4 . 3 . 3 A d d r e s s
4 . 3 . 3 A d d r e s s
This page is used to map specific private IP to specific WAN IP alias.
If you have "a group of IP Addresses" and want to apply to the router, please use WAN IP
alias function to record these IPs first. Then, use address mapping function to map specific
private IP to specific WAN IP alias.
For example, you have IP addresses ranging from 86.123.123.1 ~ 86.123.123.8. However,
your router uses 86.123.123.1, and the rest of the IPs are recorded in WAN IP alias. You
want that private IP 192.168.1.10 can use 86.123.123.2 as source IP when it sends packet out
to Internet. You can use address mapping function to achieve this demand. Simply type
192.168.1.10 as the Private IP; and type 86.123.123.2 as the WAN IP.
Each item will be explained as follows:
Item
Add
Edit
Delete
Refresh
Move Up
Move Down
Rename
Profile
Vigor2960 Series User's Guide
M a p p i n g
M a p p i n g
Description
Add a new DMZ host profile.
Modify the selected profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
rule.
Remove the selected profile.
To delete a profile, simply select the one you want to delete
and click the Delete button.
Renew current web page.
Change the order of selected profile by moving it up.
Change the order of selected profile by moving it down.
Allow to modify the selected profile name.
Display the name of the profile.
137
