8. Wireless DMX operation

The wireless version of the CitySource 96 is equipped with the Lumen Radio CRMX module and antenna for
receiving DMX signal. CRMX module operates on the 2.4 GHz band.
To link the fixture with DMX transmitter.
The fixture can be only linked with the transmitter by running the link procedure at DMX transmitter .
After linking , the level of DMX signal ( 0-100 %) is displayed in the menu item "r.InF" (SPEC-->rAdI.--> r.InF.)
To unlink the fixture from DMX transmitter.
The fixture can be unlinked from receiver via the menu item " r.UnL." (SPEC-->rAdI.--> r.UnL.).

9. Error and information messages

t.M.Er.(Temperature measuring error)
The message informs you that the LED module temperature sensor is defective.
MA.Er. (Master error)
The fixture is set as a master and DMX console is connected to the fixture.

10. Technical specifications

Power supply
• Electronic auto-ranging
• Input voltage: 100 - 240V AC, 50-60 Hz
• Fuse: T3.15 A H
• Power consumption:
Power
mode
Full mode
Eco mode
Optic & Effects
• Light source: 96 Luxeon Rebel LEDs (WW,CW)
• Optical system: 12° standard lens-array, 25° egg-crate module included;
45°and 45°x15°egg crate modules optionally available
• Fitting of additional frost foil filters
• Adjustable strobe sequences
•Lumen maintenance:
Channels @
full intensity
Two LED
channels
All LED
channels
L = 70% maintenance of initial lumen output in hours
70
Control
• 4-digit LED display and four control buttons
• USITT DMX 512 (RDM support)
• DMX protocol modes: 4 (2, 5, 7 control channels)
• Control: DMX 512, RDM support
CitySource 96 (SmartWhite)
Max. power consumption
(All LED channels at full)
200W (225VA)
115W (140VA)
Power L
mode
Full mode 70,000
Eco mode 80,000
Full mode 60,000
Eco mode 70,000
Typical power consumption
( 2 LED Channels at full)
145W
100W
70
21
Ambient
Temperature
25°C
