Grand Rapids, Michigan, U.S.A. 49504-5298
USER'S OPERATING AND INSTRUCTION MANUAL
MODEL 704-N
BUN/BAGEL SLICER
704
S20000-C1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 704-N and is the answer not in the manual?

Questions and answers

Summary of Contents for Oliver 704-N

  • Page 1 Grand Rapids, Michigan, U.S.A. 49504-5298 USER’S OPERATING AND INSTRUCTION MANUAL MODEL 704-N BUN/BAGEL SLICER S20000-C1...
  • Page 2: Table Of Contents

    INDEX Section Description Document No. Page No. SAFETY INSTRUCTIONS-------------------- 0704S20002 ----------------------------------- 1-1 SLICER SPECIFICATIONS------------------ 0704S20003 ----------------------------------- 2-1 Description ----------------------------------------------------------------------------------------- 2-1 Specifications -------------------------------------------------------------------------------------- 2-1 Product Capacities ------------------------------------------------------------------------------- 2-2 ADJUSTMENTS -------------------------------- 0704S20004 ----------------------------------- 3-1 Outside Side Guide ----------------------------------------------------------------------------- 3-1 Table Height --------------------------------------------------------------------------------------- 3-1 Inside Side Guide -------------------------------------------------------------------------------- 3-1 Slow-Down Door --------------------------------------------------------------------------------- 3-2 OPERATING INSTRUCTIONS -------------- 0704S20005 ----------------------------------- 4-1...
  • Page 3 THIS PAGE WAS INTENTIONALLY LEFT BLANK. GEN020319...
  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS WARNING VARIOUS SAFETY DEVICES AND METHODS OF GUARDING HAVE BEEN PROVIDED ON THIS MACHINE. IT IS ESSENTIAL HOWEVER THAT MACHINE OPERATORS AND MAINTENANCE PERSONNEL OBSERVE THE FOLLOWING SAFETY PRECAUTIONS. IMPROPER INSTALLATION, MAINTENANCE, OR OPERATION OF THIS EQUIPMENT COULD CAUSE SERIOUS INJURY OR DEATH. 1.
  • Page 5: Description

    These bun/bagel slicers have welded steel frames and stainless steel chutes. They are compact, durable machines for counter top use in slicing a variety of buns or bagels with speed and economy. SPECIFICATIONS • Machine dimensions: Model 704-N • Weight: Approximately 100 pounds. • Standard Color: Gloss white enamel.
  • Page 6: Product Capacities

    PRODUCT CAPACITIES • Maximum Product Size: 6-3/4 inches Wide and 3 inches High • Blade Height (adjustable): 5/8 inch to 1-1/2 inches • Maximum Cutting Depth: 6 inches 0704S20003...
  • Page 7: Adjustments

    ADJUSTMENTS WARNING NEVER ATTEMPT TO ADJUST OR SERVICE THIS MACHINE UNTIL YOU ARE SURE THE BLADE HAS STOPPED. OUTSIDE SIDE GUIDE This guide is used to determine the amount of "Hinge" left on the product and can be adjusted from leaving approximately a 3/4" hinge to a complete sever. The guide is adjusted by loosening the two knobs which are below and to the outside of the table and by sliding the guide in or out to generate the desired amount of hinge.
  • Page 8: Slow-Down Door

    INSIDE SIDE GUIDE ADJUSTMENT (Continued) If it seems necessary to adjust this guide loosen the two knobs which are on the top and to the inside of the table, then slide the guide in or out to conform with product width. Make a liberal adjustment to allow for product variances.
  • Page 9: Operating Instructions

    OPERATING INSTRUCTIONS After adjustments for product width and bottom slice height have been made, (see adjustment section), you are ready to begin slicing your product. Start the motor by turning the switch to the "ON" position, then place the product on the chute and allow it to slide into the blade, (do not throw the product into the machine).
  • Page 10: Maintenance/Cleaning/Lubrication

    MAINTENANCE/CLEANING/LUBRICATION WARNING NEVER ATTEMPT TO CLEAN OR SERVICE THIS MACHINE UNTIL IT HAS BEEN DISCONNECTED FROM THE POWER SUPPLY AND YOU ARE SURE THE BLADE HAS STOPPED. ALSO REMEMBER TO USE CARE WHENEVER YOU ARE WORKING NEAR THE BLADE. MAINTENANCE Other than normal cleaning and occasional blade replacement little other regular maintenance is required.
  • Page 11: Lubrication

    CLEANING (continued) The BLADE should be cleaned at least daily and may be cleaned in place, the maintenance person should wear cut resistant gloves to prevent injury. More frequent cleaning of the BLADE is required when cutting fruity or sticky breads. CAUTION ATTEMPTING TO SLICE PRODUCT WITH A DIRTY BLADE MAY CAUSE MOTOR OVERLOADS -- CLEAN THE BLADE FREQUENTLY.
  • Page 12: Changing The Blade

    CHANGING THE BLADE WARNING NEVER ATTEMPT TO CLEAN OR SERVICE THIS MACHINE UNTIL IT HAS BEEN DISCONNECTED FROM THE POWER SUPPLY AND YOU ARE SURE THE BLADE HAS STOPPED. ALSO REMEMBER TO USE CARE WHENEVER YOU ARE WORKING NEAR THE BLADE. CHANGING THE BLADE •...
  • Page 13: Trouble Shooting

    TROUBLE SHOOTING WARNING NEVER ATTEMPT TO CLEAN OR SERVICE THIS MACHINE UNTIL IT HAS BEEN DISCONNECTED FROM THE POWER SUPPLY AND YOU ARE SURE THE BLADE HAS STOPPED. THE SLICER MOTOR WILL NOT START OR WAS RUNNING BUT SUDDENLY STOPPED. •...
  • Page 14: Assembly Drawing

    ASSEMBLY DRAWING 704-N Rev. 11/27/02 0704S20009...
  • Page 15: Parts List

    Joint-Wire 5768-1239 Screw-Hex Hd. Cap 3/8-16 X 3/4 5843-1052 Washer-3/8 Lock Stainless 5851-9359 Enclosure-Switch 0705-0008-1 Screw-Mach 8-32 X 1/2 5843-5225 Light-Pilot (115v) 5709-0190 Light-Pilot (220v) 5709-0191 Rev. 7/7/04 Continued To obtain Replacement Parts call Oliver Products Company at 1-800-253-3893 0704S20010...
  • Page 16 5709-3042 Starter-Manual 4–6.3A (1-50/60-220/230) 5709-3041 Cord-Power (1-60-115) 5765-8300 Cord-Power 9 Ft. (1-50/60-220-230) 5765-8331 Nut-Lock 5766-7750 Wire-Ground 0619-0020 Screw-Round Hd. #10-24 X 3/8 5843-5237 Washer-#10 Lock 5851-9394 Cap-Plug (1-60-230) 5765-2030 To obtain Replacement Parts call Oliver Products Company at 1-800-253-3893 0704S20010...
  • Page 17: Wiring Diagrams

    WIRING DIAGRAMS Wiring Diagram (1/2 HP, 1Ph, 60 Hz, 115 VAC) Diagram No. 0704C12012 Wiring Diagram (1/2 HP, 1Ph, 60 Hz, 230 VAC) Diagram No. 0704C120013 0704S20011 10-1...
  • Page 18 Rev. 7/7/04 Wiring Diagram (1/2 HP, 1Ph, 50 Hz, 220 VAC) Diagram No. 0704C12009 Rev. 7/7/04 0704S20011 10-2...
  • Page 19 Oliver) proves to be defective (as defined below) within one year after shipment, and if Buyer returns the defective part to Oliver within one year, Freight Prepaid to Oliver’s plant in Grand Rapids, MI, then Oliver, shall, at Oliver’s option, either repair or replace the defective part, at Oliver’s expense.
  • Page 20 THIS PAGE WAS INTENTIONALLY LEFT BLANK. GEN020319...
  • Page 21 4. The service dealer will then complete an invoice and send it to the Customer Service Department at Oliver Products Company. 5. The Customer Service Manager of Oliver Products Company will review the invoice and returned parts, if applicable, and approve for payment.
  • Page 22 THIS PAGE WAS INTENTIONALLY LEFT BLANK. GEN020319...
  • Page 23 This policy applies to all parts returned to the factory whether for warranted credit, replacement, repair or re-stocking. Oliver Products Company requires that the customer obtain a Return Material Authorization (RMA) number before returning any part. This number should appear on the shipping label and inside the shipping carton as well.
