VLAN ID
Priority
Port
IPv4 Protocol Type
IPv6 Protocol Type
4 . 1 . 1 . 1 E t h e r n e t W
4 . 1 . 1 . 1 E t h e r n e t W
How to add a new WAN profile:
1. If the router is under Basic mode, you have to switch into Advance mode. If the router
is under Advance mode, go to Step 4 directly.
2. A confirmation dialog will appear. Click OK to apply the related settings for Advance
mode.
3. Re-login the system.
4. Open WAN>>General Setup. Click the Add button to open the following dialog.
Different protocol type selected will bring up different configuration web page.
this field. Otherwise, Disable will be shown instead.
Display the VLAN ID of the profile.
Display the level of the priority for such profile.
Display the physical WAN interface for such profile.
Display the IPv4 protocol selected by the profile.
Display the IPv6 protocol selected by the profile.
A N P r o f i l e s
A N P r o f i l e s
