INSTALLATION & USER INSTRUCTIONS
WALL MOUNTED HIGH EFFICIENCY GAS FIRE
Focal Point Fires plc.
Christchurch, Dorset BH23 2BT
Tel: 01202 499330
Fax: 01202 499326
www.focalpointfires.co.uk
e : sales@focalpointfires.co.uk
Please note : Except where otherwise stated, all rights,
including copyright in the text, images and layout of this
booklet is owned by Focal Point Fires plc. You are not per-
mitted to copy or adapt any of the content without the
prior written permission of Focal Point Fires plc.
MODELS COVERED BY THESE INSTRUCTIONS
L23S MIDNIGHT -
L30S VESUVIUS -
The products covered by this booklet are protected under
patent GB2275331B.
All instructions must be handed to the user for
1
GB IE
F500277
F500276
L23S MIDNIGHT
L30S VESUVIUS
safekeeping.
Revision A - 07/10
©
2010 Focal Point Fires plc.
Advertisement
Table of Contents
Related Manuals for Focal Point L23S MIDNIGHT
Summary of Contents for Focal Point L23S MIDNIGHT
- Page 1 GB2275331B. booklet is owned by Focal Point Fires plc. You are not per- All instructions must be handed to the user for mitted to copy or adapt any of the content without the safekeeping.
-
Page 2: Table Of Contents
• Consult ALL instructions before installation and use of this appliance. This appliance is free from any asbestos material. © © 2010 Focal Point Fires plc. 2010 Focal Point Fires plc. -
Page 3: Appliance Data
400mm (16”) from the top of the appliance inner glass panel and the wall above the appliance is non com- bustible. The appliance must not be positioned vertically within 60mm (2.4”) of a solid floor (i.e. wood or stone) or hearth. This dimension is measured vertically to the bottom of the appliance firebox. © 2010 Focal Point Fires plc. -
Page 4: Ventilation
Please dispose of all the packaging materials at your local recycling centre. 5.1 COMPONENT CHECKLIST QUANTITY DESCRIPTION Firebox and burner assembly Set of manufacturers instructions Decorative facia assembly Screw and wall plug pack Rubber grommet Fitting template © 2010 Focal Point Fires plc. -
Page 5: Gas Supply Routes
Focal Point Fires plc. assumes absolutely no responsibility for injuries and/or damages that load of the appliance. Measures may occur due to improper installation or handling. The appliance should not be installed should also be taken to ensure until all wet plastering and/or dry wall sanding and wall painting has been completed. -
Page 6: Testing And Commissioning
In the event that the burner pressure is not in accordance with the figures stated in the data section of these instructions, the appliance must not be Figure 8 commissioned, and the manufacturer should be contacted for guidance. © 2010 Focal Point Fires plc. -
Page 7: Decorative Frame
13. Check the purpose provided ventilation is un-obstructed. 14. Light the fire and test setting pressures. 15. Check safe operation of the appliance by performing a combustion test as detailed in section 10.3. For specific servicing instructions, see relevant sections. © 2010 Focal Point Fires plc. -
Page 8: Servicing The Burner Unit
100% smoke tight and small quantities of smoke may be seen in corners of joints and gasket faces etc without affecting safety when the fire is in operation. © 2010 Focal Point Fires plc. -
Page 9: Troubleshooting Guide
• Leakage occurring. Carry out leakage test and rectify any problems. • Combustible materials used in incorrect positions. • Airborne substances such as cleaning materials/air fresheners are being drawn through the fire. • Other airborne contaminants such as dust, tobacco smoke, paint vapours. © 2010 Focal Point Fires plc. - Page 10 The minimum clearance to the ceiling above the appliance is 800mm (31.5”) measured from the top of the appliance glass panel. Combustible materials should not be positioned directly in front of the appliance within a distance of one metre. © 2010 Focal Point Fires plc.
- Page 11 Test on a hidden part before cleaning. Clean only in the direction of the grain. GLASS PANEL - This can be cleaned with a suitable glass cleaner. Test on a small area first. PAINTED AREAS - These can be cleaned using a dry cloth. © 2010 Focal Point Fires plc.
- Page 12 Contact details of Engineer As our policy is one of continuous improvement and development , we hope therefore you will understand we must retain the right to amend details and/or specifications without prior notice. © 2010 Focal Point Fires plc.
