Sun Microsystems Sun StorEdge Installation Manual page 41

PCI Edge Connector Pin Definitions, 32-Bit Cards(Bottom)
TABLE A-7
Pin Description
1 TRST
2 +12V
3 TMS
4 TDI
5 +5V
6 INTA
7 INTC
8 +5V
9 RESERVED
10 +5V
11 RESERVED
12 KEYWAY
13 KEYWAY
14 RESERVED
15 RST
16 +5V
17 GNt
18 GND
19 RESERVED
20 AD30
21 +3.3V
Pin Description Pin
22 AD28 43
23 AD26 44
24 GND 45
25 AD24 46
26 IDSEL 47
27 +3.3V 48
28 AD22 49
29 AD20 50
30 GND 51
31 AD18 52
32 AD16 53
33 +3.3V 54
34 FRAME 55
35 IGND 56
36 TRDY 57
37 GND 58
38 STOP 59
39 +3.3V 60
40 SDONE 61
41 SBO 62
42 GND
Description
PAR
AD15
+3.3V
AD13
AD11
GND
AD09
KEYWAY
KEYWAY
C_BE0
+3.3V
AD06
AD04
GND
GND
AD02
+5V
REQ64
+5V
+5V
Appendix A Specifications 19
