4 Windows Utility

4.1.3 Restore factory Defaults

Right click on the USB Server in the Server Manager Window and select the Restore Factory Defaults
function to obtain the manufacturers Default settings as shown below. Or use this function via
Server Manager in the Menu bar.
Then USBIP Admin Utility pops up a window asking to continue or not. If you select the OK
button it will set the NetUSB-400i to manufacturer's default settings.
The Restore Factory default settings can also be implemented by pressing the Default button
(section 6.2) for ten seconds.
4.2 Quick Configuration Utility (Search USB Server by MAC-ID)
Each USB Server has a unique MAC-ID, and can be searched and configured even if the Server is
not yet configured in the same network (i.e. the IP Settings do not match your PC configuration).
The Search by MAC ID Quick configuration utility enables the user to search the box by its MAC-
ID. With this feature, one can detect and configure the IP Settings of the NetUSB-400i USB Server
that is present in the same physical network (same LAN).
Note: This feature will not identify or configure the NetUSB-400i USB Servers, which are behind
the Router (across the networks).
Right Click on the Server Manager Icon or the Server Manager Window and Select Search by MAC ID
to launch the quick configuration utility (figure 25).
October 2009
Figure 23: USBIP Restore Factory Defaults
Figure 24: USBIP Restore OK
NetUSB-400i User Manual 19
