X10SRH-CF/
CLN4F
USER'S MANUAL
Revision 1.0a

Advertisement

Table of Contents
loading

Related Manuals for Supero X10SRH-CF

Summary of Contents for Supero X10SRH-CF

  • Page 1 X10SRH-CF/ CLN4F USER’S MANUAL Revision 1.0a...
  • Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.

  • Page 3: About This Motherboard

    This manual is written for system integrators, IT professionals, and knowledgeable end users. It provides information for the installation and use of the X10SRH-CF/CLN4F motherboard. About This Motherboard X10SRH-CF/CLN4F supports a single Intel ® E5-2600/1600 Series Processor in an LGA2011 R3 socket. With the Intel ®...

  • Page 4: Conventions Used In The Manual

    X10SRH-CF/CLN4F User’s Manual Conventions Used in the Manual: Special attention should be given to the following symbols for proper system instal- lation: Warning: Critical information given to prevent damage to the components or injury to yourself. Note: Additional Information provided for correct system setup.

  • Page 5: Contacting Supermicro

    Contacting Supermicro Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel:...

  • Page 6: Table Of Contents

    X10SRH-CF/CLN4F User’s Manual Table of Contents Preface About This Motherboard ....................iii Manual Organization ..................... iii Conventions Used in the Manual ..................iv Contacting Supermicro ....................v Chapter 1 Introduction Overview ......................1-1 Checklist ......................1-1 Motherboard Features ..................1-7 Chipset Overview ..................1-11 Intel C612 Express Chipset Features ............1-11...
  • Page 7 Table of Contents Removing Memory Modules ................. 2-14 Memory Support .................... 2-14 Connectors/IO Ports ..................2-16 Backplane I/O Panel ..................2-16 Universal Serial Bus (USB) ..............2-17 Ethernet Ports ..................2-18 Serial Ports (COM1/COM2)..............2-18 Unit Identifier Switch/UID LED Indicator ..........2-19 VGA Port ....................
  • Page 8 Main Setup ...................... 4-2 The following Main menu items will be displayed: ........4-3 System Date/System Time ................ 4-3 Supermicro X10SRH-CF/CLN4F ..............4-3 Version: This item displays the version of the BIOS ROM used in the system......................4-3 Build Date: This item displays the date when the version of the BIOS ROM...
  • Page 9 Table of Contents used in the system was built..............4-3 Memory Information ................... 4-3 Total Memory: This item displays the total size of memory available in the system......................4-3 Memory Speed: This item displays the default speed of the memory modules installed in the system.
  • Page 10 X10SRH-CF/CLN4F User’s Manual Advanced Power Management Configuration ..........4-8 Power Technology ..................4-8 Chipset Configuration .................4-11 North Bridge ....................4-11 IIO Configuration ..................4-11  Intel VT for Directed I/O (VT-d) ..............4-13 QPI (Quick Path Interconnect) Configuration ..........4-14  South Bridge Configuration ................ 4-17 USB Configuration ..................
  • Page 11 Table of Contents Above 4G Decoding (Available if the system supports 64-bit PCI decoding) 4-24 SR-IOV (Available if the system supports Single-Root Virtualization) ..4-24 Maximum Payload ..................4-25 Maximum Read Request ................4-25 ASPM Support ..................4-25 MMIOHBase ..................... 4-25 MMIO High Size ..................
  • Page 12 X10SRH-CF/CLN4F User’s Manual High Precision Timer ................4-33 NUMA (Available when the OS supports this feature) ......4-33 Event Logs ....................4-34  Change SMBIOS Event Log Settings ............4-34 Enabling/Disabling Options ..............4-34 SMBIOS Event Log .................. 4-34 Runtime Error Logging Support ............... 4-34 Memory Corrected Error Enabling (Available when the item above-Runtime Error Logging Support is set to Enable) ..........
  • Page 13 Table of Contents Boot Mode Select ..................4-39 Fixed Boot Order Priorities ............... 4-39 Add New Boot Option ................4-40 Boot Option File Path ................4-40  Delete Boot Option ................4-40  Hard Disk Drive BBS Priorities ............. 4-41 ...
  • Page 14 X10SRH-CF/CLN4F User’s Manual Notes...

  • Page 15: Chapter 1 Introduction

    Chapter 1: Introduction Chapter 1 Introduction Overview Checklist Congratulations on purchasing your computer motherboard from an acknowledged leader in the industry. Supermicro boards are designed with the utmost attention to detail to provide you with the highest standards in quality and performance. Please check that the following items have all been included with your motherboard.
  • Page 16 X10SRH-CF/CLN4F User’s Manual X10SRH-CF/CLN4F Motherboard Image Note: All graphics shown in this manual were based upon the latest PCB Revision available at the time of publishing of the manual. Your motherboard or components may or may not look exactly the same as the graphics shown in this manual.
  • Page 17 Chapter 1: Introduction X10SRH-CF/CLN4F Motherboard Layout JUIDB1 UID-LED UID-SW 1 2 3 COM1 USB0/1 USB2/3(3.0) i350 LEDM1 JPL1 FAN5 FAN4 IPMI_LAN LAN2/LAN4 LAN1/LAN3 JVR1 USB4/5 USB6/7 USB8/9 BIOS JPS1 JOH1 JL1 CHASSIS INTRUSION JBT1 JBR1 C610 LGA2011-3 X10SRH-CF LEDS1 JPSAS1 REV: 1.00...
  • Page 18 X10SRH-CF/CLN4F User’s Manual X10SRH-CF/CLN4F Quick Reference JUIDB1 UID-LED UID-SW 1 2 3 COM1 USB0/1 USB2/3(3.0) i350 LEDM1 JPL1 FAN5 FAN4 IPMI_LAN LAN2/LAN4 LAN1/LAN3 JVR1 USB4/5 USB6/7 USB8/9 BIOS JPS1 JOH1 JL1 CHASSIS INTRUSION JBT1 JBR1 C610 LGA2011-3 X10SRH-CF LEDS1 JPSAS1 REV: 1.00...
  • Page 19 Chapter 1: Introduction X10SRH-CF/CLN4F Headers/Connectors Connector Description Onboard Battery COM1/COM2 COM1 (Port)/COM2 (Header) Fan1 - Fan5 System/CPU Fan Headers FanA - FanC 24-pin ATX Main Power Connector (Required) Speaker/Buzzer (Pins 1-3: Power LED, Pins 4-7: Speaker) Front Panel Control Header...
  • Page 20 X10SRH-CF/CLN4F User’s Manual X10SRH-CF/CLN4F LED Indicators Description State/Color Status UID LED Blue On Unit Identified Power LED Power On LEDM1 BMC Heartbeat LED Green Blinking BMC Normal Green Blinking SAS Active LEDS1 SAS LED Solid On SAS Error...

  • Page 21: Motherboard Features

    Chapter 1: Introduction Motherboard Features Single Intel ® E5-2600/1600 Series Processor in an LGA2011 R3 socket. Memory Supports DDR4 memory up to 256GB RDIMM or 512GB LRDIMM at 1333/1600/1866/2133MHz on eight (8) DIMM slots. Dual-channel memory DIMM sizes RDIMM 1 GB, 2 GB, 4GB, 8GB, 16GB, 32GB Chipset Intel ®...
  • Page 22 X10SRH-CF/CLN4F User’s Manual Network Intel ® i350 Gigabit Dual-Channel Ethernet controller for LAN1/LAN2 ports (X10SRH-CF) Intel ® i350 Gigabit Quad-Channel Ethernet controller for LAN1/LAN2/LAN3/LAN4 ports (X10SRH-CLN4F) BIOS 128 Mb AMI BIOS ® SPI Flash BIOS Plug and Play (PnP), DMI 2.3, PCI 2.3, ACPI 1.0/2.0/3.0, USB Keyboard and SMBIOS 2.5...

  • Page 23: System Block Diagram

    Chapter 1: Introduction X10SRH-CF Block Diagram VR12.5 5 PHASE 145W Skt-R3 LGA2011-3 DMI2 MINI SAS HD LSI SAS3008 PCI-E X8 Gen3 PCI-E X8 Gen3 PCIe3.0 X16 SLOT6 MINI SAS HD PCI-E X8 Gen3 ( X8 in X16 ) SLOT4 PCIe3.0 x8...
  • Page 24 X10SRH-CF/CLN4F User’s Manual X10SRH-CLN4F Block Diagram VR12.5 5 PHASE 145W Skt-R3 LGA2011-3 DMI2 MINI SAS HD LSI SAS3008 PCI-E X8 Gen3 PCI-E X8 Gen3 PCIe3.0 X16 SLOT6 MINI SAS HD PCI-E X8 Gen3 ( X8 in X16 ) SLOT4 PCIe3.0 x8...

  • Page 25: Chipset Overview

    Direct Media Interface (DMI) for chip-to-chip true isochronous communication, providing up to 5 Gb/s of software-transparent data transfer rate on each read/write direction. In addition, the X10SRH-CF/CLN4F also features a TCO timer which allows the system to recover from a software/ hardware lock and perform tasks, including Function Disable and Intruder Detect.

  • Page 26: Special Features

    X10SRH-CF/CLN4F User’s Manual Special Features Recovery from AC Power Loss Basic I/O System (BIOS) provides a setting for you to determine how the system will respond when AC power is lost and then restored to the system. You can choose for the system to remain powered off, (in which case you must press the power switch to turn it back on), or for it to automatically return to a power-on state.

  • Page 27: Acpi Features

    Chapter 1: Introduction ACPI Features ACPI stands for Advanced Configuration and Power Interface. The ACPI specifica- tion defines a flexible and abstract hardware interface that provides a standard way to integrate power management features throughout a PC system, including its hardware, operating system and application software. This enables the system to automatically turn on and off peripherals such as CD-ROMs, network cards, hard disk drives and printers.

  • Page 28: Super I/O

    X10SRH-CF/CLN4F User’s Manual to shield the computer from noise. It is recommended that you also install a power surge protector to help avoid problems caused by power surges. Super I/O The Super I/O supports two high-speed, 16550 compatible serial communication ports (UARTs).

  • Page 29: Chapter 2 Installation

    Chapter 2: Installation Chapter 2 Installation Standardized Warning Statements The following statements are industry-standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assis- tance.
  • Page 30 X10SRH-CF/CLN4F User’s Manual Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant. Jeter les piles usagées conformément aux instructions du fabricant. ¡Advertencia! Existe peligro de explosión si la batería se reemplaza de manera incorrecta. Re- emplazar la batería exclusivamente con el mismo tipo o el equivalente recomen-...

  • Page 31: Product Disposal

    Chapter 2: Installation Product Disposal Warning! Ultimate disposal of this product should be handled according to all national laws and regulations. 製品の廃棄 この製品を廃棄処分する場合、 国の関係する全ての法律 ・ 条例に従い処理する必要が あり ます。 警告 本产品的废弃处理应根据所有国家的法律和规章进行。 警告 本產品的廢棄處理應根據所有國家的法律和規章進行。 Warnung Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen.

  • Page 32: Static-Sensitive Devices

    X10SRH-CF/CLN4F User’s Manual ‫القىانين واللىائح الىطنية‬ ‫جميع‬ ‫وفقا ل‬ ‫ينبغي التعامل معه‬ ‫هذا المنتج‬ ‫من‬ ‫التخلص النهائي‬ ‫عند‬ 경고! 이 제품은 해당 국가의 관련 법규 및 규정에 따라 폐기되어야 합니다. Waarschuwing De uiteindelijke verwijdering van dit product dient te geschieden in overeenstemming met alle nationale wetten en reglementen.

  • Page 33: Motherboard Installation

    IPMI_LAN LAN2/LAN4 LAN1/LAN3 JVR1 USB4/5 USB6/7 USB8/9 BIOS JPS1 JOH1 JL1 CHASSIS INTRUSION JBT1 JBR1 C610 LGA2011-3 X10SRH-CF LEDS1 JPSAS1 REV: 1.00 DESIGNED IN USA BAR CODE 3008 SAS CODE IPMI CODE JSD2 MAC CODE BIOS LICENSE JSTBY1 JSD1 L-SAS4-7...

  • Page 34: Installing The Motherboard

    X10SRH-CF/CLN4F User’s Manual Installing the Motherboard 1. Install the I/O shield into the back of the chassis. 2. Locate the mounting holes on the motherboard. (See the previous page.) 3. Locate the matching mounting holes on the chassis. Align the mounting holes on the motherboard against the mounting holes on the chassis.

  • Page 35: Processor And Heatsink Installation

    Chapter 2: Installation Processor and Heatsink Installation Warning: When handling the processor package, avoid placing direct pressure on the label area of the fan. Notes: • Always connect the power cord last, and always remove it before adding, re- moving or changing any hardware components. Make sure that you install the processor into the CPU socket before you install the CPU heatsink.
  • Page 36 X10SRH-CF/CLN4F User’s Manual 2. Press the second load lever labeled 'Close 1st' to release the load plate that covers the CPU socket from its locking position. Pull lever away from Press down on Load the socket Lever 'Close 1st' 3. With the 'Close 1st' lever fully retracted, gently push down on the 'Open 1st' lever to open the load plate.
  • Page 37 Chapter 2: Installation 4. Using your thumb and the index finger, loosen the CPU lever and open the load plate. 5. Use your thumb and index finger to hold the CPU on its edges. Align the CPU keys, which are semi-circle cutouts, against the socket keys. Socket Keys CPU Keys 6.
  • Page 38 X10SRH-CF/CLN4F User’s Manual 7. With the CPU inside the socket, inspect the four corners of the CPU to make sure that the CPU is properly installed. 8. Close the load plate with the CPU inside the socket. Lock the lever labelled 'Close 1st' first, then lock the lever labelled 'Open 1st' second.

  • Page 39: Installing A Passive Cpu Heatsink

    Chapter 2: Installation Installing a Passive CPU Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU die -- the re- quired amount has already been applied. 2. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the Motherboard's and the Heatsink Bracket under- neath.

  • Page 40: Removing The Heatsink

    X10SRH-CF/CLN4F User’s Manual Removing the Heatsink Warning: We do not recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the heatsink, please follow the instructions below to prevent damage to the CPU or the CPU socket.

  • Page 41: Installing Ddr4 Memory

    JOH1 JL1 CHASSIS INTRUSION JBT1 the system to work properly, please JBR1 C610 LGA2011-3 use the memory modules of the X10SRH-CF LEDS1 JPSAS1 REV: 1.00 DESIGNED IN USA same type and speed in the same BAR CODE 3008 SAS CODE...

  • Page 42: Removing Memory Modules

    DIMMA2 DIMMC1 DIMMA1 The X10SRH-CF/CLN4F supports DDR4 memory up to 256GB RDIMM or 512GB LRDIMM at 1333/1600/1866/2133MHz on eight (8) DIMM slots. Populating these DIMM modules with a pair of memory modules of the same type and same size will result in interleaved memory, which will improve memory performance. Please...
  • Page 43 Chapter 2: Installation Possible System Memory Allocation & Availability System Device Size Physical Memory Remaining (-Available) (4 GB Total System Memory) Firmware Hub flash memory (System BIOS) 1 MB 3.99 Local APIC 4 KB 3.99 Area Reserved for the chipset 2 MB 3.99 I/O APIC (4 Kbytes)

  • Page 44: Connectors/Io Ports

    X10SRH-CF/CLN4F User’s Manual Connectors/IO Ports The I/O ports are color coded in conformance with the industry standards. See the figure below for the colors and locations of the various I/O ports. Backplane I/O Panel JUIDB1 UID-LED UID-SW 1 2 3...

  • Page 45: Universal Serial Bus (Usb)

    IPMI_LAN LAN2/LAN4 LAN1/LAN3 JVR1 USB4/5 USB6/7 USB8/9 BIOS JPS1 JOH1 JL1 CHASSIS INTRUSION JBT1 JBR1 C610 LGA2011-3 X10SRH-CF LEDS1 JPSAS1 REV: 1.00 DESIGNED IN USA BAR CODE 3008 SAS CODE IPMI CODE JSD2 MAC CODE BIOS LICENSE JSTBY1 JSD1 L-SAS4-7...

  • Page 46: Ethernet Ports

    X10SRH-CF/CLN4F User’s Manual Ethernet Ports LAN Ports Pin Definition Four Gigabit Ethernet ports (LAN1/ Pin# Definition LAN2/LAN3/LAN4) and an IPMI_LAN MDI_N0 port are located on the I/O backplane MDI_P0 Act LED to provide network connections. These MDI_N1 Link Up ports accept RJ45 type cables.

  • Page 47: Unit Identifier Switch/Uid Led Indicator

    IPMI_LAN LAN2/LAN4 LAN1/LAN3 JVR1 USB4/5 USB6/7 USB8/9 BIOS JPS1 JOH1 JL1 CHASSIS INTRUSION JBT1 JBR1 C610 LGA2011-3 X10SRH-CF LEDS1 JPSAS1 REV: 1.00 DESIGNED IN USA BAR CODE 3008 SAS CODE IPMI CODE JSD2 MAC CODE BIOS LICENSE JSTBY1 JSD1 L-SAS4-7...

  • Page 48: Front Control Panel

    X10SRH-CF/CLN4F User’s Manual Front Control Panel JF1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis. These connectors are designed spe- cifically for use with Supermicro chassis. See the figure below for the descriptions of the front control panel buttons and LED indicators.

  • Page 49: Front Control Panel Pin Definitions

    HDD LED BIOS JPS1 JOH1 JL1 NIC1 LED CHASSIS INTRUSION JBT1 JBR1 NIC2 LED C610 LGA2011-3 OH/Fan Fail LED X10SRH-CF LEDS1 JPSAS1 REV: 1.00 DESIGNED IN USA PWR Fail LED BAR CODE 3008 SAS CODE IPMI CODE JSD2 Reset Reset Button...

  • Page 50: Hdd Led

    X10SRH-CF/CLN4F User’s Manual HDD LED HDD LED Pin Definitions (JF1) The HDD LED connection is located Pin# Definition on pins 13 and 14 of JF1. Attach a 3.3V SB/UID_SW cable here to indicate HDD activ- HD Active ity. See the table on the right for pin definitions.

  • Page 51: Overheat (Oh)/Fan Fail/Pwr Fail/Uid Led

    NIC1 LED BIOS JPS1 JOH1 JL1 CHASSIS INTRUSION NIC2 LED JBT1 JBR1 C610 OH/Fan Fail LED LGA2011-3 PWR Fail LED X10SRH-CF LEDS1 JPSAS1 REV: 1.00 DESIGNED IN USA Reset Reset Button Ground BAR CODE 3008 SAS CODE IPMI CODE JSD2...

  • Page 52: Reset Button

    X10SRH-CF/CLN4F User’s Manual Reset Button Reset Button Pin Definitions (JF1) The Reset Button connection is located Pin# Definition on pins 3 and 4 of JF1. Attach it to a Reset hardware reset switch on the computer Ground case. Refer to the table on the right for pin definitions.

  • Page 53: Connecting Cables

    IPMI_LAN LAN2/LAN4 LAN1/LAN3 JVR1 USB4/5 USB6/7 USB8/9 BIOS JPS1 JOH1 JL1 CHASSIS INTRUSION JBT1 JBR1 C610 LGA2011-3 X10SRH-CF LEDS1 JPSAS1 REV: 1.00 DESIGNED IN USA BAR CODE 3008 SAS CODE IPMI CODE JSD2 MAC CODE BIOS LICENSE JSTBY1 JSD1 L-SAS4-7...

  • Page 54: Fan Headers (Fan 1-Fan 5 & Fan A-Fan C )

    X10SRH-CF/CLN4F User’s Manual Fan Headers (Fan 1-Fan 5 & Fan A-Fan C ) Fan Header Pin Definitions The X10SRH-CF/CLN4F has eight fan head- Pin# Definition ers (Fan 1-Fan 5 & Fan A-Fan C). These fans Ground (Black) are 4-pin fan headers. Although pins 1-3 of the 2.5A/+12V...

  • Page 55: Internal Buzzer (Spkr1)

    IPMI_LAN LAN2/LAN4 LAN1/LAN3 JVR1 USB4/5 USB6/7 USB8/9 BIOS JPS1 JOH1 JL1 CHASSIS INTRUSION JBT1 JBR1 C610 LGA2011-3 X10SRH-CF LEDS1 JPSAS1 REV: 1.00 DESIGNED IN USA BAR CODE 3008 SAS CODE IPMI CODE JSD2 MAC CODE BIOS LICENSE JSTBY1 JSD1 L-SAS4-7...

  • Page 56: Dom Pwr Connector (Jsd1/Jsd2)

    X10SRH-CF/CLN4F User’s Manual DOM PWR Connector (JSD1/JSD2) DOM PWR Pin Definitions The Disk-On-Module (DOM) power Pin# Definition connectors, located at JSD1 and JSD2, provide 5V power to a solid Ground state DOM storage device connected Ground to one of the SATA ports. See the table on the right for pin definitions.

  • Page 57: T-Sgpio 1/2/3 Headers

    IPMI_LAN LAN2/LAN4 LAN1/LAN3 JVR1 USB4/5 USB6/7 USB8/9 BIOS JPS1 JOH1 JL1 CHASSIS INTRUSION JBT1 JBR1 C610 LGA2011-3 X10SRH-CF LEDS1 JPSAS1 REV: 1.00 DESIGNED IN USA BAR CODE 3008 SAS CODE IPMI CODE JSD2 MAC CODE BIOS LICENSE JSTBY1 JSD1 L-SAS4-7...

  • Page 58: Tpm Header/Port 80 Header

    X10SRH-CF/CLN4F User’s Manual TPM Header/Port 80 Header TPM/Port 80 Header Pin Definitions A Trusted Platform Module/Port 80 Pin # Definition Pin # Definition header is located at JTPM1 to provide LCLK TPM support and Port 80 connection. LFRAME# <(KEY)> Use this header to enhance system...

  • Page 59: Jumper Settings

    IPMI_LAN LAN2/LAN4 LAN1/LAN3 JVR1 USB4/5 USB6/7 USB8/9 BIOS JPS1 JOH1 JL1 CHASSIS INTRUSION JBT1 JBR1 C610 LGA2011-3 X10SRH-CF LEDS1 JPSAS1 REV: 1.00 DESIGNED IN USA BAR CODE 3008 SAS CODE IPMI CODE JSD2 MAC CODE BIOS LICENSE JSTBY1 JSD1 L-SAS4-7...

  • Page 60: Cmos Clear (Jbt1)

    X10SRH-CF/CLN4F User’s Manual CMOS Clear (JBT1) JBT1 is used to clear the saved system setup configuration stored in the CMOS chip. To clear the contents of the CMOS, completely shut down the system, remove the AC power cord and then short JBT1 with forceps. Remove the forceps before powering on the system again.

  • Page 61: Manufacture Mode Select

    IPMI_LAN LAN2/LAN4 LAN1/LAN3 JVR1 USB4/5 USB6/7 USB8/9 BIOS JPS1 JOH1 JL1 CHASSIS INTRUSION JBT1 JBR1 C610 LGA2011-3 X10SRH-CF LEDS1 JPSAS1 REV: 1.00 DESIGNED IN USA BAR CODE 3008 SAS CODE IPMI CODE JSD2 MAC CODE BIOS LICENSE JSTBY1 JSD1 L-SAS4-7...

  • Page 62: Vga Enable

    X10SRH-CF/CLN4F User’s Manual VGA Enable VGA Enable Jumper Settings Jumper JPG1 allows the user to enable Jumper Setting Definition the onboard VGA connector. The default Enabled (Default) setting is 1-2 to enable the connection. Disabled See the table on the right for jumper settings.

  • Page 63: Bmc Enable

    IPMI_LAN LAN2/LAN4 LAN1/LAN3 JVR1 USB4/5 USB6/7 USB8/9 BIOS JPS1 JOH1 JL1 CHASSIS INTRUSION JBT1 JBR1 C610 LGA2011-3 X10SRH-CF LEDS1 JPSAS1 REV: 1.00 DESIGNED IN USA BAR CODE 3008 SAS CODE IPMI CODE JSD2 MAC CODE BIOS LICENSE JSTBY1 JSD1 L-SAS4-7...

  • Page 64: Onboard Indicators

    X10SRH-CF/CLN4F User’s Manual Onboard Indicators LAN1/LAN2 Activity LED Link LED LAN 1/LAN 2 LEDs Four LAN ports (LAN 1/LAN 2) are located GLAN 1/2 Activity Indicator on the I/O backplane of the motherboard. LED Settings Each Ethernet LAN port has two LEDs.

  • Page 65: Onboard Power Led (Le2)

    LED location. BMC Heartbeat LED BMC Heartbeat LEDM1 Status A BMC Heartbeat LED is located at Color/State Definition LEDM1 on the X10SRH-CF/CLN4F. See Green: BMC: Normal Blinking the table on the right for more informa- tion. A. PWR LED B.

  • Page 66: Sas Heartbeat Led

    X10SRH-CF/CLN4F User’s Manual SAS Heartbeat LED SAS Heartbeat LED Status (LEDS1) A SAS Heartbeat LED is located at Color/State Definition LEDS1 on the motherboard. See the Green: SAS Active table on the right for more information. Blinking Red: Solid On SAS Error A.

  • Page 67: 2-10 Sata Connections

    IPMI_LAN LAN2/LAN4 LAN1/LAN3 JVR1 USB4/5 USB6/7 USB8/9 BIOS JPS1 JOH1 JL1 CHASSIS INTRUSION JBT1 JBR1 C610 LGA2011-3 X10SRH-CF LEDS1 JPSAS1 REV: 1.00 DESIGNED IN USA BAR CODE 3008 SAS CODE IPMI CODE JSD2 MAC CODE BIOS LICENSE JSTBY1 JSD1 L-SAS4-7...
  • Page 68 X10SRH-CF/CLN4F User’s Manual Notes 2-40...

  • Page 69: Chapter 3 Troubleshooting

    Chapter 3: Troubleshooting Chapter 3 Troubleshooting Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the ‘Technical Support Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter. Always disconnect the AC power cord before adding, changing or installing any hardware components.

  • Page 70: No Video

    X10SRH-CF/CLN4F User’s Manual No Video 1. If the power is on, but you have no video--in this case, you will need to re- move all the add-on cards and cables first. 2. Use the speaker to determine if any beep codes exist. (Refer to Appendix A for details on beep codes.)

  • Page 71: Technical Support Procedures

    Chapter 3: Troubleshooting Technical Support Procedures Before contacting Technical Support, please make sure that you have followed all the steps listed below. Also, Note that as a motherboard manufacturer, Supermicro does not sell directly to end users, so it is best to first check with your distributor or reseller for troubleshooting services.

  • Page 72: Frequently Asked Questions

    Frequently Asked Questions Question: What type of memory does my motherboard support? Answer: The X10SRH-CF/CLN4F supports up to 256GB of RDIMM and 512GB of LRDIMM DDR4 1333/1600/1866/2133 MHz in eight memory slots. See Section 2-5 for details on installing memory.

  • Page 73: Battery Removal And Installation

    Chapter 3: Troubleshooting Battery Removal and Installation Battery Removal To remove the onboard battery, follow the steps below: 1. Power off your system and unplug your power cable. 2. Locate the onboard battery as shown below. 3. Using a tool such as a pen or a small screwdriver, push the battery lock out- wards to unlock it.

  • Page 74: Returning Merchandise For Service

    X10SRH-CF/CLN4F User’s Manual Returning Merchandise for Service A receipt or copy of your invoice marked with the date of purchase is required before any warranty service will be rendered. You can obtain service by calling your vendor for a Returned Merchandise Authorization (RMA) number. For faster service, you may also obtain RMA authorizations online (http://www.supermicro.

  • Page 75: Chapter 4 Bios

    Chapter 4: AMI BIOS Chapter 4 BIOS Introduction This chapter describes the AMI BIOS setup utility for the X10DRL-CF/CLN4F. The ROM BIOS is stored in a Flash EEPROM and can be easily updated. This chapter describes the basic navigation of the AMI BIOS setup utility screens. Note: For AMI BIOS recovery, please refer to the UEFI BIOS Recovery Instructions in Appendix C.

  • Page 76: How To Start The Setup Utility

    X10SRH-CF/CLN4F Motherboard User’s Manual How to Start the Setup Utility Normally, the only visible Power-On Self-Test (POST) routine is the memory test. As the memory is being tested, press the <Delete> key to enter the main menu of the AMI BIOS setup utility. From the main menu, you can access the other setup screens.

  • Page 77: The Following Main Menu Items Will Be Displayed

    Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. Supermicro X10SRH-CF/CLN4F Version: This item displays the version of the BIOS ROM used in the system. Build Date: This item displays the date when the version of the BIOS ROM used in the system was built.

  • Page 78: Advanced Setup Configurations

    X10SRH-CF/CLN4F Motherboard User’s Manual Advanced Setup Configurations Use the arrow keys to select Advanced setup and press <Enter> to access the submenu items: Warning: Take Caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency or an incorrect BIOS timing setting may cause the system to malfunction.

  • Page 79: Wait For 'F1' If Error

    Chapter 4: AMI BIOS Wait For 'F1' If Error Select Enabled to force the system to wait until the 'F1' key is pressed if an error occurs. The options are Disabled and Enabled. INT19 (Interrupt 19) Trap Response Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Immediate, the ROM BIOS of the host adaptors will "capture"...

  • Page 80: Restore On Ac Power Loss

    X10SRH-CF/CLN4F Motherboard User’s Manual Restore on AC Power Loss Use this feature to set the power state after a power outage. Select Power-Off for the system power to remain off after a power loss. Select Power-On for the system power to be turned on after a power loss. Select Last State to allow the system to resume its last power state before a power loss.

  • Page 81: Cores Enabled

    Chapter 4: AMI BIOS Select Enable to support Intel's Hyper-threading Technology to enhance CPU per- formance. The options are Enable and Disable. Cores Enabled Select Enabled to enable all CPU cores. The default setting is 0. Execute-Disable Bit (Available if supported by the OS & the CPU) Select Enable for Execute Disable Bit Technology support, which will allow the processor to designate areas in the system memory where an application code can execute and where it cannot, thus preventing a worm or a virus from flooding illegal...

  • Page 82: Dcu Mode

    X10SRH-CF/CLN4F Motherboard User’s Manual DCU Mode Use this feature to set the data-prefecting mode for the DCU (Data Cache Unit). The options are 32KB 8Way Without ECC and 16KB 4Way With ECC. Direct Cache Access (DCA) Select Enable to use Intel DCA (Direct Cache Access) Technology to improve the efficiency of data transferring and accessing.
  • Page 83 Chapter 4: AMI BIOS If the option is set to Energy Efficient or Custom, the following items will display: Config TDP (Configuring Thermal Design Power) Select Enable to configure TDP power settings to enhance thermal management. The options are Enable and Disable. Config TDP Level (Available when Config TDP above is set to Enable) Use this item to set TDP configuration level to enhance thermal management.
  • Page 84 X10SRH-CF/CLN4F Motherboard User’s Manual CPU C6 Report (Available when Power Technology is set to Custom) Select Enable to allow the BIOS to report the CPU C6 state (ACPI C3) to the operating system. During the CPU C6 state, power to all cache is turned off.

  • Page 85: Chipset Configuration

    Chapter 4: AMI BIOS Package Clamping Limit1 Use this item to set the limit on power performance states for the runtime proces- sor, with P0 being the state with the highest frequency (clock speed) and power (consumption), and P1, a step lower in performance than P0, with its frequency and voltage scaled back a notch.
  • Page 86 X10SRH-CF/CLN4F Motherboard User’s Manual PORT 1A Link Speed This item configures the link speed of a PCI-E port specified by the user. The options are Gen 1 (Generation 1) (2.5 GT/s), Gen 2 (Generation 2) (5 GT/s) and Gen 3 (Generation 3) (8 GT/s).

  • Page 87: Intel Vt For Directed I/O (Vt-D)

    Chapter 4: AMI BIOS IOAT (Intel® IO Acceleration) Configuration Enable IOAT Select Enable to enable Intel I/OAT (I/O Acceleration Technology) support, which significantly reduces CPU overhead by leveraging CPU architectural improve- ments and freeing the system resource for other tasks. The options are Enable and Disable.

  • Page 88: Qpi (Quick Path Interconnect) Configuration

    X10SRH-CF/CLN4F Motherboard User’s Manual QPI (Quick Path Interconnect) Configuration QPI Status The following information will display: • Number of CPU • Number of IIO • Current QPI Link Speed • Current QPI Link Frequency • QPI Global MMIO Low Base/Limit •...

  • Page 89: Memory Configuration

    Chapter 4: AMI BIOS Isoc Mode Select Enabled for Isochronous support to meet QoS (Quality of Service) require- ments. This feature is especially important for Virtualization Technology. The options are Enable and Disable. Memory Configuration Enforce POR Select Enable to enforce POR restrictions on DDR4 frequency and voltage programming.

  • Page 90: Dimm Information

    X10SRH-CF/CLN4F Motherboard User’s Manual Channel Interleaving Use this item to set DIMM channel interleaving mood. The options are Auto, 1-Way Interleave, 2-Way Interleave, 3-Way Interleave, and 4-Way Interleave. Rank Interleaving Use this item to select a rank memory interleaving method. The options are Auto, 1-Way, 2-Way, 4-Way, and 8-Way.

  • Page 91: South Bridge Configuration

    Chapter 4: AMI BIOS Patrol Scrub Patrol Scrubbing is a process that allows the CPU to correct correctable memory errors detected on a memory module and send the correction to the requestor (the original source). When this item is set to Enabled, the IO hub will read and write back one cache line every 16K cycles, if there is no delay caused by internal processing.

  • Page 92: Xhci Hand-Off

    X10SRH-CF/CLN4F Motherboard User’s Manual XHCI Hand-Off This is a work-around solution for operating systems that do not support XHCI (Ex- tensible Host Controller Interface) hand-off. The XHCI ownership change should be claimed by the XHCI driver. The settings are Enabled and Disabled.

  • Page 93: Pch Dmi Aspm

    Chapter 4: AMI BIOS PCH DMI ASPM Select Enabled to enable ASPM (Active State Power Management) support for a PCH DMI drive. The options are Disabled and Enabled. SATA Configuration  When this submenu is selected, AMI BIOS automatically detects the presence of the SATA devices that are supported by the Intel PCH chip and displays the fol- lowing items: SATA Controller...

  • Page 94: If The Item Above "Configure Sata As" Is Set To Ide, The Following Items Will Display

    X10SRH-CF/CLN4F Motherboard User’s Manual Port 0 ~ Port 5 Hot Plug Select Enabled to enable hot-plugging support for a port specified by the user, which will allow the user to replace a SATA disk drive installed on this port without shutting down the system.

  • Page 95: Ssata Configuration

    Chapter 4: AMI BIOS Serial ATA Port 0~ Port 5 This item displays the information detected on the installed SATA drives on the particular SATA port. • Model number of drive and capacity • Software Preserve Support Port 0~ Port 5 Select Enabled to enable a SATA port specified by the user.

  • Page 96: If The Item Above "Configure Ssata As" Is Set To Ide, The Following Items Will Display

    X10SRH-CF/CLN4F Motherboard User’s Manual *If the item above "Configure sSATA as" is set to AHCI, the following items will display: Support Aggressive Link Power Management When this item is set to Enabled, the SATA AHCI controller manages the power usage of the SATA link. The controller will put the link to a low power state when the I/O is inactive for an extended period of time, and the power state will return to normal when the I/O becomes active.

  • Page 97: If The Item Above "Configure Ssata As" Is Set To Raid, The Following Items Will Display

    Chapter 4: AMI BIOS Port 0 ~ Port 3 sSATA Device Type (Available when a SATA port is detected) Use this item to specify if the sSATA port specified by the user should be con- nected to a Solid State drive or a Hard Disk Drive. The options are Hard Disk Drive and Solid State Drive.

  • Page 98: Server Me (Management Engine) Configuration

    X10SRH-CF/CLN4F Motherboard User’s Manual Server ME (Management Engine) Configuration This feature displays the following system ME configuration settings. • General ME Configuration • Operational Firmware Version • Recovery Firmware Version • ME Firmware Features • ME Firmware Status #1 •...

  • Page 99: Maximum Payload

    Chapter 4: AMI BIOS Maximum Payload Select Auto for the system BIOS to automatically set the maximum payload value for a PCI-E device to enhance system performance. The options are Auto, 128 Bytes, and 256 Bytes. Maximum Read Request Select Auto for the system BIOS to automatically set the maximum size for a read request for a PCI-E device to enhance system performance.

  • Page 100: Onboard Lan1 Option Rom/Onboard Lan2 Option Rom/Onboard Lan3

    X10SRH-CF/CLN4F Motherboard User’s Manual Onboard LAN1 Option ROM/Onboard LAN2 Option ROM/Onboard LAN3 Option ROM/Onboard LAN4 Option ROM/Onboard Video Option ROM Use this option to select the type of device installed in LAN Port1, LAN Port2, LAN Port3, LAN Port4, or the onboard video device used for system boot. The default setting for LAN1 Option ROM is PXE, for LAN2 Option ROM, LAN3 Option ROM, or LAN4 Option ROM is Disabled, and for Onboard Video Option ROM is Legacy.

  • Page 101: Device Settings

    Chapter 4: AMI BIOS Device Settings This item displays the base I/O port address and the Interrupt Request address of a serial port specified by the user. Change Port 1 Settings/Change Port 2 Settings This feature specifies the base I/O port address and the Interrupt Request address of Serial Port 1 or Serial Port 2.
  • Page 102 X10SRH-CF/CLN4F Motherboard User’s Manual client computer. A lower transmission speed may be required for long and busy lines. The options are 9600, 19200, 38400, 57600 and 115200 (bits per second). Data Bits Use this feature to set the data transmission size for Console Redirection. The options are 7 (Bits) and 8 (Bits).

  • Page 103: Sol/Com2

    Chapter 4: AMI BIOS Use this item to select the number of rows and columns used in Console Redi- rection for legacy OS support. The options are 80x24 and 80x25. Putty KeyPad This feature selects Function Keys and KeyPad settings for Putty, which is a terminal emulator designed for the Windows OS.
  • Page 104 X10SRH-CF/CLN4F Motherboard User’s Manual Use this feature to set the data transmission size for Console Redirection. The options are 7 (Bits) and 8 (Bits). Parity A parity bit can be sent along with regular data bits to detect data transmission errors.
  • Page 105 Chapter 4: AMI BIOS This feature selects Function Keys and KeyPad settings for Putty, which is a terminal emulator designed for the Windows OS. The options are VT100, LINUX, XTERMR6, SCO, ESCN, and VT400. Redirection After BIOS Post Use this feature to enable or disable legacy Console Redirection after BIOS POST (Power-On Self-Test).

  • Page 106: Trusted Computing (Available When A Tpm Device Is Installed And Detected By The Bios)

    X10SRH-CF/CLN4F Motherboard User’s Manual Use this item to set the flow control for Console Redirection to prevent data loss caused by buffer overflow. Send a "Stop" signal to stop data-sending when the receiving buffer is full. Send a "Start" signal to start data-sending when the receiving buffer is empty.

  • Page 107: Acpi Settings

    Chapter 4: AMI BIOS ACPI Settings  WHEA Support Select Enabled to support the Windows Hardware Error Architecture (WHEA) plat- form and provide a common infrastructure for the system to handle hardware errors within the Windows OS environment to reduce system crashes and to enhance system recovery and health monitoring.

  • Page 108: Event Logs

    X10SRH-CF/CLN4F Motherboard User’s Manual Event Logs Use this feature to configure Event Log settings. Change SMBIOS Event Log Settings  This feature allows the user to configure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.

  • Page 109: Memory Correctable Error Threshold

    Chapter 4: AMI BIOS Memory Correctable Error Threshold Use this item to enter the threshold value for correctable memory errors. The default setting is 10. Erasing Settings Erase Event Log Select Enabled to erase all error events in the SMBIOS (System Management BIOS) log before an event logging is initialized at bootup.

  • Page 110: Ipmi

    X10SRH-CF/CLN4F Motherboard User’s Manual IPMI Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. IPMI Firmware Revision This item indicates the IPMI firmware revision used in your system. IPMI Status This item indicates the status of the IPMI firmware installed in your system.

  • Page 111: When Sel Is Full

    Chapter 4: AMI BIOS When SEL is Full This feature allows the user to determine what the BIOS should do when the sys- tem event log is full. Select Erase Immediately to erase all events in the log when the system event log is full. The options are Do Nothing and Erase Immediately. Note: After making changes on a setting, be sure to reboot the system for the changes to take effect.

  • Page 112: Security Settings

    X10SRH-CF/CLN4F Motherboard User’s Manual Security Settings This menu allows the user to configure the following security settings for the system. Password Check Select Setup for the system to prompt for a password at Setup. Select Always for the system to prompt for a password at bootup and upon entering the BIOS Setup utility.

  • Page 113: Boot Settings

    Chapter 4: AMI BIOS Boot Settings Use this feature to configure Boot Settings: Boot Configuration Setup Prompt Timeout Use this item to indicate how many seconds the system shall wait for the BIOS setup activation key to respond before the system starts to boot. The default setting is 1. Boot Mode Select Use this item to select the type of device to be used for system boot.

  • Page 114: Add New Boot Option

    X10SRH-CF/CLN4F Motherboard User’s Manual • Dual Boot Order #7 • Dual Boot Order #8 • Dual Boot Order #9 • Dual Boot Order #10 • Dual Boot Order #11 • Dual Boot Order #12 • Dual Boot Order #13 •...

  • Page 115: Hard Disk Drive Bbs Priorities

    Chapter 4: AMI BIOS  Hard Disk Drive BBS Priorities • Legacy Boot Order #1 - Legacy Boot Order #10  Network Drive BBS Priorities • Legacy Boot Order #1 - Legacy Boot Order #3  UEFI Application Boot Priorities •...

  • Page 116: Save & Exit

    X10SRH-CF/CLN4F Motherboard User’s Manual Save & Exit Select the Save & Exit tab from the BIOS setup screen to configure the settings below. Discard Changes and Exit Select this option to quit the BIOS setup without making any permanent changes to the system configuration, and reboot the computer.

  • Page 117: Restore Defaults

    Chapter 4: AMI BIOS Restore Defaults To set this feature, select Restore Defaults from the Exit menu and press <Enter>. These are manufacture default settings designed for maximum system performance but not for maximum stability. Save As User Defaults To set this feature, select Save as User Defaults from the Exit menu and press <En- ter>.
  • Page 118 X10SRH-CF/CLN4F Motherboard User’s Manual Notes 4-44...

  • Page 119: Appendix A Bios Error Beep Codes

    Appendix A: POST Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue with bootup.
  • Page 120 X10SRH-CF/CLN4F User’s Manual Notes...

  • Page 121: Appendix B Software Installation Instructions

    Appendix B: Software Installation Instructions Appendix B Software Installation Instructions B-1 Installing Software Programs The Supermicro ftp site contains drivers and utilities for your system at ftp://ftp. supermicro.com. Some of these must be installed, such as the chipset driver. After accessing the ftp site, go into the CDR_Images directory and locate the ISO file for your motherboard.

  • Page 122: B-2 Installing Superdoctor5

    X10SRH-CF/CLN4F Motherboard User’s Manual B-2 Installing SuperDoctor5 The Supermicro SuperDoctor® 5 is a hardware monitoring program that functions in a command-line or web-based interface in Windows and Linux operating systems. The program monitors system health information such as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 123: Appendix C Uefi Bios Recovery Instructions

    Appendix C: UEFI BIOS Recovery Appendix C UEFI BIOS Recovery Instructions Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 124 X10SRH-CF/CLN4F User’s Manual 1. Using a different machine, copy the "Super.ROM" binary image file into the disc Root "\" Directory of a USB device or a writeable CD/DVD. Note: If you cannot locate the "Super.ROM" file in your driver disk, visit our website at www.supermicro.com to download the BIOS image into...
  • Page 125 Appendix C: UEFI BIOS Recovery 6. After the process of BIOS Recovery is complete, press any key to reboot the system. 7. Using a different system, extract the BIOS package into a bootable USB flash drive. 8. When a DOS prompt appears, enter AMI.BAT BIOSname.### at the prompt. Note: Do not interrupt this process until BIOS flashing is completed.
  • Page 126 X10SRH-CF/CLN4F User’s Manual 9. After seeing the message that BIOS update is completed, unplug the AC pow- er cable from the power supply to clear CMOS, and then plug the AC power cable in the power supply again to power on the system.

  • Page 127: Appendix D Dual Boot Block On Grantley Platforms

    Appendix D: Dual Boot Block Appendix D Dual Boot Block on Grantley Platforms Overview On X10 Grantley platforms, Supermicro introduces the Dual Boot Block feature that revives the system from an inert state if the primary boot block in the ROM chip is damaged.

  • Page 128: D-1 Ipmi Gui Browser

    X10SRH-CF/CLN4F User’s Manual D-1 IPMI GUI Browser To perform perform the Dual Boot Block through the IPMI GUI browser, follow the instructions below: 1. After the IPMI GUI browser log-in, click on the Miscellaneous tab, then BIOS Resilience, then the Resile button.
  • Page 129 Appendix D: Dual Boot Block 3. Click on the Remote Control tab, then Console Redirection, then the Launch Console button to open the Java iKVM Viewer. 4. In the Java iKVM Browser, click on the Virtual Media tab, then Virtual Stor- age to open the Virtual Media Loader.
  • Page 130 X10SRH-CF/CLN4F User’s Manual 5. In the Virtual Media loader, click on the Device1 tab, then Logical Drive Type drop-down menu, then select the USB flash drive with Super.ROM. Click Plug In, then OK. 6. Click on the Remote Control tab, then Power Control, then check the Power On Server button.
  • Page 131 Appendix D: Dual Boot Block 7. After the system powers on, the secondary boot block starts to initialize the essential hardware components and locates Super.ROM in the USB flash drive, which was mounted earlier. If Super.ROM is found, the on-duty boot block boots to it and finishes the rest of the POST processes.
  • Page 132 X10SRH-CF/CLN4F User’s Manual 9. A message box will appear to indicate the BIOS recovery flash process is complete. Press ENTER to finish. The system will do a power cycle to deacti- vate the dual boot block feature and produce a normal BIOS POST.

  • Page 133: D-2 Ipmi Command Sets

    Appendix D: Dual Boot Block D-2 IPMI Command Sets To perform perform the Dual Boot Block through the IPMI Command Sets, follow the instructions below: 1. After the IPMI GUI browser log-in, click on the Remote Control tab, then Console Redirection, then the Launch Console button to open Java iKVM Viewer.
  • Page 134 X10SRH-CF/CLN4F User’s Manual 3. Enable BIOS Resilience mode in remote IPMI and confirm. • To enable, type the following command in the command prompt: ipmi raw 30 70 C2 D5 00 00 • To confirm, type the following command in the command prompt: impi raw 30 70 C3 D5 4.

  • Page 135: User Approach

    Appendix D: Dual Boot Block 5. Power on the remote system for BIOS recovery flash. • To power on, type: ipmi power up After the system powers on, the secondary boot block initializes the essential hardware components and locates Super.ROM in the USB flash drive, which are the same as Steps 7-9 in Section D-1.
  • Page 136 X10SRH-CF/CLN4F User’s Manual Notes D-10...
  • Page 137 (Disclaimer Continued) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.

This manual is also suitable for:

Cln4fX10srh-cln4f

Table of Contents
