jablotron JA-63 „Profi“ User Manual

2.9 Subsystem arming
In a large building a sub control panel can be enrolled to the JA-63. The
subsystem reports all alarms and failures to the main system.
The installer can program if the systems will be armed and disarmed separately
(by their own codes and remote controls) or if the main control panel will rule the
sub control panel. Ask your installer for explanation on how to operate your
system if a sub control is panel installed.
2.10 Appliance control
The system can be used to control an electrical appliance (light, heating,
ventilation etc.). In such a case users can operate the device:
Locally with keypad* – entering F81 (ON) or F80 (OFF).
Remotely by phone keypad or by SMS messages – the control panel
must be equipped with GSM communicator for this feature
*
Installer can program that this feature will work only when the entry is followed by a user code.
3 User's settings
Following section is designated for the system supervisor, who knows the
master code.
All programming sequences can be terminated before completed (by N key).
3.1 New master code
The master code is used by the supervisor. The factory default master code is
1234 and you should program your own four digits code. Code programming is only
possible when the system is disarmed.
To change an existing master code enter:
F 5
where xxxx is the existing and yyyy is the new master code (new code must be
entered twice to avoid an error).
Example:
Existing code 1234 will change to 6723 entering: F 5 1234 6723 6723
Alarm system JA-63 „Profi"
xxxx yyyy yyyy
- 8 -
3.2 User codes setting
There can be up to 14 different user codes for individual users. The system stores
to its memory which code was used for what event and when. This data can go to a
Central monitoring station as well and can also be viewed by a PC with Comlink
software.
All user codes are empty as a factory default and the supervisor should program
them entering:
where xxxx is the master code, yy is the user code index (from 01 to 14) and
zzzz is the new user code.
Example:
If the master code is 1234 and the user 3 new code should be 5277 enter:
To delete a particular user code, enter 0000 as the new code (combination
0000 can not be used as a valid code).
Example:
If the master code is 1234 the user 3 code can be deleted by:
Notes:
•
You can program new codes only when the system is disarmed.
•
The supervisor should record the codes to the table on last page of this
manual (it should be kept hidden in a safe place).
•
•
If the system is split, the supervisor can change the user codes, but can
not change to which section the particular code belongs (only the installer
can change this).
3.3 Internal clock setting
The control panel has a built in real time clock. All events are stored to the event
memory including the time & date. The clock should be set after installation, but
the supervisor can set the clock while in the user mode.
To switch the control panel to the user mode enter F 0 master code. User
mode will be indicated by a U on the keypad. To set the clock enter:
where: hh = hours; mm = minutes; DD = day; MM = month and YY = year
Example: at 21:30 on March 19. 2005 enter:
To exit user mode press N.
MGK51503 Alarm system JA-63 „Profi"
F 6 xxxx yy zzzz
F 6 1234 03 5277
F 6 1234 03 0000
4 hh mm DD MM YY
4 21 30 19 03 04
- 9 - MGK51503
