluggble Module Method NOTE Please contact Axiomtek for the available option display Step 1 Pluggable the box into display Step 2 Fasten the screws as illustrated Hardware Installation...

  • Page 35: Chapter 3 Connectors

    OPS860-HM User’s Manual CHAPTER 3 CONNECTORS This chapter provides users with detailed description how to set up basic system configuration through the AMIBIOS8 BIOS setup utility. Connectors Connectors connect this board with other parts of the system. Loose or improper connection might cause problems. Make sure all connectors are properly and firmly connected.
  • Page 36 OPS860-HM User’s Manual Connectors...

  • Page 37: Jae Tx25 Connector (Cn1)

    OPS860-HM User’s Manual 3.1.1 JAE TX25 Connector (CN1) Connector JAE TX25 CN1 is for JAE interface support. Signal Signal Signal DDP_3N DDP_3P DDP_2N DDP_2P DDP_1N DDP_1P DDP_0N DDP_0P DDP_AUXN DDP_AUXP DDP_HPD TMDS_CLK- TMDS_CLK+ TMDS0- TMDS0+ TMDS1- TMDS1+ TMDS2- TMDS2+ DVI_DDC_DATA DVI_DDC_CLK DVI_HPD +12V~+19V...
  • Page 38 OPS860-HM User’s Manual Signal Signal Signal USB_PP2 USB_PN1 USB_PP1 USB_PN0 USB_PP0 LINEOUT_L LINEOUT_R PB_DET (Optional For CEC) PS_ON# PW R_STATUS Connectors...

  • Page 39: Cpu Fan (Cn3)

    OPS860-HM User’s Manual 3.1.2 CPU FAN (CN3) Description Connectors...

  • Page 40: Display Port Connector (Cn4)

    OPS860-HM User’s Manual 3.1.3 Display Port Connector (CN4) CN4 is a standard Display Port Connector co-layout with CN7 (Optional) Signal DPB_LANE0 DPB_LANE0# DPB_LANE1 DPB_LANE1# DPB_LANE2 DPB_LANE2# DPB_LANE3 DPB_LANE3# Detect Pin DPB_AUX DPB_AUX# DPB_HPD +3.3V Connectors...

  • Page 41: Vga Port (Cn7)

    OPS860-HM User’s Manual 3.1.4 VGA Port (CN7) DB15 CRT Connector (CN7) Co-layout with CN4 CN7 is a DB15 connector commonly used for the CRT Monitor. Signal Signal Signal Green Blue DETECT DDC DATA Horizontal Sync Vertical Sync DDC CLK Connectors...

  • Page 42: Min Card Slot (Scn1)

    OPS860-HM User’s Manual 3.1.5 Min Card Slot (SCN1) Signal Signal Signal RVD1 WAKE# +3.3VAUX RVD2 +1.5V CLKREQ# RVD19 RVD18 REFCLK- RVD16 REFCLK+ RVD15 RVD14 RVD3 RVD4 +3.3VAUX PERST# PERN0 +3.3VAUX PERP0 +1.5V SMB_CLK PETN0 SMB_DATA PETP0 USB_D- RVD5 USB_D+ +3.3VAUX +3.3VAUX LED_WWAN# RVD8...

  • Page 43: Battery 2 Pin (Bat1)

    3.1.7 ATX Auto Power ON/ Clear CMOS (SW1) Auto On Clear Normal Remark: The product which is shipped after 12/20/2011 is with the setting shown below. If you are not sure which date you received your product, please contact Axiomtek. Connectors...

  • Page 44: Rj45 (Wg82579Lm) (Lan1)

    OPS860-HM User’s Manual 3.1.8 RJ45 (WG82579LM) (LAN1) The RJ-45 connector LAN1 is for Ethernet. To connect the board to 100-Base-T or 1000-Base-T hub, just plug one end of the cable into LAN1 and connect the other end (phone jack) to a 100-Base-T hub or 1000-Base-T hub.

  • Page 45: Chapter 4 Drivers Installation

    OPS860-HM User’s Manual CHAPTER 4 DRIVERS INSTALLATION System OPS860-HM supports W indows XP, W in Vista and W indow 7. To facilitate the installation of system driver, please carefully read the instructions in this chapter before start installing. Insert Intel Express Installer Driver CD and select the “\Driver\”.
  • Page 46 OPS860-HM User’s Manual MEMO: Drivers Installation...

  • Page 47: Chapter 5 Ami Bios Setup Utility

    OPS860-HM User’s Manual CHAPTER 5 AMI BIOS SETUP UTILITY This chapter provides users with detailed description h ow to set up basic system configuration through the AMIBIOS8 BIOS setup utility. Starting To enter the setup screens, follow the steps below: ...
