- Page 1 DSP511 Quick Installation Guide Packing List System Unit x 1 84W power adapter x 1 ➢ Do not try to apply power to the system if any damaged components. Dimensions © Copyright 2021 Axiomtek Co., Ltd. Version A1 December 2021 Printed in Taiwan...
- Page 2 USB 3.2 USB 2.0 RS-232 4x HDMI Clear EDID button GbE LAN Reset button 2.5GbE LAN Power button Audio jack Remote power switch (line_out/Mic_in) Device management port © Copyright 2021 Axiomtek Co., Ltd. Version A1 December 2021 Printed in Taiwan...
- Page 3 Step 4 Insert a gold-colored contact into the socket and push the module two end latches till locked of the DRAM Step 5 Put the DRAM cover and fasten one screw back into the system. © Copyright 2021 Axiomtek Co., Ltd. Version A1 December 2021 Printed in Taiwan...
- Page 4 Step 4 Identify the M.2 M Key slot, insert a SSD module into the socket and then fasten a screw. Step 5 Put the TOP cover and fasten four screws back into the system. © Copyright 2021 Axiomtek Co., Ltd. Version A1 December 2021 Printed in Taiwan...
