Focal Point POLARIS Installation & User's Instructions

Stone effect decorative gas fire
Hide thumbs Also See for POLARIS:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instructions for Using
INSTALLATION & USER INSTRUCTIONS
STONE EFFECT DECORATIVE GAS FIRE
Focal Point Fires plc.
Christchurch, Dorset BH23 2BT
Tel: 01202 499330
Fax: 01202 499326
www.focalpointfires.co.uk
e : sales@focalpointfires.co.uk
Questions or problems with your appliance?
Don't take it back to the store
01202 588601
just give us a call on
lines open between 9am and 5pm, Monday to Friday
IN THE UK ALWAYS USE A GAS SAFE REGISTERED ENGINEER TO INSTALL, REPAIR OR SERVICE THIS APPLIANCE
Please note : Except where otherwise stated, all rights,
including copyright in the text, images and layout of this
booklet is owned by Focal Point Fires plc. You are not per-
mitted to copy or adapt any of the content without the
prior written permission of Focal Point Fires plc.
MODELS COVERED BY THESE INSTRUCTIONS
POLARIS
we're here to help
1
All instructions must be handed to the user
for safekeeping.
Revision B - 05/13
GB IE
BS EN 509 : 2000
KM579168
2013 Focal Point Fires plc.
'

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POLARIS and is the answer not in the manual?

Questions and answers

Related Manuals for Focal Point POLARIS

Summary of Contents for Focal Point POLARIS

  • Page 1 Focal Point Fires plc. You are not per- mitted to copy or adapt any of the content without the prior written permission of Focal Point Fires plc.

  • Page 2: Table Of Contents

    • Consult ALL instructions before installation and use of this appliance. • This appliance is intended for decorative purposes. • This appliance is free from any asbestos material. • Refractories and fuel bed are constructed from ceramic fibre. 2013 Focal Point Fires plc.

  • Page 3: Appliance Data

    (±2.0 mbar) Natural gas Gross Gross I 2H Polaris 4.95 3.15 GB - IE Specifications Polaris - All models Main burner injector Stereo size 66 Oxypilot SIT 9090 Gas Control Copreci 21400/342 Gas Inlet 8mm compression - Inlet restrictor elbow Ignition...

  • Page 4: Ventilation

    Remove the burner unit from the remaining packaging. Check that the components supplied correlate with the checklist given in section 6.1. Please dispose of the packaging materials at your local recycling centre. 2013 Focal Point Fires plc.

  • Page 5: Installing The Burner

    Similarly, the upper dec- orative trim sits on top of the stone effect body. No additional fixing is required. Fit the upper decorative trim 8.0 FUEL BED LAYOUT Please refer to the relevant section of the user manual. 2013 Focal Point Fires plc.

  • Page 6: Operating The Fire

    The gas pressure reaching the fire must also be checked. The thermocouple connection into the back of the gas control valve may also have worked loose during installation, simply tighten to remedy if this is the case. 2013 Focal Point Fires plc.

  • Page 7: Testing For Spillage

    8. Strip off the burner pipes and clean thoroughly. 9. Clean out the injector and pilot assembly. DO NOT attempt to dismantle the pilot unit. 10. Ensure the injector is aligned squarely in the injector bracket. Re-assemble and re-fit the burner tray. 2013 Focal Point Fires plc.

  • Page 8: Troubleshooting Guide

    Lint in pilot aeration hole, clean thoroughly internally. Fire smells when first lit or in use Newness smell from brand new appliance. Spillage occurring. Carry out spillage test and rectify any problems. Low temperature sealants or combustible materials used in incorrect positions. 2013 Focal Point Fires plc.

  • Page 9: User Instructions

    Any combustible side walls must be at least 500mm to the side of the radiant heat source. As with all heating appliances, any decorations, soft furnishings, and wall coverings (i.e. flock, blown vinyl and embossed paper) positioned too close to the appliance may discolour or scorch. 2013 Focal Point Fires plc.

  • Page 10: Fire Guards

    HIGH or LOW positions, press the control knob in, and return to the nine o’clock position and release. To turn the fire OFF, keep the knob pressed in, return to the off position and release. 2013 Focal Point Fires plc.

  • Page 11: Flue Spillage Monitoring System

    A to M.You will need to select the pebbles in alphabetic order beginning with ‘A’. Place the pebbles marked ‘A’,‘B’ and ‘C’ as shown. The letters are on the bottom of the pebbles and should face downwards. 2013 Focal Point Fires plc.
  • Page 12 Never add to the thirteen pebbles, or change them for a different type. Never throw rubbish or other matter onto the fuel bed. Due to the light colour of the pebbles, some discolouration/sooting is to be expected during normal operation. 2013 Focal Point Fires plc.

  • Page 13: Cleaning

    Do not use polish, wax or solvent based cleaners or detergent as these may stain or discolour the body. 9.0 LIST OF REPLACEMENT PARTS Polaris - All models Item Part number...

  • Page 14: Service History

    3G Service Department to the address below. Alternatively, you can email or fax.Please note that this does not affect your statutory rights. Focal Point Fires plc, 3G Service Department, Reid Street, Christchurch, Dorset, BH23 2BT. Alternatively email: 3g@focalpointfires.co.uk or fax. 01202 499326.
