Summary of Contents for Ozito HTL-072
-
Page 2: Specifications
SPECIFICATIONS – MODEL NO. HTL-072 Motor: 7.2V Input: 230-240V ~ 50Hz Cutting diameter: Charge time: 3 - 5 hours Run time: 40 minutes (approx.) Hedge trimmer blade length: 150mm Grass blade length/width: 100mm x 74mm Weight: 0.75kg KNOW YOUR PRODUCT 1. -
Page 3: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS ……………………………………….. Page 1 KNOW YOUR PRODUCT………………………………. Page 1 INTRODUCTION………………………………………… Page 3 ELECTRICAL SAFETY…………………………………… Page 3 GENERAL POWER TOOL SAFETY WARNINGS…….. Page 4 BATTERY SAFETY WARNINGS………………………… Page 6 LITHIUM ION HEDGE/GRASS TRIMMER SAFETY WARNINGS………………………………………………. Page 7 BATTERY CHARGING…………………………………… Page 8 FITTING/CHANGING BLADES…………………………... -
Page 4: Introduction
The electric motor has been designed for 230V and 240V only. Always check that the power supply corresponds to the voltage on the rating plate. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. -
Page 5: General Power Tool Safety Warnings
SAFETY INSTRUCTIONS Warning! A battery operated tool with individual batteries or a separate battery pack must be recharged only with the specific charging unit for the battery. A charging unit that may be suitable for one type of battery may create a risk of fire when used with another battery type. - Page 6 General Power Tool Safety Warnings - Personal Safety 3) Personal safety a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
-
Page 7: Battery Safety Warnings
General Power Tool Safety Warnings - Personal Safety g) Use the power tool, accessories and tool bits etc. in accordance with these instructions and in the manner intended for the particular type of power tool, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation. -
Page 8: Lithium Ion Hedge/Grass Trimmer Safety Warnings
Battery Safety Warnings (cont.) • DO NOT store or use the tool and battery pack in locations where the temperature may reach or exceed 40ºC (such as outside sheds or metal buildings in summer). • The charger is designed to operate on standard household electrical power (240 volts). -
Page 9: Battery Charging
BATTERY CHARGING Battery The length of service between each charge will depend on the type of work you are doing. The battery in this Hedge/Grass Trimmer has been designed to provide maximum trouble free life. However, like all batteries, it will eventually wear out. To obtain the longest possible battery life, we suggest the following: •... -
Page 10: Fitting/Changing Blades
FITTING/CHANGING BLADES Changing the blades Fig. 3 Fig. 4 The Hedge/Grass Trimmer is equipped with two blades for all your gardening needs.The hedge trimmer blade (2) is used to cut hedges and the grass shear blade (1) (Fig. 3) is used to cut grass and hedges where finer detail is required (Fig. -
Page 11: Operation
FITTING/CHANGING BLADES (cont.) To remove a blade 1. Turn the Hedge/Grass Trimmer upside down holding in Fig. 10 one hand on a hard surface. Gently lift the tab of the blade cover (9) and slide back until the blade cover (9) can be removed (Fig. -
Page 12: Cutting Tips
Our Environment We at Ozito care about the environment and consider what we may do to protect it. If you share this concern you may already be aware of the suggestions below, if not please consider them as a small step in protecting our future. -
Page 13: Maintenance
Cleaning unusually heavy deposits may require removal of the blades. Note: Ozito Industries will not be responsible for any damage or injuries caused by repair of the trimmer by an unauthorised person or by mishandling of the trimmer. -
Page 14: Description Of Symbols
DESCRIPTION OF SYMBOLS Volts Hertz Alternating current Watts ø Direct current Diameter Milliamperes No load speed Revolutions or Electrical Emissions reciprocation per minute Conformity (EMC) Read instruction manual Warning Indoor use only Double insulated Isolation transformer Polarity Thermal cut-out Transformer Energy protection at 130ºC Rating (MEPS) Lithium Ion battery... -
Page 15: Contents
1 x Hedge Trimmer Blade 1 x Grass Shear Blade 1 x AC Charging Adaptor 1 x Instruction Manual OZITO INDUSTRIES PTY LTD AUSTRALIA (Head Office) 1 - 23 Letcon Drive, Bangholme, Victoria, Australia 3175 Telephone: 1800 069 486 Facsimile: +61 3 9238 5588 Website: www.ozito.com.au... -
Page 16: Warranty
PURCHASED FROM: ________________________________________________ DATE PURCHASED: ________________________________________________ 2 YEAR REPLACEMENT WARRANTY Your Ozito tool is guaranteed for a period of 24 months from the original date of purchase and is intended for DIY (Do it yourself) use only. WARNING The following actions will result in the warranty being void.
