ADJ FREQ Matrix User Instructions page 6

FREQ Matrix
power is applied or the DMX signal is lost.
• MASL (Master Slave) - If the DMX signal is lost or power is
applied, the unit will automatically go into Master Slave mode.
• BLND (Blackout) - If the DMX signal is lost or power is applied,
the unit will automatically go into stand by mode.
• LAST (Last State) - If the DMX signal is lost the fixture will stay
in the last DMX set up. If power is applied and this mode is set,
the unit will automatically go into the last DMX set up.
3. Press ENTER to confirm your desired set up.
LED
- With this function the LED display will turn off after
2 minutes.
1. Press the MENU button until "LED" is displayed, press ENTER.
2. Either "ON" or "OFF" will now be displayed. Press the UP or
DOWN buttons to select "ON" to keep the LED display on at all
times, or "OFF" to allow the LED display to turn off after 2 min-
utes. Press any button to turn the LED display on again.
3. Press ENTER to confirm your selection.
DISP
- This will "flip" the LED display
1. Press the MENU button until "DISP" is displayed, press
ENTER.
2. When "DISP" is displayed the LED display will remain normal,
when "DSIP" is displayed, the LED display will be "flipped".
Use the ENTER button to find your desired display set up, then
press MENU to confirm and exit.
TEST
- This function will run a self test program.
1. Press the MENU button until "TEST" is displayed, press
ENTER.
ADJ Products, LLC - www.adj.com - FREQ Matrix Instruction Manual Page 11
System Menu FREQ Matrix
2. The fixture will now run a self test. Press the MENU button to
exit.
TEMP
perature of the fixture.
1. Tap the MENU button until "TEMP" is displayed, press
ENTER.
2. The current temperature of the fixture will now be displayed.
Press MENU to exit.
FHRS
time of the unit.
1. Press the MENU button until "FHRS" is displayed, press
ENTER.
2. The running time of the fixture will now be displayed. Press
MENU to exit.
VER
1. Press the MENU button until "VER" is displayed. Press the
ENTER button and the software vesion will be displayed.
2. Press the MENU button to leave this function.
- With this function you can check the current tem-
- With this function you can display the running
- This will display the software version
ADJ Products, LLC - www.adj.com - FREQ Matrix Instruction Manual Page 12
System Menu
