Static Route - Draytek Vigor2960 Series User Manual

4. Enter all the settings and click Apply. The new profile will be added on the screen.
4 . 2 . 4 S t a t i c R o
4 . 2 . 4 S t a t i c R o
When there are several subnets in LAN, a more effective and quicker way for connection is
static route rather than other methods. Simply set rules to forward data from one specified
subnet to another specified subnet.
4 . 2 . 4 . 1
4 . 2 . 4 . 1
Each item will be explained as follows:
Item
Add
Edit
Delete
Refresh
Rename
Vigor2960 Series User's Guide
u t e
u t e
S t a t i c R o u t e
S t a t i c R o u t e
Description
Add a new static route setting.
Modify the selected static route setting.
To edit static route setting, simply select the one you want to
modify and click the Edit button. The edit window will
appear for you to modify the corresponding settings for the
selected rule.
Remove the selected static route setting.
To delete a static route setting, simply select the one you
want to delete and click the Delete button.
Renew current web page.
Allow to modify the selected profile name.
109
