PACKAGE COOLING UNITS
•
Refer to Service Manual RS6300003 for installation, op-
eration, and troubleshooting information.
•
All safety information must be followed as provided in the
Service Manual.
•
Refer to the appropriate Parts Catalog for part number
information.
This manual is to be used by qualified HVAC
technicians only. Amana does not assume
any responsibility for property damage or
personal injury for improper service
procedures done by an unqualified person.
®
Model and Manufacturing
numbers listed in this manual.
MODEL
M/N
PCC24C02E
P1231101C
PCC30C02E
P1231102C
PCC36C02E
P1231103C
PCC42C02E
P1231104C
PCC48C02E
P1231105C
PCC60C02E
P1231106C
RT6322001
February 2000
