AMANA C-MODEL
Gasket
Cover
1/2" OD
Drain Fitting
(12.7mm)
Condenser Baffles
Condenser
42-27/32"
AIR FLOW
MAIN DUCT
MDK02
(Included in
TRANSITION
DUCT
BRACKET
MDK02)
Hot Water Inlet / Outlet Connections Steam/Water
Steam Inlet / Outlet Connection Coil Position
16-3/4"
8-1/4"
20-3/16"
2-1/8"
53"
Hydronic Air
FRONT VIEW
Inlet
(unit wi/Hronic Kit installed)
Model
Nominal 230V
BTUs
All 1,500
Rated Watts
7K & 9K
Full Load Amps
(including fan)
12K & 15K
7K & 9K
Minimum
Ampacity
12K & 15K
Fuse Size All
Condensate Drain Kit
Attaches to the wall sleeve base pan for controlled inter-
nal or external disposal of condensate
Plate
Security Key Locks
In conjunction with the tamper-resistant front, the installa-
tion of Amana's security key locks prevents tampering of the
controls used to set temperature, heating and cooling
functions. U.L. approved for institutional use only.
Remote Escutcheon Kit
Optional kit for use with units controlled via a wall thermo-
stat. Replaces knob controls for units operated by wall
thermostat.
Condenser Baffle Kit
For use on non-baffled grilles. These deflectors direct the
air in toward the center and away from the inlet to prevent
recirculation of the hot condenser air.
Duct Extension Kit
Extends air distribution to an adjoining room. Consists of a
main duct for the room of origin and an extension duct to
reach the adjoining room and terminal duct.
PARTITION
WALL
DUCT Power Vent Kit
TERMINATION
KIT
6" TO 42-1/2"
Installation of Power Vent increases CFM up to approxi-
mately 95. Vent door will automatically close when unit fan
DUCT EXTENSION
AIR FLOW
EDK02 is off.
BRACKET
Power Door Kit
1" to
adjoining
wall
surface
Vent door will automatically open when unit fan is on.
MINIMUM
5"
BOTH SIDES
Hydronic Transformer Relay Kit
Add-on kit that allows field conversion of a standard PTC
unit to a Hydronic unit.
Hydronic Heat Kit
Add-on kits fit all units allowing the addition of hydronic
Hot Water Inlet / Outlet Connections
water or hydronic steam heat to cooling and heating units.
Steam Inlet / Outlet Connections
The kits feature left- or right-hand piping. Unit retains com-
plete service access with a kit installed.
Hydronic Valves
Water and steam valves are available for use with the
HWK03 (water) and HVK03 (steam) heat kits.
chitects and Engineers Manual for specifications.)
Leveling Legs
Optional leveling legs fit wall sleeve to provide front sup-
port and leveling, if required. Four screws provided.
Condensate Removal Pump
Can be field installed. Assists in removing condensate
developed by heat pump operation and transfers it to in-
door coil to dissipate into room while adding humidity to the
room.
208V 265V
Spare Filters
Helps keep dirt and lint out of the air and off the coil, thus
1,200 1,500
increasing unit's efficiency.
6.9 6.2 6.1
remove, wash, and replace.
7.1 6.4 6.3
Heater Kit
8.6 8.6 7.5
Optional 1.5kW heater kits are available for use only with
8.8 8.8 7.7
models originally shipped without electric heat. Ask sales-
15 15 15
person for details.
(not shown)
(not shown)
(not shown)
(not shown)
(not shown)
(not shown)
(not shown)
Amana filters are easy to
(for heaterless units only) (not shown)
C - 7
ACCESSORIES
DK9001
KL03 Security Key Lock
Remote Escutcheon
REK10A
DGK1
MDK02
EDK02 Extension Duct
TDK02
PVK3A
PVK4A
PDK3A
PDK4A
HTK3
HTK4
HWK03 Hydronic Water Kit
HVK03 Hydronic Steam Kit
VS2WNCA* 2 way-24V-Steam-End Switch
VS2WNOA* 2 Way-24V-NO-Steam-End Switch
VW2WNCA* 2 Way-24V-NC-End Switch
(See Ar-
VW3WNC2B* 3 Way-24V-NC/NO-End Switch
*Poptop Actuator
LL2B Leveling Legs
CDP302
CDP402
FK10A Filters (10/pack)
HK315F
HK415F
Condensate
Drain Kit
Kit (10/pack)
Condenser
Baffle Kit
Main Duct
Terminal Duct
230/208V
265V
230/208V
265V
230/208V
265V
230/208V
265V
230/208V
265V
