Menu Level 1 Menu Level 2
SPEC. rdML
rdMH
Adj.
rAdI*
uPd.
* Only for wireless DMX version

6. Fixture menu

The control panel menu allows to set the fixture according to your needs, obtain information on its operation, test
its various parts and lastly program it, if it has to be used in a Stand-alone mode.
The four control buttons on the front have the following functions:
- ESCAPE button-leaves menu without saving changes.
- ENTER button- enters menu, confirms adjusted values and leaves menu.
- UP and - DOWN buttons - move between menu items on the same level, sets values.
After switching the fixture on, the fixture display shows the current DMX address:
Use the UP/DOWN buttons to scroll through the various menu items. To select desired item, press the ENTER.

6.1 Fixture Address

Use this menu to set the DMX address of the fixture or set the fixture as a Master (Slave).
dM.Ad. --- DMX addressing. Select this submenu to set a DMX start address.
To set a DMX address.
1. Use the UP/DOWN buttons to find " A001" menu.
2. Press the ENTER button.
3. Use the UP/DOWN buttons to select desired start address.
CitySource 96 (SmartWhite)
Menu Level 3 Menu Level 4
DMH WWh.1
:
F.dimr
CaL.U. WWh.1
:
CWh.2
Stor.
r.InF. No.LI (0-100)
r.UnL.
14
Menu Level 5 Menu Level 6
S.tim. 0-25.5 sec
CoPY
