THE AMANA "STANDARD" ADVANTAGE
Amana has designed the Packaged Terminal Air Conditioner for customer comfort and owner peace of mind. No other
unit in the industry offers so many "extras" already built in as "STANDARD" on every unit. With all the features and benefits
our units have to offer, you no longer need to settle for anything less than the Amana "Standard" Advantage!!
Standard Features
Enjoy one of the most comprehensive warranties in the industry. Full 1-year warranty on unit parts and labor;
Five-Year Warranty full 5-year warranty on the entire sealed system components; limited 2nd through 5th year parts-only warranty
on functional components. See back of this brochure for details.
Our units' high efficiencies can qualify you for many of the rebates offered by electrical power companies
Energy Efficiencies
EER's up to 11.6 and heat pump COP's up to 3.3 keep energy consumption to a minimum.
No more worries about bursting water pipes or broken fixtures caused by freezing temperatures. When the
Freeze
unit senses temperatures of 40 degrees Fahrenheit or below, the unit activates the fan motor, and either
Protection
the electric resistance heater or the hydronic heater.
Enhance valuable room space--the unit front has a sleek 7" depth, one of the shallowest silhouettes in the
7" Unit Front
industry today. In addition, to inhibit guest-tampering, the front can be secured to the chassis with hidden screws.
Our unit's stylish design and neutral color make it compatible with virtually any room décor or
Versatile Style
architectural design. The unit becomes less noticeable as it blends into the room's color scheme.
No complex controls to confuse your guests and create phone calls for your manager. Controls are easy
Easy To Use Controls
to read, understand, and activate.
Each unit is built to be operated from a remote-mounted thermostat, if desired. Even if you start without
Remote Thermostat
a remote, you can take advantage of a built-in low voltage power source which accommodates a variety
Control
of manufaturer approved thermostat choices --manual, auto change-over, or programmable -- at a later date.
Increased Maintain lower humidity levels in rooms while cooling them without the need for expensive add-on's.
Dehumidification As a result, guests feel more comfortable at higher temperatures, thus reducing cooling costs, and increasing the life
of your furniture, wall coverings, and fixtures is extended which means less replacement costs.
Capacity
The unit's state of the art design and construction provide a quiet environment allowing guests to enjoy peaceful,
Quiet Operation
sleep-filled nights. Operating sound levels are further dampened when unit is in "low fan" mode of operation.
Obtain greater savings by centrally controlling units and eliminate wasted energy generated by cooling
Front Desk Control and heating unoccupied rooms. Each unit has low voltage interface capability with a field supplied
front desk ON/OFF switch.
Remote Temperature Guests enjoy ultimate comfort with consistent climate control. When the field installed thermister(RTS02) is used,
Sensing the unit mounted thermostat is overridden to allow more accurate, internal wall-sensing of room ambient temperature.
Thirty Fan continues to run thirty (30) seconds after compressor has stopped in either cooling or heat pump mode
Second and after electric heat has been turned off. This improves efficiency by dispersing the conditioned air on the coils
Fan Off Delay into the room.
This feature helps prolong the life of the compressor by preventing short-cycling. When the compressor is
Compressor switched from off to on because room temperature has risen or fallen below the specified limit, it will remain on
Lock-In for at least four minutes. If the temperature set point is changed during this four minutes, the lock-in feature
is overriden.
The Amana condensate dispersion system removes condensate from indoor cooling operation by throwing water directly
Condensate on to the outdoor coil for rapid evaporation and increased cooling efficiencies. The slinger ring on the fan blade draws
Dispersion System water up and into fan blade. This water is then atomized and evaporated into the atmosphere
through the condenser.
No more "my unit is not heating" complaints during the middle of the night. Heat pump units will automatically switch over
Automatic
to electric resistance heat if for any reason the heat pump compressor system fails or if the heating load is greater than
Emergency Heat
the unit capacity.
Extended The heat pump models will operate in the heat pump heating mode down to as low as 24°F outdoor ambient, providing
Heat Pump Heating additional hours of energy saving operation.
Advantages and Benefits
