Attaching the Regulatory Label
007-4506-001
If you received a system upgrade label with your Duo kit, place it on the Octane2 system
label, as follows:
1.
Face the back of the Octane2 workstation. The system label (containing the model
number/CMN number) is located at the top center of the back of the workstation,
as shown in Figure 3-1.
2. Place the upgrade label over the VCCI and CISPR 22 information.
R
L
In Out
2
1
Figure 3-1
Locating the System Label
Proceed to Chapter 4 to connect the second keyboard and mouse.
Attaching the Regulatory Label
System label
15
