2 Installation of M.2 Device

Step 1 Turn off the system and unplug the power cord.

Step 2 Turn the system upside down to locate screws at the bottom

and then loosen all screws.

Step 3 Open the TOP cover.

Step 4 Located the M.2 socket on main board.

Step 5 Identify the M.2 slot, insert a M.2 module into the socket and

then fasten a screw.

Step 6 Put the TOP cover and fasten four screws back onto the system.

Version A1 October 2018

Printed in Taiwan

9412K501000E

DSP501-527 Quick Installation Guide

Packing List

System Unit x 1

60W power adapter x 1

Quick Installation Guide x 1

Do not try to apply power to the system if any damaged components.

Dimensions

Version A1 October 2018

Printed in Taiwan

9412K501000E
