- Page 1 ACKAGE ACKAGE ERMINAL ERMINAL ONDITIONERS & H UMPS Featuring the most energy efficient heat pump ever built by Amana Don’t settle Heating & Air Conditioning for less than the ® Amana Standard Advantage Comfort. Quality. Trust.
- Page 2 “extras” already built in as “STANDARD” on every unit. With all the features and benefits our units have to offer, you no longer need to settle for anything less than the Amana “Standard” Advantage!!
- Page 3 No more worries about changing out non-standard sleeves that do not accommodate the bulk of what the Wall Sleeve industry has to offer. Amana's wall sleeve is an industry standard size of 13-3/4" deep x 42" wide x 16-1/16" 13-3/4" x 42" x16-1/16"...
-
Page 4: Ventilated Air, Cfm (Fan Only)
AMANA C-MODEL SPECIFICATIONS COOLING/ELECTRIC HEAT PTC Models Cooling Performance Model (Basic) (NOTES 1, 7 & 9) PTC073A**AC PTC074A**AC PTC093A**AC PTC094A**AC PTC123A**AC PTC124A**AC PTC153A**AC PTC154A**AC 230/208 230/208 230/208 230/208 Voltage (NOTES 1 & 3) 7,100 / 7,000 7,100 9,100/8,900 9,100 12,000 / 11,900... -
Page 5: Specifications
COP - Coefficiency of Performance per ARI Test Procedures Units are rated for capacities and efficiencies. NOTES: All 265v models must use Amana’s subbase (PTSB4**C) or Amana’s hard wire kit (PTPWHWK4) Minimum branch circuit ampacity ratings conform to the National Electric Code. However, local codes should apply. - Page 6 The switch is rated at 30 amp Fuse Holder Power Switch and Circuit Breaker Location Location capacity. The switch is for use with Amana's standard subbases or PTPWHWK4 Hard Wire Kit. Subbase Kit PTSB320C 230/208V 15/20A...
- Page 7 In conjunction with the tamper-resistant front, the installa- Drain Fitting KL03 Security Key Lock tion of Amana’s security key locks prevents tampering of the (12.7mm) controls used to set temperature, heating and cooling functions. U.L. approved for institutional use only.
- Page 8 AMANA C-MODEL Chassis UIDE PECIFICATIONS Furnish and install air cooled through the wall package terminal air conditioners (heat pumps). Units are rated in accordance with the ARI (Air-Conditioning & Refrigeration Institute) Standards 310/380-93, and CSA (Canadian Standards Association) EEV certification programs and listed by U. L. (Underwriters Laboratories).
-
Page 9: Guide Specifications
AMANA C-MODEL Accessories UIDE PECIFICATIONS (New installations typically require a minimum of WS900B wall sleeve and an outdoor grille.) Wall Sleeves Outdoor Grilles The wall sleeve must be industry accepted dimen- Must be architectural extruded, louvered aluminum sions: 13-3/4” depth x 42” width x 16-1/16” height and... -
Page 10: Top View
AMANA C-MODEL STANDARD UNIT DIMENSIONS Unit with Accessory Wall Sleeve and Subbase Accessory U n it w ith W a ll S l e e v e a n d S u b b a s e A c c e s s o rie s 4 2 "... - Page 11 If mounted to bottom of sleeve, allow 2” height clearance from floor to bottom of sleeve. (3). For U.L. approval -- 265v units must use Amana Subbase (PTSB***C) or Amana Hard Wire Kit (PTPWHWK4). Over-current protection on 265V units must be by cartridge style time delay fuses which are included and factory installed on Amana 265v chassis.
-
Page 12: Full One-Year Warranty
ON FUNCTIONAL PARTS WARRANTY PROVIDES FOR: FULL FIRST YEAR WARRANTY: Amana will repair or replace, free of charge, f.o.b. Fayetteville, Tennessee, any part of the unit or Amana accessory, which proves to be defective due to workmanship or materials. FULL FIVE YEAR SEALED SYSTEM WARRANTY: Amana will repair or replace, free of charge, f.o.b. Fayetteville, Tennessee, the evaporator coil, condenser coil, compressor or connecting tubing, which proves to be defective due to workmanship or materials or non-reparable refrigerant leak(s).
