SPECIFICATIONS
Cooling Performance
Model (Basic) (NOTES 1, 7 & 9)
Voltage (NOTES 1 & 3)
Capacity (BTUH)
Amps
Watts
EER
Unit without Electric Heater
Min.Circuit Ampacity
(NOTES 2 & 4)
CFM (Cool, Wet Coil) High
Low
CFM (Dry Coil) High
Low

Ventilated Air, CFM (Fan Only)*

Ventilated Air, CFM (Compressor & Fan)*
Dehumidification (Pints/Hr.)
Net Weight (approximate Lbs.)
Shipping Weight (approximate lbs.)
* Approximately 95 CFM with optional power vent kit. Actual vent CFM performance will vary due to application and installation conditions.
ELECTRIC
VOLTAGE HEATER
SIZE (kW)
230/208V 2.5/2.0
230/208V 3.5/2.9
230/208V 5.0/4.1
265V 2.5
265V 3.7
265V 5.0
**PTC/H09*A50*C is 2-stage; PTC/H12*A50*C and PTC/H15*A50*C are 1-stage.
Hydronic Heat Models
Hydronic Models / Hot Water & Steam Heating
These special models are shipped without a chassis front,
without electric heat, and have an additional relay and 40VA
transformer for water or steam valve operation. Also avail-
able in Hydronic with Powered Vent and Hydronic with Pow-
ered Door. See Model Identification (right) for Special Fea-
ture Codes for these models. See C-7 for hydronic accesso-
ries.
Hydronic with Manual Door
Voltage
Model Number
Capacity
PTC093A00HC 230/208
PTC123A00HC 230/208
PTC153A00HC 230/208
PTC094A00HC 265
PTC124A00HC 265
PTC154A00HC 265
COOLING/ELECTRIC HEAT
PTC073A**AC PTC074A**AC
230/208 265
7,100 / 7,000 7,100
2.8/3.0 2.3
610 / 600 610
11.6 11.6
4.0 3.6
245 / 240 245
220 / 205 220
265 / 260 265
230 / 215 230
65* 65*
65* 65*
1.6 1.6
90 90
105 105
Electric Heater Performance (PTC and PTH Models)
(Primary Heating for PTC models; Auxiliary Heating for PTH models)
NOMINAL HEATING
NO. OF BTUH BTUH
STAGES AT 230V AT 208V
1 8,500 6,800
1 12,000 9,900
** 17,100 14,000
1 - - - -
1 - - - -
** - - - -
Cooling
EER
Capacity
9,100 / 8,900 11.3
12,000 / 11,900 10.7
14,200/14,000 9.2
9,100 11.3
12,200 10.7
14,200 9.3
PTC Models
PTC093A**AC PTC094A**AC PTC123A**AC
230/208 265
9,100/8,900 9,100 12,000 / 11,900
3.7/3.8 3.0
805 / 785 805 1,120 / 1,110
11.3 11.3
5.1 4.4
245 / 240 245
220 / 205 220
265 / 260 265
230 / 215 230
65* 65*
65* 65*
2.6 2.6
95 95
110 110
TOTAL TOTAL
BTUH WATTS
AT 265V (NOTE 6) (NOTE 8)
- - 2,650/2,140 11.5/10.2
- - 3,650/3,040 15.8/14.5
- - 5,150/4,240 22.3/20.3
8,500 2,650
12,600 3,850
17,100 5,150
PT C 09
PACKAGE
TERMINAL
MODEL TYPE
C = COOLER
H = HEAT PUMP
NOMINAL
COOLING CAPACITY
(BTUH)
07 = 7,000 Btuh
09 = 9,000 Btuh
12 = 12,000 Btuh
15 = 15,000 Btuh
VOLTAGE
3=230/208v 60 Hz 1 PH
4=265v 60 Hz 1 PH
5=240/220v 50 Hz 1 PH
C - 4
AMANA C-MODEL
PTC124A**AC PTC153A**AC
230/208 265 230/208
12,000 14,200 / 14,000
4.6/5.0 4.3 6.3 / 6.9
1,130 1545 /1520
10.7 10.7
6.4 5.7
325 / 315 325 325/315
250 / 229 250 250/220
345 / 335 345 345/335
265 / 235 265 265/235
70* 70*
70* 70*
3.5 3.5
105 105
120 120
MIN. CIRCUIT OVERCURRENT
AMPS AMPACITY PROTECTION
(NOTE 2) (NOTE 4)
14.2
19.6
27.7
10.0 12.4
14.6 18.1
19.5 24.2
3 A 35
SPECIAL FEATURE CODE
A = Standard Model
MAJOR B = Power Vent
DESIGN C = Seacoast Model
SERIES D = Cond. Disposal Pump
F = Hydronic w/Power Vent & Door
G = Hydronic w/Power Door
H = Hydronic w/Manual Door
J = Power Door
K = Cond. Pump & Power Vent
L = Cond. Pump & Power Door
HEATER SIZES
00 = 0.0 KW
15 = 1.5 KW
25 = 2.5 KW
35 = 3.5 KW
3.7 KW (265V) Models
50 = 5.0 KW
PTC154A**AC
265
14,200
5.9
1,525
9.2 9.3
8.4 7.4
325
250
345
265
70* 70*
70* 70*
4.4 4.4
110 110
125 125
POWER
CORD
15 6 - 15 P
20 6 - 20 P
30 6 - 30 P
15 7 - 20 P
20 7 - 20 P
25 7 - 30 P
A C
ENGINEERING
DESIGN LEVEL
(A - C)
