4 Windows Utility
Figure 32: USB Ports and LED
Tech Note NetUSB-400i only: On top of each USB port is a green LED light (for a total of 4
lights). These LED lights indicate whether or not your USB device is supported in the current
software/firmware.
If your device is supported, you will have a solid green light when the device is logically connected
using USBIP Admin Utility on any of the client machine on network.
If the device is not supported the LED will not glow even if the Device is tried to connect using
USBIP Admin Utility on any of the client machine on network.
Note: Any device is to be disconnected or unplugged only after proper closure of related applica-
tions.

4.4.2 Automatic functions per USB Device

The USBIP Admin Utility allows to perform some actions automatically, once a USB device is
plugged into the NetUSB-400i USB Server. To enable and configure these options, right-click on
the device in the Device mapping Window and select Settings option (figure 33). These options are
effective once the Device Mapping is started / initiated on your PC client.
Figure 33: Device Settings Option
A dialog appears with the name of the selected device (figure 34).
October 2009 NetUSB-400i User Manual 24
