4 Windows Utility
4.1.1 Server Configuration
The Server Manager has an option to change Server Configuration settings through USBIP Admin
Utility. To open the server configuration window select the the NetUSB-400i USB Server displayed
on the Server Manager Main window and click the Server Configuration button. You may also
right-click on the server and select the Server Configuration option (figure 13), or use the function
via Server Manager in the Menu bar.
Figure 13: USBIP Select Server Configuration
Now the Server Configuration window (figure 14) pops up, with the parameters to configure.
Figure 14: USBIP Server Settings
Once the configuration change is completed, click on the Save button. Then USBIP Admin Utility
shows a progress bar for some time and after that a message box (Figure 15) pops up.
Figure 15: USBIP Configuration OK
October 2009 NetUSB-400i User Manual 14
