AMANA C-MODEL
COOLING/HEAT PUMP & ELECTRIC HEAT
Heat Pump Cooling Performance
Model (Basic) (NOTES 1, 7 & 9)
Voltage
(NOTES 1 & 3)
Capacity (BTUH)
Amps
Watts
EER**
Units without Electric Heater
Min.Circuit Ampacity
(NOTES 2 & 4)
CFM (Cool, Wet Coil) High
Low
CFM (Dry Coil) High
Low
Ventilated Air, CFM (Fan Only)*
Ventilated Air, CFM (Compressor & Fan)*
Dehumidification (Pints/Hr.)
Net Weight (approximate lbs.)
Shipping Weight (approximate lbs.)
* Approximately 95 CFM with optional power vent kit. Actual vent CFM performance will vary due to application and installation conditions.
**EER - Energy Efficiency Ratio per Air-Conditioning & Refrigeration Institute (ARI) Test Procedures and Canadian Standards Association (CSA) EEV Test Procedures
Heating Performance - Reverse Cycle
Heating Capacity
Reverse Cycle (NOTE 1)
BTUH (NOTE 5)
Amps
Watts
COP (NOTE 5)
CFM (Dry)
Heating, BTUH ° F
(Note 5) 62
57
Outdoor Ambient 52
47
Rating Point
(COP)*
42
37
32
27
24
Watts 62
57
52
Outdoor Ambient 47
42
37
32
27
24
COP - Coefficiency of Performance per ARI Test Procedures Units are rated for capacities and efficiencies.
NOTES:
1. All 265v models must use Amana's subbase (PTSB4**C) or Amana's hard wire kit (PTPWHWK4)
2. Minimum branch circuit ampacity ratings conform to the National Electric Code. However, local codes should apply.
3. Minimum voltage on 230/208 volt models is 197 volts; maximum is 253 volts. Minimum voltage on 265 volt models is 238.5 volts; maximum is 291.5 volts.
4. Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265 volt models must be cartridge-style time delay fuses
(included and factory installed on Amana all 265 volt chassis).
5. Heating capacity and efficiency is based on unit operation without condensate pump. Unit automatically switches to electric heat at approximately 24°F
outdoor ambient.
6. Total watts for 12,000 and 15,000 Btuh models. Subtract 70 watts for PT07/09*A**AC.
7. Please specify 2-digit heater kW size to complete model number.
8. Total amps for 12,000 and 15,000 Btuh models; subtract 0.2 amps for PT07/09*A*AC.
9. Refrigerant used in all systems is R-22.
PTH Models - Heat Pumps
PTH073A**AC PTH074A**AC
230/208 265
7,100 / 7000 7,100
2.8/3.0 2.3
615/610 615
11.5 11.5
4.0 3.6
245 / 240 245
220 / 205 220
265 / 260 265
230 / 215 230
65* 65*
65* 65*
1.6 1.6
95 95
110 110
(See facing page for Auxillary Electric Heater Performance and Power Cord Configuration)
PTH073A**AC PTH074A**AC PTH093A**AC
6,400/6,200 6,400 8,100/8,000
2.6/3.0 2.2
570/550 570
3.3 3.3
235/230 235
7,400/7,200 7,400 9,700/9,600
7,100/6,900 7,100 9,200/9,100
6,700/6,500 6,700 8,600/8,500
6,400/6,200 6,400 8,100/8,000
3.3/3.3 3.3
6,100/5,900 6,100 7,600/7,500
5,800/5,600 5,800 7,100/7,000
5,500/5,300 5,500 6,600/6,500
5,200/5,000 5,200 6,100/6,000
5,000/4,800 5,000 5,800/5,700
600/585 600
595/580 595
575/560 575
570/555 570
560/535 560
545/530 545
535/520 535
525/510 525
520/505 520
PTH093A**AC PTH094A**AC PTH123A**AC
230/208 265
9,000/8,800 9,000 12,000 / 11,800
3.5/3.8 3.0
805 / 785 805 1,120 / 1,110
11.2 11.2
5.1 4.4
245 / 240 245
220 / 205 220
265 / 260 265
230 / 215 230
65* 65*
65* 65*
2.6 2.6
100 100
115 115
PTH094A**AC PTH123A**AC
8,100 10,800/10,600
3.2/3.6 2.6 4.5/5.1
740/730 740 1,020/1,000
3.2 3.2
235/230 230 310/290
9,700 13,000/12,800
9,200 12,300/12,100
8,600 11,600/11,400
8,100 10,800/10,600
3.2/3.2 3.2 3.1/3.1
7,600 10,100/9,900
7,100 9,400/9,200
6,600 8,600/8,400
6,100 7,900/7,700
5,800 7,500/7,300
800/790 800 1,120/1,100
790/780 790 1,090/1,075
765/755 765 1,060/1,045
740/730 740 1,020/1,005
720/710 720 985/970
695/685 695 950/935
680/670 680 900/885
650/640 650 855/840
630/620 630 830/815
C - 5

SPECIFICATIONS

PTH124A**AC PTH153A**AC
230/208 265 230/208
12,000 14,000/13,800
4.6/5.0 4.3 6.3/6.9
1,120 1505 / 1485
10.7 10.7
6.4 5.7
325 / 315 325 325/315
250 / 229 250 250/220
345 / 335 345 345/335
265 / 235 265 265/235
70* 70*
70* 70*
3.5 3.5
110 110
125 125
PTH124A**AC PTH153A**AC
10,800 13,300/13,200
3.9 5.7/6.3
1,020 1,390/1,380
3.1 3.1
310 345/335
13,000 15,800/15,700
12,300 15,000/14,900
11,600 14,200/14,100
10,800 13,300/13,200
3.1 2.8/2.8
10,100 12,500/12,400
9,400 11,700/11,600
8,600 10,800/10,700
7,900 10,000/9,900
7,500 9,500/9,400
1,120 1,490/1,480
1,090 1,465/1,455
1,060 1,430/1,420
1,020 1,390/1,380
985 1,350/1,340
950 1,310/1,300
900 1,265/1,255
855 1,215/1,205
830 1,205/1,195
PTH154A**AC
265
14,000
5.9
1,505
9.3 9.3
8.4 7.4
325
250
345
265
70* 70*
70* 70*
4.4 4.4
115 115
130 130
PTH154A**AC
13,300
5.4
1,390
2.8 2.8
345
15,800
15,000
14,200
5,440
2.8
12,500
11,700
10,800
10,000
9,500
1,490
1,465
1,430
1,390
1,350
1,310
1,265
1,215
1,205
